- Page 1 Doc. No. DOC1051887 PRODUCT NAME Digital pressure switch for vacuum compatible) MODEL / Series / Product Number ZK2-ZS□L□□□□-A ZB1-ZS□L□□-A ZL3-VP□-1-□L□□-A ZQ-ZS□L□□□□-□-A...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions Model Indication and How to order Summary of Product parts Wiring Wiring Internal circuit and wiring example Mounting and Installation IO-Link specifications Outline of the IO-Link functions Communication specifications Process data IO-Link parameter setting Example of ejector operation Setting Setting by buttons Default setting... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing business. Use in non-manufacturing business is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 Operator This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
- Page 6 Caution ■Do not touch the terminals and connectors while the power is on. Otherwise electric shock, malfunction or damage to the product can result. ■Perform sufficient trial run. Otherwise, injury or damage to the system can result due to suction failure depending on the conditions of the suction of the workpiece or the pressure switch settings.
- Page 7 ●Product handling Installation •Tighten to the specified tightening torque. If the tightening torque is exceeded the mounting screws and brackets may be broken. If the tightening torque is insufficient, the product can be displaced and loosen the mounting screws. (Refer to page 16) •Be sure to ground terminal FG when using a commercially available switch-mode power supply.
- Page 8 Wiring •Do not pull the lead wires. In particular, never lift a Pressure switch equipped with fitting and piping by holding the lead wires. Otherwise damage to the internal parts can result, causing malfunction or to be off the connector. •Avoid repeatedly bending or stretching the lead wire, or placing heavy load on them.
- Page 9 •Prevent foreign matter such as remnant of wires from entering the Pressure switch. Take proper measures for the remnant not to enter the Pressure switch in order to prevent failure or malfunction. •Do not use the product in an environment that is exposed to temperature cycle. Heat cycles other than ordinary changes in temperature can adversely affect the inside of the product.
-
Page 10: Model Indication And How To Order
Model Indication and How to order ■ZK2□A series Pressure switch for vacuum (IO-Link compatible) ZK2 - ZS E L1 (1) (2) (3) (4) (5) (1) Rated pressure range and function 0 to -101 kPa PNP open collector 2 outputs (for valves) -100 to 100 kPa (2) Output Supply valve: N.C. - Page 11 ■ZB series Pressure switch for vacuum (IO-Link compatible) ZB1 - ZS E L (1) (2) (3) (4) (1) Rated pressure range and function 0 to -101 kPa PNP open collector 2 outputs (for valves) -100 to 100 kPa (2) Output IO-Link (3) Unit Note 1)
- Page 12 ■ZL3/ZL6 series Pressure switch for vacuum (IO-Link compatible) with valve plate assembly ZL3 - VP 1 - 1 - E L (3) (4) (5) (6) (1) Supply valve N.C. N.O. (2) Release valve N.C. (3) Rated pressure range and function 0 to -101 kPa PNP open collector 2 outputs (for valves) -100 to 100 kPa...
- Page 13 ■ZQ□A series Pressure switch for vacuum (IO-Link compatible) ZQ - ZS EL1 - 0 - A (1) (2) (3) (4) (1) Rated pressure range, output, valve type and function Supply valve: N.C. 0 to -101 kPa Supply valve: N.O. IO-Link, Supply valve: N.C.
