Network Configuration section on page 28.
If you are unable to find the unit in the list of devices, it is possible that a network setting (such
as subnet mask) may be different, the unit may be connected to a different network, or the unit
may not be powered on. SSi recommends consulting an IT engineer or network administrator.
If needed, call SSi at (513) 772-0060.

Touch Screen Interface

Main Screen

The Main screen shows the current percentage of CO
screen or the Chart screen.

Menu Screen

Super Systems Inc.
Single Gas Analyzer (SGA)
Operations Manual
. From here the user can enter the Menu
2
Page 10 of 37
