Spirent B2-800-QD-4-T1S

Installation Instructions

Refer to the Release Notes for information on supported software applications and

versions.

•

PN 71-009377 Rev A May 2022

Getting Started . . . . 4

Certifications and Standards . . . . 5

Technical Specifications . . . . 7

Site Selection . . . . 8

Rack Mounting Considerations . . . . 8

Requirements . . . . 9

System Description . . . . 10

Appliance Firmware Support . . . . 15

Connecting to the Appliance . . . . 16

Need help?

Do you have a question about the B2-800-QD-4-T1S and is the answer not in the manual?

Questions and answers

Summary of Contents for Spirent B2-800-QD-4-T1S

Page 1: Table Of Contents
Appliance Firmware Support ..15 • Connecting to the Appliance ..16 • Related Documentation ..21 • How to Contact Us ..22 PN 71-009377 Rev A May 2022 Spirent B2-800-QD-4-T1S Installation Instructions...
Page 2 Software which it supplies will operate in material conformity with the specifications supplied by Spirent for such Software for a period of ninety (90) days from the date of delivery (the “Software Warranty Period”). The “Product Warranty Period” shall mean the Hardware Warranty Period or the Software Warranty Period, as applicable.
Page 3 WARRANTIES, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, NONINFRINGEMENT AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY EXCLUDED, AND THE LIABILITY OF SPIRENT, IF ANY, FOR DAMAGE RELATING TO ANY ALLEGEDLY DEFECTIVE PRODUCT SHALL BE LIMITED TO THE ACTUAL PRICE PAID BY THE CUSTOMER FOR SUCH PRODUCT.
Page 4: Getting Started
Getting Started B2-800-QD-4-T1S is operated with specialized software designed to help you create and analyze realistic traffic for determining the operating characteristics of a device, system, or network under test. Due to the powerful traffic generating capabilities of B2-800-QD-4- T1S, precautions should be taken when connecting the test ports to an operational network.
Page 5: Certifications And Standards
Connect the appliance test ports to your device or system under test. Certifications and Standards Spirent B2-800-QD-4-T1S complies with the limits for a Class A digital device in accordance with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment.
Page 6 CERTIFIED TO CSA STD C22.2 NO. 62368-1 ETL marking This product carries the cETLus mark.Environmental Considerations This label is on all Spirent-provided electrical and electronic products that are sold and shipped. Figure 1. Waste of Electrical and Electronic Equipment (WEEE) Label This label indicates that the product contains material that presents an environmental concern.
Page 7: Technical Specifications
Spirent B2-800-QD-4-T1S Installation Instructions Technical Specifications Technical Specifications • Environmental • Operating requirements: 50° to 95° F (10° to 35° C) when using QSFP-DD800 transceivers rated up to 15W of type 2A with a transceiver case temperature thermal limit of 70C. When using QSFP-DD800 transceivers dissipating 30W of type 2A with a thermal limit of 70C, the maximum operating temperature is 68°...
Page 8: Site Selection
Spirent B2-800-QD-4-T1S Installation Instructions Site Selection Site Selection The Spirent B2-800-QD-4-T1S appliance is a high-end network testing device that must be installed in a dust free and dry environment with adequate airflow, power, and cooling. • The appliance is designed with front to rear airflow and both ventilation locations must remain unobstructed for proper operation.
Page 9: Requirements
Note: The terms management port and administrative port are used interchangeably. 10/100/1000 Base-T Administrative Port The administrative port must connect to a 10/100/1000 Base-T network. Spirent recommends the appliance be connected through a switch and isolated from your test environment.
Page 10: System Description
Connector Panel Figure 2 shows the connector panels and Table 1 on page 10 describes the connectors on the appliance. Figure 2. B2-800-QD-4-T1S Front and Back Panel Connectors Table 1. B2-800-QD-4-T1S Connectors Connector Description Power switch – press this button to power on and off the appliance.
Page 11 Spirent B2-800-QD-4-T1S Installation Instructions System Description Table 1. B2-800-QD-4-T1S Connectors (continued) Connector Description Console access and control from left to right: • USB 3.1 port • USB 2.0 port • Video VGA connector External Time Reference connectors, from left to right: •...
Page 12 Spirent B2-800-QD-4-T1S Installation Instructions System Description Front Panel System LEDs The LEDs located on the front of the chassis show the status of the chassis and the PC connection. Table 2 describes the operation. Table 2. Front Panel System LEDs...
Page 13 Spirent B2-800-QD-4-T1S Installation Instructions System Description Test Port LEDs Each test port has one multi-color LED to indicate the speed for which the port is configured. The SPEED LEDs are labeled on the front panel. Table 3 describes the speed LEDs.
Page 14 (Figure 2 on page 10) to turn on the appliance. The typical boot time is seven (7) minutes. Package switch times (switching from Spirent TestCenter to another product, or from another product to Spirent TestCenter) and firmware upgrades take approximately 10-15 minutes.
Page 15: Appliance Firmware Support
Power off the appliance, before you unplug it. Appliance Firmware Support With the dual boot feature, you can switch between two installed versions of Spirent TestCenter using the command line interface. You can identify the current version and standby version using the appropriate commands described in this section.
Page 16: Connecting To The Appliance
You will be presented with a login prompt when the appliance is fully booted up. Use the following system administrator login / password: • Login: admin • Password: spt_admin Spirent TestCenter - Spirent Communications, Inc. Device : 192.168.0.100 255.255.255.0 (static) Gateway : 192.168.0.1 Welcome admin.
Page 17 Spirent B2-800-QD-4-T1S Installation Instructions Connecting to the Appliance You can now use the following commands to set the addressing mode and/or set the IP address, netmask and gateway. When you have made your changes, you must activate the new settings and reboot the appliance: admin(hypervisor)>>...
Page 18 Spirent B2-800-QD-4-T1S Installation Instructions Connecting to the Appliance Table 6. Spirent Admin Commands Command Description activate [[<deviceName>]<ipaddress> Save and activate the network configuration <netmask> <gwaddress>] | [dhcp] | [ipv6 [<deviceName>] <ipv6addres> <ipv6gwaddress>] authenticate [on|off|reset] Enable | Disable | Reset authenticate mode console <vm name>...
Page 19 Spirent B2-800-QD-4-T1S Installation Instructions Connecting to the Appliance Table 6. Spirent Admin Commands (continued) Command Description ping6 <ipv6address> Ping an IPv6 address Display or change the ptp settings reboot Reboot the system recovery <chassis|tm> <enable|disable> Enable or disable appliance or test module recovery (Test...
Page 20 When authenticate is on or reset, a password must be generated using simple ascii text, but it cannot be left blank. After the password is generated, the Spirent TestCenter GUI or API user will be required to enter the generated password when they attempt to connect to the chassis or appliance.
Page 21: Related Documentation
The release notes are available as a Related Resource on the CSC Downloads page (https://support.spirent.com). • If you are using the new Spirent AION Platform for licensing, refer to the Spirent AION Setup Guide f or details on how to deploy the platform on- premises.
Page 22: How To Contact Us
Phone: +86 (400) 810-9529 (toll-free mainland China only) Phone: +86 (10) 8233 0033 (China) Hours: Monday through Friday, 09:00 to 18:00, Beijing Time Information about Spirent Communications and its products and services can be found on the main company website at https://www.spirent.com. Company Address Spirent Communications, Inc.
