- Page 1 Sonoma 16 and 1216 Pergola Manual and Installation Instructions Please read these instructions before removing parts from crate...
- Page 2 Introduction Thank you for your purchase from The Outdoor GreatRoom Company. This pergola has been engineered and manufactured in the USA. This user manual will help make the installation and setup of your new pergola fast and easy. Outdoor GreatRoom company recommends visiting with your local authority for building codes, restrictions, or requirements for this product.
- Page 3 Included Parts: Arch Mending plate Foot Tall Corbel Short Corbel Post Brace Post Brace Col- ALL bolts require washers M10x 55 Hex Bolt (with nut and washers) M10 x160 Hex Bolt (with nut and wash- ers) Canopy Beam, T Canopy Beam, Right L Canopy Beam, Left L M10 x 90 Hex Bolt (with nut and wash-...
- Page 4 Step 2: Step 1: Step 3: Bolt steel footplate to each of four sup- plied posts “A” as shown. Use hardware “M”, and “O”. Apply construction adhesive to boards on one side and bolt beams together as shown using bolts “P” with a nut and washers. Bolt heads should be on the side comprised of beams Attach rectangular mending plates...
- Page 5 NOTE: In the remaining steps, a rubber mallet may be useful in fitting beams together properly. Step 5: Step 7: After end arched beams are Lay columns on level sur- Once header beams are installed, Tall Corbel Post face. Bolt ledger beams installed and bolts are Braces “B”...
- Page 6 Step 8: Carefully position posts in final location. Check for square. Install cano- py beam assemblies with screw “R” at inter- sections with arch beams. The use of a level or similar tool is highly suggested.
- Page 7 Dimensional and Post Location Information NOTE 1: Dimension Sonoma 16 (in) Sonoma 1216 (in) Recommended 12-18” DIA footing (12” mini- mum). Check local codes for depth minimums. Footing typically 24” minimum depth, 42” for ex- 151 1/2 treme cold climates.
- Page 8 The Outdoor GreatRoom Company. Any of the circumstances described in the previous sentence voids this warranty. This warranty is void if the Product or any component has been removed, repaired, or replaced before The Outdoor GreatRoom Company has been afforded a rea- sonable opportunity to inspect the Product.