-
Page 14: Summary Of Product Parts
Summary of Product parts ZK2□A,ZB,ZL3/ZL6 ZQ□A Output LED for release valve (Green): LED is ON when the switch output OUT1 (connected to release valve) is ON. Output LED for supply valve (Red) : LED is ON when the switch output OUT2 (connected to supply valve) is ON. -
Page 15: Wiring
Wiring ■Wiring ○Connection •Connections should only be made with the power supply turned off. •Use separate routes for the Pressure switch wiring and any power or high voltage wiring. Otherwise, malfunction may result due to noise. •Ensure that the FG terminal is connected to ground when using a commercially available switch-mode power supply. -
Page 16: Internal Circuit And Wiring Example
ZK2□A Pin assignment for valve connector Pin assignment for valve connector (‘VAC’ is marked on the supply valve lead wire) ZL3/ZL6, ZQ□A Pin assignment for valve connector (‘VAC’ is marked on the supply valve lead wire) ■Internal circuit and wiring example •... -
Page 17: Mounting And Installation
Mounting and Installation ■Installation • ZK2□A, ZB, ZL3/ZL6 Mount the O-ring provided into the O-ring groove of the pressure switch, and mount the pressure switch to the ejector body with the mounting screws provided. Exceeding the recommended tightening torque can damage or break the mounting part. Tightening torque: 0.08 to 0.10 Nm Tightening torque: 0.078 to 0.098 Nm In the case of ZL3/ZL6, mount the pressure switch with valve plate assembly to the ejector body. -
Page 18: Io-Link Specifications
IO-Link Specifications ■Outline of the IO-Link functions ○Communication function This product can check the pressure measurement value, diagnostic information and output status for valves using cyclic data communication via the IO-Link system. ○Product status monitoring function This function monitors the product status via the IO-Link communication. •Detects the error status (internal hardware error, short circuit for valve output) •Detects the warning conditions (product internal temperature error, measurement pressure error). -
Page 19: Process Data
■Process data Process data is the data which is exchanged periodically between the master and device. Process data size is occupied as follows. Input process data Output process data 4 byte 2 byte The process data of this product is Big-Endian type. When the transmission method of the upper communication is Little-Endian, the byte order will be changed. - Page 20 Pressure measurement value •Pressure Range: 0 to -101[kPa] • Pressure Range: 100 to -100[kPa] Pressure display Pressure display Bit 31-16 (Dec) Bit 31-16 (Dec) value[kPa] value[kPa] (unused) (unused) 0x1068 (4200) -105 0x1068 (4200) -105 0x1064 (4196) -104.9 0x1064 (4196) -104.9 …...
- Page 21 ○Unit specification and pressure measurement value Pressure range Unit Rated pressure range Display/setting range Min. setting unit 0.00 -0.101 0.010 -0.105 0.001 -101.0 10.0 -105.0 kgf/cm 0.000 -1.030 0.102 -1.071 0.001 0.000 -1.010 0.100 -1.050 0.001 0.00 -14.65 1.45 -15.23 0.01 0 to -101[kPa] inchHg...
- Page 22 ○Conversion formula of the process data and pressure measurement value (1) Conversion formula from the process data to the pressure measurement value: Pr = a × (PD) + b (2) Conversion formula from the pressure measurement value to the process data: (PD) = (Pr –...
-
Page 23: Io-Link Parameter Setting
■IO-Link parameter setting ○IODD file IODD (I/O Device Description) is a definition file which provides all properties and parameters required for establishing functions and communication of the device. IODD includes the main IODD file and a set of image files such as vendor logo, device picture and device icon. - Page 24 ●ISDU parameters Index Sub index Access Parameters Default value Remarks (Dec) 0x0002 Refer to "System command" on System command page 23 0x000C Refer to "Device access lock Device access lock 0x0000 (12) parameter" on page 24 0x0010 Vender name SMC Corporation (16) 0x0011 Vender text...
- Page 25 ●Device access lock parameters (Index 12) The contents are as follows. Data type: 16 bit Record Value (Dec) Contents 0x0000(0) Key lock release, Data storage unlock (Default value) 0x0002(2) Key lock release, Data storage lock 0x0008(8) Key lock, Data storage unlock 0x000A(10) Key lock, Data storage lock [Key lock]...
- Page 26 ●Product individual parameters Data Index (dec) Access Parameter Data symbol (byte) index Storage 0x03E8 (1000) Unit (Display unit) U8 (1) 0x0708 (1800) FiL (Digital filter) U16 (2) 0x0712 (1810) FSC (Display fine adjustment) S16 (2) 0x07DA (2010) drE (Display resolution) U8 (1) 0x07EE (2030) Cut (Zero cut-off)
- Page 27 ●Detailed product individual parameters [F0] Unit (Display unit parameter) (Index 1000) Default value Sub index Data type Access Description (dec) Setting of display unit 0: MPa 1: kPa 0x01 2: kgf/cm 3: bar 4: psi 5: inHg 6: mmHg [F6] Fil (Digital filter parameter) (Index 1800) Default value Sub index Data type Access...
