Spirent VisionWorks 7562
Probe
Installation and Setup Manual
Issue 7
November 04, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VisionWorks 7562 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spirent VisionWorks 7562

Summary of Contents for Spirent VisionWorks 7562

  • Page 1 Spirent VisionWorks 7562 Probe Installation and Setup Manual Issue 7 November 04, 2022...
  • Page 2 © 2022 Spirent Communications, Inc. All of the company names and/or brand names and/or product names referred to in this document, in particular the name “Spirent” and its logo device, are either registered trademarks or trademarks pending registration in...

  • Page 3: Table Of Contents

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Contents Introduction 1.1 Important safety notes ........1-1 1.2 About this document .
  • Page 4 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2.6 Commands ..........2-10 2.6.1 Unit configuration/administration commands .
  • Page 5 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Accessing a TL1 prompt ......... . . 4-4 Conducting Ethernet management communications .
  • Page 6 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual www.spirent.com...
  • Page 7 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual List of Figures 1: Introduction 2: Product Overview Figure 2-1 VisionWorks Probe and an Ethernet network – Example ....2-3 Figure 2-2 Typical physical configuration (DC powered units) .
  • Page 8 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Figure 4-3 Connection to a USB port ........4-4 Figure 4-4 Sample HyperTerminal connection/COM options .
  • Page 9 Table 1-8 Related Spirent documents ........
  • Page 10 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 3: Installation 4: Verification and Configuration Table 4-1 Physical configuration verification ....... . . 4-18 5: Maintenance www.spirent.com...

  • Page 11: Introduction

    This product should be installed, operated, and serviced as specified in this and other product documentation. A failure to adhere to published directives may result in equipment damage and/or personal injury. Spirent assumes no liability for damage or injury that occurs as a result of a failure to heed the documentation, and likewise any damage caused in this manner may void the warranty.
  • Page 12 • No user-serviceable parts inside. Do not open unit. • Any power cords provided by Spirent are intended for use with Spirent products only. • Ultimate disposal of this product should be handled according to all national laws and regulations.

  • Page 13: About This Document

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 1.2 About this document 1.2.1 Purpose and scope This document provides overview, installation, and configuration information for the model 7562 VisionWorks Probe, which is a standalone, non-modular chassis with two 100 Gbps test ports.The total simultaneous bandwidth across both ports is 200 Gbps,...

  • Page 14: Conventions

    Initial publication - - - 1.2.4 Conventions Notes and safety alerts are used throughout Spirent Communications manuals to highlight important information or to warn users of possible personal injury or property damage. NOTE is used to call attention to important information.

  • Page 15: Related Documents

    Spirent Knowledge Base (http://support.spirent.com/). The Knowledge Base gives you access to tens of thousands of documents that help answer your network analysis and measurement questions. New content is added daily by Spirent’s communications and networking experts.
  • Page 16 UK (EMEA TAC) +44 1803 546333 CAUTION: The unit must be returned to Spirent Communications for service. Do not remove the cover of the unit. on page 5-2 for instructions on how to return Returning a defective unit for service the unit.

  • Page 17: Product Overview

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2: Product Overview This section provides an overview and physical descriptions of the unit. It includes the following information: • Warnings and symbols on page 2-1 - Describes warnings and symbols that may appear on the product.

  • Page 18: Product Purpose And Architecture Notes

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Symbol Description The installation and handling of this product carries the risk of electrical shock. This product falls under Waste Electronic and Electrical Equipment (WEEE) Directive. Before disposing of this product, consult local regulations and/or contact Spirent.

  • Page 19: Typical Unit Configuration (Wiring/Connectivity)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Customer site Customer site Provider edge Customer edge Customer edge Provider edge device device device device Transport network core (L2VPN, MPLS, etc.) Test Test Test Test interface Core device...

  • Page 20: Access Device Notes

    Specific details on interoperability are complex and beyond the scope of this document. For more information, please contact Spirent. A network administrator typically selects the port(s) for test access and performs any necessary configuration, then informs the installation personnel so they know where to connect the unit test interface(s).

  • Page 21: Physical Description

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2.3 Physical description WARNING Intra-building ports described in this section and subsections are suitable for connection to intra-building or unexposed wiring or cabling only. They MUST NOT be metallically connected to interfaces that connect to the outside plant (OSP) or its wiring.

  • Page 22: Figure 2-4 Management Port Leds

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Feature Description Ethernet/IP 10/100/1000 Mbps port for TL1 management over plain text or SSH, management intended for the permanent management connection. The port has two LEDs: (MANAGEMENT) Link/Activity Link speed Figure 2-4 MANAGEMENT port LEDs •...

