- Page 1 AC WELDING TRANSFORMER WT-A56241-220 OPERATION MANUAL Z06OM1162064-04...
-
Page 2: Table Of Contents
WT-A56241-220 Thank you for purchasing our AC Welding Transformer WT-A56241-220. Before using this Transformer, read this operation manual carefully until you have familiarized yourself with it. After reading save the manual in place where operators can refer to it at any time. -
Page 3: Special Precautions
WT-A56241-220 1. Special Precautions (1) Safety Precautions CAUTION ！ Before using, read "Safety Precautions" carefully to understand the correct method Denotes operations and practices that of use. may result in personal injury or damage to the equipment if not correctly followed. - Page 4 WT-A56241-220 WARNING ！ Do not put your hands between the electrodes When welding, keep your fingers and hands away from the electrodes. Do not touch +/- terminal, secondary cable, any welded part or electrodes during welding and just after welding finished These parts are very hot.
- Page 5 WT-A56241-220 CAUTION ！ Do not splash water on the Welding Transformer Water splashed over the electric parts can cause electric shock and short circuits. Use proper tools (wire strippers, pressure wire connectors, etc) for termination of the connecting cables Do not cut the conductor of wire. A flaw on it can cause fire and electric shock.
-
Page 6: Precautions For Handling
WT-A56241-220 (2) Precautions for Handling When transporting or moving the Transformer, do not lay it down. Also, handle the Transformer with care so as not to make an impact such as drop on it. Moving the Transformer by hand must be done by at least two people. -
Page 7: Shipping Kit
WT-A56241-220 (4) Shipping Kit Verify that contents of the container agree with the kit list. If you see any damage, please contact us. Packaged Kit Quantity WT-A56241-220 Operation manual 1. Special Precautions... -
Page 8: Outline Drawing And Specifications
WT-A56241-220 2. Outline Drawing and Specifications (1) Outline Drawing 2. Outline Drawing and Specifications... -
Page 9: Specifications
WT-A56241-220 (2) Specifications Model name WT-A56241-220 Rated capacity 56 kVA Rated voltage 220 V/50 Hz Max. capacity 145 kVA No-load secondary 9.1 V voltage Max. output current 16 kA Max. duty cycle 7.5% (at 16 kA) Temperature +5°–+45°C, Humidity 90% or less (Dew...