- Page 28 ●Detailed product individual parameters (continued) [F0] PoE (Output process data during communication error parameter) (Index 2310) Default value Sub index Data type Access Description (dec) Setting of output process data during IO-Link communication error. 0x00 0: off 1: hold [F80] ECo (Power saving mode parameter) (Index 2400) Default value Sub index Data type Access...
- Page 29 ●Detailed product individual parameters (continued) [F0] CHA (Valve protection parameter) (Index 4020) Default value Sub index Data type Access Description (dec) Setting of Enable/Disable valve protection function and its number of times. Refer to "example of ejector operation". The valve protection function is described below. 0x0000 When the valve has switched ON/OFF a set number of times during operation of energy saving function, the energy saving will turn off, and continuous absorption will...
- Page 30 ●Detailed product individual parameters (continued) [F2] P2 setting (Energy saving pressure/hysteresis parameter) (Index 4210) Default value Sub index Data type Access Description (dec) Setting of P2 energy saving confirmation threshold. Refer to "example of ejector 0x0BB8 operation". (3000) Setting range: 4 to 4200 (-0.1 to -105[kPa]) -75[kPa] Conditions with other parameters: P1+H2≦P2≦4200 Setting of H2 energy saving confirmation hysteresis.
- Page 31 ●Detailed product individual parameters (continued) [F5] P5 setting (P5 pressure confirmation parameter) (Index 4240) Default value Sub index Data type Access Description (dec) Setting of P5L pressure confirmation lower threshold. Refer to "example of ejector 0xFF60 operation". (-160) Setting range (Normal): -4200+H5L to P5H 4[kPa] Setting range (Reversed): -4200 to P5H-(H5L or H5H)* *Use greater value...
- Page 32 ●Detailed product individual parameters (continued) Gradient (Process data conversion formula Gradient) (Index 8000) Default Sub index Data type Access Description value (dec) Responds to the current gradient value. Refer to Conversion formula of the process data and pressure measurement value on page 21.
-
Page 33: Example Of Ejector Operation
Example of Ejector Operation ■Example ○Energy saving operation (Supply valve: N.C.) (1) The vacuum instruction turns on (0 to 1). (2) The supply valve is automatically OFF (not-energized) when the vacuum pressure reaches P2. (3) When the vacuum pressure drops by P2-H2, the supply valve is automatically ON (energized) again. (4) Repeat steps (2) and (3) unless the valve protection function is activated. - Page 34 ○Energy saving operation (Supply valve: N.O.) (1) The vacuum instruction turns off (1 to 0). (2) The supply valve is automatically ON (energized) when the vacuum pressure reaches P2. (3) When the vacuum pressure drops by P2-H2, the supply valve is automatically OFF (not-energized) again. (4) Repeat steps (2) and (3) unless the valve protection function is activated.
- Page 35 ○Valve protection operation When the valve has switched ON/OFF a set number of times during operation of energy saving function, the energy saving will turn off, and continuous absorption will resume. Diagnostic information is then issued. *The graph is supply valve: N.C. type. *The energy saving control can not be used for ZB series.
- Page 36 ○Automatic release valve operation The release pressure can be used without instructing release instruction bit. (1) The vacuum instruction turns on (0 to 1). (2) The workpiece is moved to the release position, and then the vacuum instruction turns off (1 to 0). (3) After delay time, the release valve is ON.
- Page 37 ○Pressure confirmation (P4, P5) When the output logic is normal, the pressure confirmation bit set to 1 within the confirmation pressure range. When the output logic is reversed, the pressure confirmation bit set to 1 outside of the pressure confirmation range. The output logic can be set in the P4/P5 output logic parameter. -36- Doc.