  • Page 23: Main Chassis Features - Rear View

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Feature Description General status HD - Flashes during hard drive activity. LEDs STATUS - Provides the following indications: Solid green - Normal operation. • • Blinking green - System is booting up (initializing).

  • Page 24: Factory-Assigned Management Ip Addresses

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Table 2-3 Chassis rear features Feature Description Chassis ground on page 3-7. Chassis ground connection connections Fan module One of four removable, interchangeable fan modules. Power switch Basic on/off power switch. Note that the switch executes internal routines for software-based startup and shutdown.

  • Page 25: Tcp/Ip Ethernet Management Port Pinout (Management)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Table 2-4 Async (CONSOLE) port pinout Description Request to send (RTS) Not connected Transmit data (TxD) Signal ground Signal ground Receive data (RxD) Not connected Clear to send (CTS)

  • Page 26: Commands

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2.6 Commands The unit uses a subset of TL1 commands as defined in the Operations Technology General Requirement (OTGR), a Telcordia publication. Additionally, it implements many commands specific to its respective functionality. This section lists supported commands that are applicable to the unit and basic information about these commands.
  • Page 27 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Command Extended name Description Edit User Security Edits the password associated with a TL1 user ED-USER-SECU identifier. The user must have access privileges at least as high as those associated with the user to be changed.

  • Page 28: Test Access Commands

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Command Extended name Description Retrieve Licensed Retrieves a list of unit options that are currently RTRV-LICENSED- OPTIONS Options licensed. RTRV-USER-SECU Retrieve User Retrieves a list of all previously-configured TL1 Security user identifiers.

  • Page 29: Data Testing Commands

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Command Extended name Description Disconnect Test Causes the unit to release the specified test DISC-TACC Access session in an orderly fashion (that is, “drop” the access), as applicable to the access configuration and access device type.

  • Page 30: Table 2-9 "Pm" Active Tests

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Test name TL1 command Description IP Ping TST-MCAST-PING Sends ICMP ping requests to a multicast address and waits for unicast (Multicast) responses, then reports on the host(s) specified the test input.

  • Page 31: Table 2-10 Loopbacks And Servers

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Test name TL1 command Description IP Ping TST-PING-PM Runs a set of unicast ICMP ping tests to multiple targets in a (Unicast) simultaneous, ongoing manner. It is designed to leverage the capabilities of TST-PING for long-term performance monitoring, versus on-demand tests typically used for verification and troubleshooting.

  • Page 32: Table 2-11 Passive Data Testing Commands

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Test name TL1 command Description Multicast MEF TST-MLPBK- Performs a multicast loopback to identify MEPs on the service. The test 46 Loopback MEF46 operates at the Ethernet layer, where a multicast loopback request frame...

  • Page 33: Detailed Specifications

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2.7 Detailed specifications 2.7.1 Dimensions and weight NOTE: Physical dimensions and weight are approximate and may vary according to installed components. Height Width Depth Weight 1.8 in 16.8 in 17.3 in...

  • Page 34: Temperature

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2.7.3 Temperature Operating temperature Storage temperature Operating humidity range range 32° to 113° F -40° to 194° F 5 to 96% (0° to 45° C) (-40° to 90° C) 2.8 Regulatory compliance...

  • Page 35: Rohs Table

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2.9 RoHS table 2-19 www.spirent.com Product Overview...
  • Page 36 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 2-20 www.spirent.com Product Overview...

  • Page 37: Site Planning And Engineering

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 3: Installation This section contains information on how to install and configure the unit, including: • on page 3-1 - How to plan for an installation. Site planning and engineering •...

  • Page 38: Rack Space Requirements

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 3.1.1 Rack space requirements When using an existing rack, you should verify whether the necessary space is available. Ensure that one extra rack mounting space is left empty above the unit for heat dissipation.

  • Page 39: General Installation Notes

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 3.2.2 General installation notes The entire installation must be in compliance with local guidelines, including safety, administrative, general, and installation requirements and methods. A copy of the product application drawings should be retained on the job site for reference.

  • Page 40: Unpacking And Inspection

    1-5 for contact Technical assistance information. Do not return the equipment to Spirent until a claim for damage has been established. Under U.S. shipping regulations, damage claims must be submitted by the consignee. Retain all bills of material, instructions, and other documents.

  • Page 41: Mounting Procedure

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Front of unit Figure 3-1 Front-mount rack ear installation Front of unit Figure 3-2 Center-mount rack ear installation 3.2.7 Mounting procedure 1. Attach the rack ears using the supplied hardware. For more information, see Rack on page 3-4.

