Model:LM-500/750
LF-500/750
User's Manual
2020
www.rattanebike.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM-750 and is the answer not in the manual?

Questions and answers

Armando Fernandez
March 11, 2025

I need a replacement battery

User image 67d045b0c9624
1 comments:
Mr. Anderson
March 11, 2025

You can contact Rattan eBike for a replacement battery through their official email at info@rattanebike.com (Official Store) or reibokservice@gmail.com (Amazon Store). You may also call their service hotline at +1 909-319-0013.

This answer is automatically generated

Summary of Contents for RATTAN LM-750

  • Page 1 Model:LM-500/750 LF-500/750 User’s Manual 2020 www.rattanebike.com...
  • Page 2: Table Of Contents

    CONTENTS Part 1 Main Parts Introduction (page 1) Part 2 Assembly Instructions (page 2-3) Part 3 The Correct Usage of Main Accessories (page 4-5) Part 4 Check Before Riding (page 6) Part 5 Riding Guidance (page 7-8) Part 6 Adjustment of Main Parts and Components (page 9-19) Part 7 Handling of Abnormal Ebike Conditions...
  • Page 3: Part 1 Main Parts Introduction

    Part 1 Main Parts Introduction 1. Handlebar 13. Battery 2. Quick Release 14. Folder 3. Head Tube Clamp 15. Crank Set 4. Front Led light 16. Peddle 5. Suspension Front Fork 17. Crank 6. Valve 18. Kickstand 7. Fender 19. Rear Saddle 8.
  • Page 4: Part 2 Assembly Instructions

    Part 2 Assembly Instructions  Unboxing  Unfold and lock the ebike...
  • Page 5  Assemble the rear pedals  Power on the battery before turn on the display Click our Website (www.rattanebike.com) or the find the video on YouTube.
  • Page 6 Part 3 How to use the part correctly Battery and Charger Make sure the charger is pressed to the end of charging connector when charging.  Fully charge the battery for each ride to extend the life of battery  Charger light in red means charging, charger light in green means fully charged.
  • Page 7  Two ways for charging: 1. Charge the Ebike without removing the battery 2. Remove the battery, and charge it.  Turn off the display and keep the key at power off position w hen charge the Ebike without removing the .
  • Page 8: Part 4 Check Before Riding

    Part 4 Check before riding  Make sure all components are tightened. Adjust the height of the handlebar and the seat post. DO NOT raise it above the safety line.  Make sure the brakes can cut off the power supply to the motor, and whether it is sensitive and reliable.
  • Page 9: Part 5 Riding Guidance

    Part 5 Riding Guidance  The electric bike has three riding modes:Pedal Mode, Electric Mode, and Pedal Assist Mode:  Pedal Mode: This mode does not require any power. It allows the E-bike to work as other regular bike. You will be automatically switched to this mode when the battery dies while riding ...
  • Page 10  Always wear a helmet that meets the standards and make sure having the necessary protection to ensure the safety when riding the ebike,  Turn on the headlight when riding at night. Use the headlight for a long time will consume part of the electric energy and reduce the mileage.
  • Page 11: Part 6 Adjustment Of Main Parts And

