Toro 132-4164 Installation Instructions

Cab Hardware Improvement Kit
4045 Directional Drill with Cab
Model No. 132-4164
WARNING
CALIFORNIA
Proposition 65 Warning
This product contains a chemical or chemicals
known to the State of California to cause cancer,
birth defects, or reproductive harm.
Installing the Hardware
1. Move the machine to a level surface, turn off the
machine, and remove the key.
Note: Swing the operator platform fully out for easier
access; refer to the machine Operator's Manual.
2. Remove the hardware on the cab and replace it with
the bolts noted in Figure 1
included in this kit.
Torque the bolts to 2.52 N-m (1.88 ft-lbs).
Front View
1. Bolts (M4-0.07 x 16 inch)
© 2015—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
and Figure 2 and the nuts
Figure 1
Register at www.Toro.com.
Figure 2
1. Bolts (M4-0.07 x 16 mm)
2. Bolts (M4-0.07 x 20 mm)
Original Instructions (EN) All Rights Reserved *3395-913* A
Printed in the USA
Form No. 3395-913 Rev A
Installation Instructions
3. Bolts (M4-0.07 x 12 mm)