  • Page 42: Wiring Connections

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 3.3 Wiring connections This section provides information on the cabling connections for the unit. 3.3.1 Optical transceivers CAUTION: Removal and/or installation of transceivers requires wrist straps or comparable ESD precautions.

  • Page 43: Management And Test Interface Wiring

    AWG. • A listed, two-hole grounding lug is required for connecting the ground wire to the unit. One such lug used in the Spirent lab is the Panduit LCDX6-14A. Other models from other manufacturers are also available. See Figure 3-4 for size requirements.

  • Page 44: Figure 3-4 Ground Terminal Connection On Rear Of Unit

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual • Both ends of the grounding cable, including all applicable hardware, should be coated with an anti-oxidant/corrosion-preventative compound. When grounding to an equipment rack or similar, it may be necessary to remove paint, after which a thin coat of compound should be used between the lug and the metal to ensure contact.

  • Page 45: Dc Power Wiring (Dc-Powered Models)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual NOTE: For a more detailed diagram of the rear of the unit, see Main chassis on page 2-7. features - Rear view 2. Connect the other end to the equipment rack ground system as shown in the following figure.
  • Page 46 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual – For a DC mains supply that is not a hazardous voltage, a removable fuse, provided that it is accessible only to a service person – Any equivalent device •...

  • Page 47: Figure 3-6 -48 Vdc Power Connections

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual -48 VDC Battery return 3. Remove power from the leads, normally by removing the panel fuse. 4. Remove the cover from the power connection terminals, if installed. 5. Connect the -48 VDC lead to the negative (-) power terminal on the unit (left terminal).

  • Page 48: Ac Power Cord Connection And Retaining Clip

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual For instructions on powering up the unit, see Powering up and shutting down the unit on page 3-14. 3.3.5 AC power cord connection and retaining clip Before connecting the power cord, note the following: •...

  • Page 49: Figure 3-7 Ac Power Cord Connection - Insert The Cord

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Figure 3-7 AC power cord connection - Insert the cord With the plug fully inserted, gently pull the clip back and slide it over the plug, as shown in the following figure: 3-13 www.spirent.com...

  • Page 50: Powering Up And Shutting Down The Unit

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Figure 3-8 AC power cord connection - Mount the clip For instructions on powering up the unit, see Powering up and shutting down the unit on page 3-14. 3.4 Powering up and shutting down the unit To start up the unit: On the rear of the chassis, set the chassis power switch to the “on”...
  • Page 51 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Solid green POWER and STATUS LEDs on the front panel (see • Main chassis on page 2-5). features - Front view • For each connected test port, a solid green LNK LED.
  • Page 52 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 3-16 www.spirent.com Installation...

  • Page 53: General Operation

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 4: Verification and Configuration This section contains information about provisioning, testing, and basic operation of the unit. For detailed information on unit operation, see the Command and Operation Manual.

  • Page 54: Basic Management Communications

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual When controlled by a Spirent OSS or other system, a VisionWorks Probe access on an Ethernet switch is an example of RTU mode access. For example, during a passive (monitor) access, the OSS sends commands to the switch which cause it to mirror a port or VLAN to the passive test access port.

  • Page 55: Preparations For Async Communications Over Usb

    PC. Because many modern PCs do not have a serial port, a USB connection may be the only option. To use the USB option, you must order a USB-to-serial adapter cable from Spirent. This cable connects to the serial cable included with the unit.

  • Page 56: Connecting The Cable

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual The driver software may be located under the Support tab. 3. Unzip the ZIP, find the proper installation EXE file in the Windows area, and run it to install the drivers.

  • Page 57: Conducting Ethernet Management Communications

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual • The numbering of COM ports varies between PCs. If you have more than one selection available, you may need to examine system hardware settings (or use trial and error) to determine the correct selection.
  • Page 58 No password is required. All other ports are closed. Upon a successful connection with either protocol, the unit provides immediate access to a TL1 prompt, for example: COPYRIGHT 2009-2021 SPIRENT COMMUNICATIONS OF ROCKVILLE, INC., ALL RIGHTS RESERVED www.spirent.com Verification and Configuration...

  • Page 59: About The Onboard Dhcp Server

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Host : VISIONWORKS-PROBE Firmware Rev : RA13.40.04 Under normal conditions, a semicolon appears where you may issue an ACT-USER command to achieve higher access privilege. Note that along with all other ports not mentioned, the normal Telnet port 23 is permanently closed on all units.

  • Page 60: About In-Band Management

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual – If the pings fail, it starts up the server. In this case, it assumes that it still has the default factory configuration and/or is connected directly to a PC. Likely, the factory-configured default gateway will never be a valid address.

