- Page 1 24’ 12-Light String Light INSTALLATION MANUAL SKU NUMBER: 346-2129 MODEL : lvy-24PT-SLPB 24 ft 12” 24” 12” Questions, problems, need help? Call our customer service department at 1-866-839-2888, 8 a.m. - 5 p.m., EST, Monday - Friday P. 1 2022-03-10...
- Page 2 PACKAGE CONTENT PART # DESCRIPTION QUANTITY REPLACEMENT PART AVAILABILITY Power Cord Not Available Socket Assembly Not Available Replacement Available (call customer LED Bulb +1 replacement service 1-886-839-2888) Male Socket Not Available Female Socket Not Available Plastic Shade (with lock nut) Not Available TOOLS REQUIRED (not supplied) Ladder...
- Page 3 Any modification or alteration from what is specified in this instruction manual will void any and all warranty on this product. PATRIOT LIGHTING® is not responsible for any damage to the unit or personal property caused by improper installation. If you disregard instructional warnings, you will void your warranty and possibly deal with damage.
- Page 4 STRING LIGHT INSTALLATION 1.1.* If you are connecting multiple string light sets in series (up to 60 sets), connect the male socket (D) of the next light set to the current set’s female socket (E). 1.2. Install the plastic shades (F) by screwing lock nut to the socket assembly (B). 1.3.
- Page 5 Patriot Lighting products will remain beautiful for many years if you properly care for them. Patriot Lighting does not recommend the use of harsh abrasive cleaners on any of its products. Harsh cleaners will damage the finish of your product.