- Page 38 ○IO-Link indicator light operation and display Communication Status Display Content with master Normal communication status (Reading of measurement value, [oPE] [measured value] instruction) Output process data: Available Operate Normal communication status Correct (Reading of measurement value) [idLE] [measured value] Output process data: Not available [Str] ...
-
Page 39: Setting
Setting ■Setting by buttons ● Measurement mode The measurement mode is the condition where the pressure is detected and indicated, and the switch function is operating. This is the basic mode, and other modes should be selected for setting changes and other function settings. ●... - Page 40 <How to change the set value by buttons> (1) Press the button once in measurement mode. (Refer to page 38) (2) “P1" and the set value are displayed in turn. (3) Press the button to change the set value. button is to increase vacuum pressure and the button is to decrease.
- Page 41 button to complete the setting of “H2”. The display shows [P3] and the set value in turn. (7) Press the button is to increase and the button is to decrease the set value. button to complete the setting of “P3”. The display shows [H3] and the set value in turn. (8) Press the button is to increase and the button is to decrease the set value.
- Page 42 button to complete the setting of “H4L”. The display shows [H4H] and the set value in turn. (14) Press the button is to increase and the button is to decrease the set value. button to complete the setting of “H4H”. The display shows [P5L] and the set value in turn. (15) Press the button is to increase and the button is to decrease the set value.
-
Page 43: Default Setting
<How to change the functions by buttons> ■Default setting The default settings are as follows, •[F 0] Display unit/ Energy saving control/ Valve protection/ Output priority/ Output process data during communication error See page Item Description Default setting Display unit Setting of display unit. - Page 44 •[F 4] Setting of P4 confirmation pressure/hysteresis See page Item Description Default setting Output logic(P4) Setting of P4 output logic. Normal Pressure(P4L) Setting of P4L pressure confirmation lower threshold. 4 kPa Pressure(P4H) Setting of P4H pressure confirmation upper threshold. -4 kPa Setting of H4L pressure confirmation lower hysteresis.
-
Page 45: F0 Display Units, Energy Saving, Valve Protection, Output Priority, Communication Error
■[F 0] Display unit/ Energy saving control/ Valve protection/ Output priority/ Output process data during communication error <Operation> Press the button in function selection mode to display [F 0]. Press the button. Move on to select the display unit. Selection of the display unit Press the button to select the display unit. - Page 46 Setting of output priority Press the button to select the output priority. Press the button to set. Move on to select the output process data during communication error. Setting of output process data during communication error Press the button to select the output process data during communication error.
-
Page 47: F1 Vacuum Pressure/Hysteresis
■[F 1] Setting of vacuum confirmation pressure/hysteresis The output of P1 can be set. <Operation> Press the button in function selection mode to display [F 1]. Press the button to set. Move on to setting of pressure. Setting of pressure Press the button to adjust pressure setting. -
Page 48: F2 Energy Saving Pressure/Hysteresis
■[F 2] Setting of energy saving confirmation pressure/hysteresis The output of P2 can be set. <Operation> Press the button in function selection mode to display [F 2]. Press the button to set. Move on to setting of pressure. Setting of pressure Press the button to adjust pressure setting. -
Page 49: F3 Release Pressure/Hysteresis And Automatic Release Valve
■[F 3] Setting of release confirmation pressure/hysteresis The output of P3 can be set. <Operation> Press the button in function selection mode to display [F 3]. Press the button. Move on to setting of pressure. Setting of pressure Press the button to adjust pressure setting. -
Page 50: F4 P4 Setting (P4 Confirmation Pressure/Hysteresis And Output Logic)
■[F 4] Setting of P4 confirmation pressure/hysteresis The output of P4 can be set. <Operation> Press the button in function selection mode to display [F 4]. Press the button. Move on to setting of output logic. Setting of output logic Press the button to select the output logic. -
Page 51: F5 P5 Setting (P5 Confirmation Pressure/Hysteresis And Output Logic)
■[F 5] Setting of P5 confirmation pressure/hysteresis The output of P5 can be set. <Operation> Press the button in function selection mode to display [F 5]. Press the button. Move on to setting of output logic. Setting of output logic Press the button to select the output logic. -
Page 52: F6 Digital Filter
■[F 6] Digital filter The digital filter can be selected to filter the pressure measurement. Output chattering or flicker in the measurement mode display can be reduced by setting the digital filter. Digital filter can be set in 0.01[sec] increment in the range of 0.00 to 10.00 sec. <Operation>... -
Page 53: F7 Auto Preset
■[F 7] Auto preset This function calculates and sets the pressure values automatically based on the on-going operation. <Operation> Press the button in function selection mode to display [F 7]. Press the button. Move on to setting of auto-preset function. Auto preset setting Press the button to select auto-preset. - Page 54 •Auto preset When auto preset is selected in function selection mode, the set value can be calculated and memorized from the measured pressure. Repeating the suction and release of a workpiece several times automatically optimizes the set value. 1, Selection of auto preset P1 Press the button in measurement mode to display "AP1".
