PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
1.47
5
LENGTH TO SUIT USER REQUIREMENTS
4
COAT THREADS OF SENSOR WITH PTFE THREAD SEALANT IF REQUIRED
(FOR VACUUM TIGHT SEAL ONLY)
3
ADJUST MODEL 065B01 SEAL TO APPROXIMATE POSITION REQUIRED
2
USE 9/32 [7] NUT DRIVER TO TURN SENSOR INTO TAPPED HOLE. NORMAL
LOCATION OF DIAPHRAGM FACE IS FLUSH WITH INSIDE SURFACE. RECESS .010 [.25]
FOR ABLATIVE COATING IF DESIRED. WHILE HOLDING SENSOR WITH NUT DRIVER,
A
TIGHTEN SEAL TO OBTAIN PRESSURE-TIGHT SEAL AND LOCK SENSOR IN PLACE.
RECOMMENDED MOUNTING TORQUE 20-25 IN-LBS [226-282 N-cm]
1.) THIS SENSOR IS A SEALED ASSEMBLY AND MUST BE RETURNED TO THE
FACTORY SHOULD SERVICE BECOME NECESSARY
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS
XX ±.01
XXX ±.005
ANGLES
2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1'
=
+1"/ - 0
1'≤ LENGTH < 5'
=
+2"/ - 0
5'≤ LENGTH < 100'
=
+6"/ - 0
100'≤ LENGTH
=
+1'/ - 0
FILLETS AND RADII
.003 - .005
2
[
]
.05 37.2
1.3
.82 [20.9]
5
DIMENSIONS IN MILLIMETERS
NJF
[ IN BRACKETS ]
DECIMALS
X
± 0.3
XX
± 0.13
TITLE
ANGLES
2 DEGREES
CABLE TOLERANCES IN METRIC
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
MODEL 101A & 102A02, A07, A09, A12
30.5cm ≤ LENGTH < 1.5m
= +5.1cm/ - 0
1.5m
≤ LENGTH < 30.5m
= +15.2cm/ - 0
30.5m ≤ LENGTH
= +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
REV
B
UPDATED OVERALL LENGTH TOLERANCE
DRAWN
CHECKED
10/04/22
10/04/22
JDM
INSTALLATION DRAWING
PRESSURE SENSORS
1
REVISIONS
DESCRIPTION
ELECTRICAL CONNECTOR
10-32 UNF - 2A
CLAMP NUT
2
9/32 [7] HEX
MODEL 065B01 SEAL
3
9/16 [14] HEX
(SUPPLIED)
3/8-24 UNF - 2A 4
MOUNTING HOLE PREPARATION:
3/8-24 UNF - 2B THRU
ENGINEER
10/04/22
AJA
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE:
2X
1
DIN
53183
B
A
8495
SHEET
1 OF 1