  • Page 61: Powering Up And Shutting Down The Unit

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual When the parameter is set to enable in-band management, the dedicated management port becomes immediately unresponsive and transfers to the specified test port. Therefore, it is strongly recommended to use the async provisioning port with a local computer for this action.

  • Page 62: Static Date/Time Configuration

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual NOTE: “Network time” (NTP or PTP) is required if the unit will be used for one-way latency tests to other units, or in any situation where its internal clock needs to be synchronized with an external device or system.

  • Page 63: Precision Time Protocol (Ptp)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual – Have the NTP server derive time from an external source with low jitter (for example, a GPS receiver or sync from several lower stratum NTP servers). – Check the server's relative frequency, assuming a value below 50 (absolute value) as preferable.

  • Page 64: Time Zones Supported For Network Time

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual • Reduce the number of hops to the master clock server. Fewer hops normally result in more consistent jitter and latency, which in turn makes PTP more accurate. PTP includes a hierarchy of master clocks such as grandmaster clocks, boundary clocks, and transparent clocks that may be available for strategic hop reduction.
  • Page 65 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual America/Atka America/Bahia America/Barbados America/Belem America/Belize America/Blanc-Sablon America/Boa_Vista America/Bogota America/Boise America/Buenos_Aires America/Cambridge_Bay America/Campo_Grande America/Cancun America/Caracas America/Catamarca America/Cayenne America/Cayman America/Chicago America/Chihuahua America/Coral_Harbour America/Cordoba America/Costa_Rica America/Cuiaba America/Curacao America/Danmarkshavn America/Dawson America/Dawson_Creek America/Denver America/Detroit...
  • Page 66 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual America/Scoresbysund America/Shiprock America/St_Barthelemy America/St_Johns America/St_Kitts America/St_Lucia America/St_Thomas America/St_Vincent America/Swift_Current America/Tegucigalpa America/Thule America/Thunder_Bay America/Tijuana America/Toronto America/Tortola America/Vancouver America/Virgin America/Whitehorse America/Winnipeg America/Yakutat America/Yellowknife Antarctica/Casey Antarctica/Davis Antarctica/DumontDUrville Antarctica/Mawson Antarctica/McMurdo Antarctica/Palmer Antarctica/Rothera Antarctica/South_Pole...
  • Page 67 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Asia/Ulaanbaatar Asia/Ulan_Bator Asia/Urumqi Asia/Vientiane Asia/Vladivostok Asia/Yakutsk Asia/Yekaterinburg Asia/Yerevan Atlantic/Azores Atlantic/Bermuda Atlantic/Canary Atlantic/Cape_Verde Atlantic/Faeroe Atlantic/Faroe Atlantic/Jan_Mayen Atlantic/Madeira Atlantic/Reykjavik Atlantic/South_Georgia Atlantic/St_Helena Atlantic/Stanley Australia/ACT Australia/Adelaide Australia/Brisbane Australia/Broken_Hill Australia/Canberra Australia/Currie Australia/Darwin Australia/Eucla Australia/Hobart...
  • Page 68 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Europe/Chisinau Europe/Copenhagen Europe/Dublin Europe/Gibraltar Europe/Guernsey Europe/Helsinki Europe/Isle_of_Man Europe/Istanbul Europe/Jersey Europe/Kaliningrad Europe/Kiev Europe/Lisbon Europe/Ljubljana Europe/London Europe/Luxembourg Europe/Madrid Europe/Malta Europe/Mariehamn Europe/Minsk Europe/Monaco Europe/Moscow Europe/Nicosia Europe/Oslo Europe/Paris Europe/Podgorica Europe/Prague Europe/Riga Europe/Rome Europe/Samara...

  • Page 69: Post-Installation Configuration And Verification

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Pacific/Norfolk Pacific/Noumea Pacific/Pago_Pago Pacific/Palau Pacific/Pitcairn Pacific/Ponape Pacific/Port_Moresby Pacific/Rarotonga Pacific/Saipan Pacific/Samoa Pacific/Tahiti Pacific/Tarawa Pacific/Tongatapu Pacific/Truk Pacific/Wake Pacific/Wallis Pacific/Yap Poland Portugal PST8PDT Singapore Turkey Universal US/Alaska US/Aleutian US/Arizona US/Central US/Eastern US/East-Indiana...