-
Page 55: F8 Fine Adjustment Of Display Value
■[F 8] Fine adjustment of display value This function is used to manually perform fine adjustment of the displayed pressure. It is adjustable within the range 5% R.D. ± <Operation> Press the button in function selection mode to display [F 8]. Press the button. -
Page 56: F11 Display Resolution
■[F11] Display resolution This function is used to change the pressure display resolution. This can be used to prevent the digits from flickering on the display. <Operation> Press the button in function selection mode to display [F11]. Press the button. Move on to display resolution setting. -
Page 57: F14 Zero Cut-Off
■[F14] Zero cut-off When the pressure display value is close to zero, the product rounds the value and zero will be displayed. The zero cut-off range is 0.0 to 10.0% F.S., and can be set in 1.0% F.S. increments. <Operation> Press the button in function selection mode to display [F14]. -
Page 58: F80 Power Saving Mode
■[F80] Power saving mode Power saving mode is selectable. When selected and no buttons are pressed for 30 seconds, the pressure switch will shift to power saving mode. The default setting is normal mode (power saving mode off). <Operation> Press the button in function selection mode to display [F80]. -
Page 59: F81 Security Code
■[F81] Security code A security code can be selected, which must be entered to unlock the keys when the keys are locked. In the default setting, entry of a security code number is not required. <Operation> Press the button in function selection mode to display [F81]. Press the button. - Page 60 •How to entry the security code The left most digit starts flashing. Press the button to change the value. Press the button to make the next digit to the right flash. (If the button is pressed when the last digit is flashing, the left most digit starts flashing again).
-
Page 61: F90 Setting Of All Functions
■[F90] Setting of all functions All functions can be set, one after the other. <Operation> Press the button in function selection mode to display [F90]. Press the button. Move on to setting of all functions. Setting of All functions Press the button to select all functions. - Page 62 •Order of function of setting Order Function Display unit/ Energy saving control/ Valve protection/ Output priority/ Output process data during communication error Setting of vacuum confirmation pressure/hysteresis Setting of energy saving confirmation pressure/hysteresis Setting of release confirmation pressure/hysteresis Setting of P4 confirmation pressure/hysteresis Setting of P5 confirmation pressure/hysteresis Digital filter Auto preset...
