Specifi cations
Product Specifi cations
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI DVI-D 24pin
DisplayPort DisplayPort Connector Digital RGB
VGA 15pin Mini D-sub
RGB/HV* 2 BNC (R,G,B,H,V)
HDMI HDMI Connector
2
DVD/HD* BNC X 3
VIDEO1 BNC
VIDEO2* 2 BNC
S-VIDEO Mini DIN 4 pin
Output Signal
DVI DVI-D 24pin
DisplayPort DisplayPort Connector Digital RGB
VIDEO1 BNC
AUDIO
AUDIO RCA (L/R)
Input STEREO Mini Jack X2
HDMI Connector
AUDIO STEREO Mini Jack
Output
Speaker Output
Control
Power Supply
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible mounting interface
Power Management
Plug & Play
Accessories
NOTE: Technical specifi cations are subject to change without notice.
70" /177.8 cm diagonal
Pixel Pitch: 0.807 mm
Resolution: 1920 x 1080
Color: Over 16 million colors (depending on video card used)
Brightness: 600 cd/m 2 (Max.), 420 cd/m
Contrast Ratio: 2000:1
Viewing Angle: 89° (typ) @ CR>10
Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
50.0 - 85.0 Hz
Vertical:
25.2 MHz - 162.0 MHz
1549.4 x 871.6 mm
Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
DisplayPort Complies with Standard V1.1a, applicable to HDCP V1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV HDMI
Digital RGB VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Digital RGB DVI (HDCP)
DisplayPort Complies with Standard V1.1a, applicable to HDCP V1.3
Composite 1.0 Vp-p with 75 ohm terminated
Analog Audio Stereo L/R 0.5 Vrms
Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10W + 10W
RS-232C In: 9 Pin D-sub
RS-232C Out: 9 Pin D-sub (with daisy chain)
LAN: RJ-45 10/100 BASE-T
Remote IN: Stereo Mini jack 3.5
Remote OUT: Stereo Mini jack 3.5
8.2 - 3.3 A @ 100-240VAC, 50/60Hz
Temperature: 5 - 40°C / 41 - 104°F (Default brightness), 5 - 20°C / 41 - 68°F (Max brightness)
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m (Brightness may decrease with altitude)
Temperature: -20 - 60°C / -4 - 140°F
Humidity: 10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
1680 (W) x 1004 (H) x 198 (D) mm / 66.1 (W) x 39.5 (H) x 7.8 (D) inches
94.5 Kg (208.3 lbs)
400 mm x 400 mm (M8, 4 Holes)
VESA DPM
VESA DDC2B, DDC/CI, DisplayPort
Setup manual, Power Cord, Video Signal cable, Remote Control, AA Battery x 2, Clamp,
Screw x 7, CD-ROM, Cable cover, Eyebolt (M12) x 2, Washer for eyebolt (M12) x 2
English-39
2 (Factory setting Typ.) @25°C
1 , 1920X1080 (60Hz), 1080p, 1080i
1 , 1920x1080 (60 Hz), 1080p, 720p
1 , 1920X1080 (60Hz)
1 , 1920X1080 (60Hz)
1
, 1920x1080 (60 Hz), 1080p, 1080i,
*1: Compressed image *2: Common terminal
