- Page 1 EN User Manual | Oven EOF4P56X...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 4: Safety Instructions
similar accommodation where such use does not exceed (average) domestic usage levels. • Only a qualified person must install this appliance and replace the cable. • Do not use the appliance before installing it in the built-in structure. • Disconnect the appliance from the power supply before carrying out any maintenance. - Page 5 • Before mounting the appliance, check if • Make sure not to cause damage to the the appliance door opens without restraint. mains plug and to the mains cable. Should • The appliance is equipped with an electric the mains cable need to be replaced, this cooling system.
- Page 6 The earth cord (green / yellow cable) must be • Discoloration of the enamel or stainless 2 cm longer than the brown phase and blue steel has no effect on the performance of neutral cables. the appliance. • Use a deep pan for moist cakes. Fruit 2.3 Use juices cause stains that can be permanent.
-
Page 7: Installation
– any excess food residues, oil or • Concerning the lamp(s) inside this product grease spills / deposits. and spare part lamps sold separately: – any removable objects (including These lamps are intended to withstand shelves, side rails, etc., provided with extreme physical conditions in household the appliance) especially any non-stick appliances, such as temperature,... - Page 8 3.1 Building in www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux Oven - Column installation (*mm) min. 550 min. 560 (*mm) min. 550 min. 560 ENGLISH...
-
Page 9: Product Description
3.2 Securing the oven to the cabinet 4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knob for the heating functions Display Control knob Heating element Lamp Shelf support, removable Shelf positions 4.2 Accessories To bake and roast or as pan to collect fat. •... -
Page 10: Before First Use
functions to the off position to turn the appliance off. Timer Fast Heat Up Light Lock Confirm setting 5.3 Display Display with key functions. Display indicators Basic indicators Lock Assisted Cooking Cleaning Settings Fast Heat Up Timer indicators Minute minder Time Delay Uptimer End time... -
Page 11: Daily Use
Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h. Step 3 Set the maximum temperature for the function: Let the oven operate for 15 min. The oven can emit an odour and smoke during preheating. - Page 12 Heating function Application To defrost food (vegetables and fruit). The defrosting time depends on the amount and size of the frozen food. Defrost This function is designed to save energy during cooking. When you use this function, the temperature in the cavity may differ from the set temperature. The residual heat is used.
- Page 13 7.5 Assisted Cooking Legend Legend Shelf level. Weight Automatic available. The display shows P and a number of the dish that you can check in the table. Preheat the appliance before you start cooking. Dish Weight Shelf level / Accessory Roast Beef, rare 2;...
- Page 14 Dish Weight Shelf level / Accessory Spare Ribs 2 - 3 kg; use raw, 2 3; deep pan - 3 cm thin spare Add liquid to cover the bottom of a dish. Turn the meat af‐ ribs ter half of the cooking time. Lamb leg with bones 1.5 - 2 kg;...
-
Page 15: Clock Functions
Dish Weight Shelf level / Accessory Loaf cake 2; loaf pan on wire shelf Baked potatoes 1 kg 2; baking tray Put the whole potatoes with skin on baking tray. Wedges 1 kg 3; baking tray lined with baking paper Use your favourite spices. - Page 16 Clock Function Application Maximum is 23 h 59 min. This function has no effect on the operation of the oven. To turn on and off the Uptimer select: Menu, Settings. Uptimer 8.2 How to set: Clock functions How to set: Time of day Step 1 Step 2 Step 3...
-
Page 17: Using The Accessories
How to set: Time Delay Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 The dis‐ play The display shows: the shows: time of day --:-- STOP Select the Press repeat‐ START Set the start Set the end heating Press: Press:... -
Page 18: Additional Functions
10. ADDITIONAL FUNCTIONS 10.1 Lock This function prevents an accidental change of the appliance function. Turn it on when the appliance works - the set cooking continues, the control panel is locked. Turn it on when the appliance is off - it cannot be turned on, the control panel is locked. - press and hold to turn on the - press and hold to turn it off. - Page 19 (°C) (min) Sweet rolls, 16 pieces baking tray or dripping pan 20 - 30 Rolls, 9 pieces baking tray or dripping pan 30 - 40 Pizza, frozen, 0.35 kg wire shelf 10 - 15 Swiss Roll baking tray or dripping pan 25 - 35 Brownie baking tray or dripping pan...
- Page 20 Ramekins Pizza pan Baking dish Flan base tin Ceramic Dark, non-reflective Dark, non-reflective Dark, non-reflective 8 cm diameter, 5 28 cm diameter 26 cm diameter 28 cm diameter cm height 11.4 Cooking tables for test institutes Information for test institutes Tests according to IEC 60350-1.
-
Page 21: Care And Cleaning
( °C) (min) Fatless True Fan Wire shelf 2 and 4 40 - 60 Preheat the oven for sponge Cooking 10 min. cake, cake mould Ø26 Short bread True Fan Baking tray 140 - 150 20 - 40 Cooking Short bread True Fan Baking tray 2 and 4 140 - 150... - Page 22 Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects. Accessories 12.2 How to remove: Shelf supports Remove the shelf supports to clean the oven.
- Page 23 Pyrolytic Cleaning C2 - Normal cleaning 1 h 30 min C3 - Thorough cleaning 2 h 30 min Step 2 - press to select the cleaning programme. Step 3 - press to start the cleaning. Step 4 After cleaning, turn the knob for the heating functions to the off position. When the cleaning starts, the oven door is locked and the lamp is off.
- Page 24 Step 2 Lift and pull the latches until they click. Step 3 Close the oven door halfway to the first opening position. Then lift and pull to remove the door from its seat. Step 4 Put the door on a soft cloth on a stable sur‐ face.
-
Page 25: Troubleshooting
Make sure that you put the glass panels (A and B) back in the correct sequence. Check for the symbol / printing on the side of the glass panel, each of the glass panels looks different to make the disassembly and assembly easier. - Page 26 13.1 What to do if... In any cases not included in this table please contact with an Authorised Service Centre. The appliance does not turn on or does not heat up Problem Check if... You cannot activate or operate the appliance. The appliance is correctly connected to an electrical supply.
-
Page 27: Energy Efficiency
14. ENERGY EFFICIENCY 14.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Electrolux Model identification EOF4P56X 949498213 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional mode 0.93 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.69 kWh/cycle... -
Page 28: Menu Structure
When you use this function the lamp turn on the lamp again but this action will automatically turns off after 30 sec. You may reduce the expected energy savings. 15. MENU STRUCTURE 15.1 Menu Step 1 Step 2 Step 3 Step 4 Step 5 Select the option... - Page 32 867369311-B-122023...
