PCB Piezotronics ICP 102A08 Installation And Operating Manual page 10

Model Number
102A08
Performance
Measurement Range(for ±5V output)
Sensitivity(± 15 %)
Maximum Pressure(static)
Resolution
Resonant Frequency
Rise Time
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Electrical Isolation
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector 10-32 Coaxial Jack
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
50 psi 345 kPa
100 mV/psi 14.5 mV/kPa
1 kpsi 6,895 kPa
0.001 psi 0.007 kPa
≥ 430 kHz ≥ 430 kHz
≤ 1.0 µ sec ≤ 1.0 µ sec
0.5 Hz 0.5 Hz
≤ 1.0 % FS ≤ 1.0 % FS
≤ 0.002 psi/g ≤ 0.0014 kPa/(m/s²)
-100 to +275 °F -73 to +135 °C
≤ 0.03 %/°F ≤ 0.05 %/°C
3,000 °F 1,650 °C
20,000 g pk 196,000 m/s² pk
Positive Positive
≥ 1.0 sec ≥ 1.0 sec
24 to 30 VDC 24 to 30 VDC
2 to 20 mA 2 to 20 mA
< 100 Ohm < 100 Ohm
10 to 15 VDC 10 to 15 VDC
8 8
10 Ohm 10 Ohm
Compression Compression
Quartz Quartz
Stainless Steel Stainless Steel
Invar Invar
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack
0.42 oz 12 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1] - Metric Mount
M
Supplied Accessory: Model 065A42 Floating clamp nut and thread seal, M10 x 1.0 thd. (1)
N - Negative Output Polarity
S - Stainless Steel Diaphragm
Diaphragm
[2]
N OTES:
[1]Due to high sensitivity, the static pressure should be applied and removed very slowly. Rate should
prevent more than 10 Volt change in output until Output Bias Voltage returns to normal
(approximately 15 times discharge time constant).
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 065B01 Floating clamp nut and thread seal 3/8-24 thd (1)
Entered: ND Engineer: RPF
Date: 11/28/2022 Date: 11/28/2022 Date: 11/28/2022 Date: 11/28/2022 28383
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 53357
OPTION AL VERSION S
316L Stainless Steel 316L Stainless Steel
Sales: RWM Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