-
Page 63: F91 Device Id And Number Of Pressurizing Errors
■[F91] Device ID / Number of pressurizing errors Device ID can be displayed. When the pressure has exceeded 115% of the rated pressure, this is counted as a pressurizing error. <Operation> Press the button in function selection mode to display [F91]. Press the button. -
Page 64: F96 Output Process Data Check
■[F96] Output process data / Actual cycle time / Setting cycle time The status of the output process data and the cycle time of IO-Link can be displayed. <Operation> Press the button in function selection mode to display [F96]. Press the button. -
Page 65: F98 Input Process Data Check
■[F98] Input process data The status of the input process data and the switch output connected to the valves can be confirmed. The status and outputs can be turned ON/OFF manually. <Operation> Press the button in function selection mode to display [F98]. Press the button. - Page 66 Press the button for 2 seconds or longer. Press the button to set. Measurement Mode Input process data check (via IO-Link communication) Press the button to select input process data check. P1(vacuum confirmation) : ON/OFF P2(energy saving confirmation) : ON/OFF P3(release confirmation) : ON/OFF P4(pressure confirmation)
-
Page 67: F99 Reset To The Default Setting
■[F99] Reset to the default setting If the setting of the pressure switch becomes unknown, the default setting can be restored. <Operation> Press the button in function selection mode to display [F 99]. Press the button. Move on to reset to the default setting. Reset to the default setting Set the display [ON] by pressing the button,... -
Page 68: Other Settings
Other Settings ○Peak/Bottom hold value display The maximum (minimum) vacuum pressure from when the power was supplied to this moment is detected and updated. For peak display, when the button is pressed for 1 second or longer, the maximum vacuum pressure and "Hi"... - Page 69 <Operation -With security code-> •Locking 1, Press and hold the button for 5 seconds or longer in measurement mode. [UnL] is displayed. 2, Press the button to select locking of the keys [LoC]. 3, Press the button to enter the setting. •Unlocking 1, Press and hold the button for 5 seconds or longer in measurement mode.
-
Page 70: Maintenance
Maintenance How to reset the product for power cut or forcible de-energizing The setting of the product will be retained as it was before a power cut or de-energizing. The output condition is also recovered to that before a power cut or de-energizing, but may change depending on the operating environment. -
Page 71: Troubleshooting
Troubleshooting • Troubleshooting Applicable Pressure switch: ZK2-ZS□L1/L2□□□-A, ZB1-ZS□L□□-A, ZL3-VP□-1-□L□□-A, ZQ-ZS□L1/L2□□□-□-A If an operational failure of the pressure switch occurs, please select the cause of failure from the flow chart below. If a cause applicable to the failure cannot be identified and normal operation can be recovered by replacement with a new pressure switch, this indicates that the pressure switch itself was faulty. - Page 72 The display The display is not Refer to fluctuates normal reference No.7 The display Refer to disappears reference No.8 The display Refer to breaks off reference No.8 The display Refer to flashes reference No.9 Pressure display difference when using Refer to 2 or more Pressure reference No.10 switches...
- Page 73 • Cross-reference for troubleshooting Error Problem Possible cause Investigation method Countermeasure •Output remains (1) Reset the pressure (1) Check the set pressure value. Indication LED Incorrect pressure settings. (2) Check the settings of the remains ON. setting (2) Reset the function •Output remains hysteresis and output type.
- Page 74 Error Problem Possible cause Investigation method Countermeasure (1)，(2) Connect the (1) Check if the output current is 80 mA or more. appropriate load. (2) Check if the specified load is (3) Use a relay with a surge connected. voltage suppressor or Over current to the (3) Check if a relay without a surge take measures to...
- Page 75 Error Problem Possible cause Investigation method Countermeasure Incorrect power Check if the power supply voltage is in Supply power supply supply the range 24 VDC ±10%. voltage of 24 VDC ±10%. •The display turns OFF. Check the power supply wiring. Incorrect wiring Correct the wiring.
- Page 76 Error Problem Possible cause Investigation method Countermeasure "-M" in the part number means that the measurement unit cannot Improper model be changed. selection Check if there is a "-M" at the end of (kPa or MPa can be (Selection of The display units the part number printed on the selected.)
- Page 77 ■Error Indication This function is to display error location and content when a problem or an error occurs. Error Name Error Display Error Type Troubleshooting Method Turn the power off and remove the The switch output load current is more Over current Error cause of the over current.
-
Page 78: Specifications
Specification ■Specifications Fruid Rated pressure range 0 to -101 kPa 100 to -100 kPa Set pressure range 10 to -105 kPa 105 to -105 kPa Proof pressure 500 kPa Min. setting unit 0.1 kPa 24 VDC ±10%, Ripple(P-P) 10% or less Power supply voltage (Protected against reverse connection) Current consumption... - Page 79 Revision history First Edition: - [Sep 2023] 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