    Part 6 Adjustment of main parts and components Display Instruction (MODEL: LCD-YL80C) Appearance Dimensions ...
  • Page 12  Function Overview YL80C display provides a variety of functions to meet your riding needs, including: Electricity display  Motor power indication  Boost gear adjustment and indication  Speed display (including real-time speed, maximum  speed and average speed) Mileage display (including single mileage and total ...
  • Page 13  Button Definition There are five buttons on the corresponding operation unit of YL80C instrument, of which the buttons replaced by the words "UP" and "DOWN" respectively in the following instructions.  General Operations Press the button for few seconds to turn on/off the display and controller.
  • Page 14 Display Interface Switch  Electric Assistance Pushing Mode Keep pressing the DOWN button, and the ebike will enter the electric assistance pushing mode. The ebike will run at a constant speed of 6 km/h. At the same time, the screen shows Release the DOWN button and the electric bike will immediately power off.
  • Page 15  Turn the Backlight On/Off Press the headlight button briefly to turn on the taillight and the controller will turn on the headlight at the same time when the environment light is dark or driving at night. Press the headlight button again,the display taillight turns light and the controller off.
  • Page 16  Motor Power Indication The output power of the motor can be known through the display.  Error Code Display The display will automatically show the error code When the electric control system is not working. See the table for the definition of the detailed error code.
  • Page 17  General Settings Press the key for a few seconds to start the display. In the start up state, when the ebike is stationary, press the UP + DOWN button over 2 seconds. The display will access the display setting. ...
  • Page 18  Conversion of Imperial and Metric Units U for units, 1 for imperial system and 2 for metric system. The default unit of the instrument is metric.  Password Settings Press the "i" key to set the password, and the screen shows "P2" to indicate the password.
  • Page 19  Password Switch Setting Y indicates password required; N indicates password not required. Select Y and press the "i" key to enter the password modification. Select N and exit the password setting. Default setting is N.  Password Modification Press the UP/DOWN to switch the number.
  • Page 20 setting; press the DOWN more than 2 seconds to cancel the operation and exit the setting. The display will exit the setting automatically if there’s no operation input in one minute. The adjustment of the handlebar Adjust the handlebar to a suitable riding height.
  • Page 21 noise or brake stuck when braking). Adjust the brake pad to keep the rotor in the middle position. Tighten the screws after each adjustment. The adjustment of the derailleur Adjust the screw on the shifting wire when it is hard to switch the shifter. Loose screw 1 slightly when the shifter can`t switch to the 8th gear;...
  • Page 22 Part 7 Common problems and solutions  The battery cannot be charged, the display shows an abnormal battery power.  Use a multimeter to check if the battery still have voltage.  Check if the charger indicator is normal. (Red light means charging, green light means fully charged) ...
  • Page 23  When an error code appears on the display. Error Code Definition Current Abnormality Throttle Abnormality Motor Abnormality Motor Hall Signal Abnormality Brake Abnormality Communication Abnormality  Error code 21 and 30 indicates controller problem.  Error code 25 indicates brake problem. Do following steps to make sure which brake is defective: ...
  • Page 24  Can I do some upgrades of the bike?  We provide upgrade service for some accessories. Contact Rattan for more details.  I need to return the bike, what should I do? We only accept returns with original package. Any returns...
  • Page 25: Part 8 Use And Maintenance

    Part 8 Use and Maintenance  Battery Maintenance  Fully charge the battery for the first use.  Do not use the battery in low power level.  Must use the specified charger for charging.  Do not charge the battery at high temperature (over 212 Fahrenheit/100°C).
  • Page 26  Clean the brake regularly.  Motor Maintenance  Do not try to disassemble the motor.  If there is any problems with the motor, contact Rattan with a video.  Tire Maintenance  Check regularly to prevent air leak.
  • Page 27  Common failures and check Problem Possible reason Remedy 1. Battery voltage is too low. Make sure the battery is  The speed adjuster 2. Speed adjusting handle connection fully charged doesn’t work or the becomes loosed. Disconnect and  maximum speed 3.The spring is stuck.
  • Page 28: Part 9 After Sales And Warranty

    Part 9 After sales and Warranty  After sales Thanks for choosing Rattan Ebike as your green travel solution. Let’s ride together to keep our earth and home green. If you have any questions about our products, or would like to get the latest news, deals from us, please...
  • Page 29  Warranty The main parts of the warranty provisions Warranty Depreciation Component Performance failure Remark period rate /day Natural sealing  Except Front fork off. 1year 0.2% damaged handle bar Fracture key  caused by riders parts crack.. Internal gear ...
  • Page 30  Common Part Warranty Warranty Depreciation Performance Component Remark period rate/day failure Switch 1year 0.1% Not work Skid, fracture Freewheel/chain 1year 0.1% freewheel stagnation Crank 1year 0.1% Not work Except damaged Expansion brake 1year 0.1% Not work caused by rider Throttle 1year 0.1%...
  • Page 31 Rattan, that have been made to your product. We will not be responsible for any damage to the product that occurs during the repair process that is a result of any unauthorized modifications or repairs or replacements not performed by Rattan.
  • Page 32 2. Any unauthorized modification to the product, such as disassemble the bike without direction by Rattan, faulty installation, repair, or maintenance by anyone other than Rattan.
  • Page 33 In most cases, we do not require you send the defective parts back to us. If applicable law requires Rattan to return a replaced item to you, you agree to pay Rattan the retail cost of the replacement item and shipping.  Do-It-Yourself (DIY) Parts Service.
  • Page 34 *Note: We DO NOT accept return of the bike except any unsolvable quality problem and we don’t accept return of the bike for personal reason. If you have any problems with the product, please contact us at info@rattanebike.com. Our dedicated customer support will be more than happy to assisting you.