  • Page 70: Postinstallation Configuration (Unit Provisioning)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual NOTE: Make sure the installation instructions in Mounting on page 3-2 have been accurately followed before beginning the verification. Also, visually inspect the equipment for loose connectors, missing grounds, and proper fuse ratings.
  • Page 71 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual NOTE: This procedure covers basic configuration parameters that typically require an operator on-site, primarily the configuration of the management port for remote operation. The unit has many other configurable parameters which may or may not need to be set before running test functions, depending upon implementation details.
  • Page 72 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual NEW-TESTSET-SID 00-00-00 00:00:32 M CTAG COMPLD 5. Assign the date and time. NOTE: The date is entered as yymmdd. The time is entered as 24-hour hhmmss. Also, network time protocol (NTP or PTP) is supported in place of entering a static date and time.
  • Page 73 Sample command: INIT-SYS:::CTAG::4; Sample response: NEW-TESTSET-SID 10-04-21 10:21:30 M CTAG COMPLD COPYRIGHT 2009-2019 SPIRENT COMMUNICATIONS OF ROCKVILLE, INC., ALL RIGHTS RESERVED Host : NEW-TESTSET-SID Firmware Rev : RA13.10.07 9. Log back into the unit after the system has been initialized.

  • Page 74: Functional Testing Procedures

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual RTRV-ATTR-IP:[<sid>]:[<jid>]:<ctag>; Sample command: RTRV-ATTR-IP:::CTAG; Sample response: NEW-TESTSET-SID 10-04-21 14:28:18 CTAG COMPLD /* JID DHCP IP ADDRESS " MGMT 10.32.90.18 " /* SUBNET MASK DEFAULT GATEWAY " 255.255.255.0 10.32.90.1 "...
  • Page 75 3. Retrieve and verify the test session information. Command format: RTRV-COND-TST:[<sid>]:[<tsn>]:<ctag>; Sample command: RTRV-COND-TST:::CTAG; Sample response: Passive session: NEW-TESTSET-SID 10-04-21 10:22:04 CTAG COMPLD /* SPIRENT COMMUNICATIONS OF ROCKVILLE - COPYRIGHT (C) 2009-2019 */ /* TSN PORT VLAN PRI SRC_IP CIR KFPS DES_ADDR STATUS " " " "...

  • Page 76: Passive Testing (Top Talkers)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual NEW-TESTSET-SID 10-04-21 10:22:04 CTAG COMPLD /* SPIRENT COMMUNICATIONS OF ROCKVILLE - COPYRIGHT (C) 2009-2010 */ /* TSN PORT VLAN PRI SRC_IP CIR KFPS DES_ADDR STATUS " 172.30.1.10 " "...

  • Page 77: Active Testing (Ping)

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual ADDR=300 COUNT=3392 BYTE COUNT=904429 BWIDTH=0.07751 RATE=338.01916 TOTBWIDTH=0.07751 TOTRATE=338.01916 Sample response with no traffic reported: NEW-TESTSET-SID 10-04-21 10:22:04 M CTAG COMPLD VLAN TOP TALKERS ON VLAN 300 0000-10 FLOWS=0 TOTBWIDTH=0.00000 TOTRATE=0.00000...

  • Page 78: Disconnecting The Test Session And Logging Off

    Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual "REPLY FROM 172.30.1.20: BYTES = 32 TIME < 1 MS TTL = 64" "REPLY FROM 172.30.1.20: BYTES = 32 TIME < 1 MS TTL = 64" "REPLY FROM 172.30.1.20: BYTES = 32 TIME < 1 MS TTL = 64"...
  • Page 79 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual Sample response: NEW-TESTSET-SID 10-04-21 10:22:04 M CTAG COMPLD 3. If unit shutdown is desired, see Powering up and shutting down the unit page 4-9. 4. Disconnect the laptop from the unit.
  • Page 80 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual 4-28 www.spirent.com Verification and Configuration...

  • Page 81: Maintenance

    Technical assistance on page 1-5. 5.2 Maintenance (Fan filter) Spirent recommends inspection of the fan filter every 24 months and replacement of the filter if deemed necessary. The filter detaches from the front using the two hand fasteners (see on page 2-5).

  • Page 82: Returning A Defective Unit For Service

    6. Pack the unit in the original shipping container or a strong, double-walled shipping container. 7. Mark the shipping container as follows: FRAGILE: DELICATE ELECTRONIC INSTRUMENT 8. Ship the container to Spirent with the return authorization number printed on it, for example: ATTN: Return Authorization Number: _________ www.spirent.com...

  • Page 83: Maintenance Agreement

    Issue 7 - Installation and Setup Manual 5.4 Maintenance agreement Spirent Communications offers a hardware maintenance agreement to extend the first year limited warranty of the unit for an additional year. This maintenance agreement can be renewed annually for up to five years from the date of original shipment. Contact...
  • Page 84 Spirent VisionWorks 7562 Probe Issue 7 - Installation and Setup Manual www.spirent.com Maintenance...
