- Page 1 Sonoma 16 and 1216 Pergola Manual and Installation Instructions Please read these instructions before removing parts from crate...
- Page 2 Introduction Thank you for your purchase from The Outdoor GreatRoom Company. This pergola has been engineered and manufactured in the USA. This user manual will help make the installation and setup of your new pergola fast and easy. Outdoor GreatRoom company recommends visiting with your local authority for building codes, restrictions, or requirements for this product.
- Page 3 Included Parts: Arch Mending pl a te Foot Tall Corbel Post Short Corbel Post Brace Brace Col u mn ALL bolts require washers M10x 55 Hex Bol t (with nut and washers) M10 x160 Hex Bol t (with nut and washers) Canopy Beam, Ri g ht L Canopy Beam, T Canopy Beam, Left L...
- Page 4 Step 2: Step 1: Step 3: Bolt steel footpl a te to each of four suppli e d posts “A ” as shown. Use hardware “M”, and “O”. Apply construction adhesive to boards on one side and bolt beams together as shown using bolts “P”...
- Page 5 NOTE: In the remaining steps, a rubber mallet may be useful in fitting beams together properly. Step 5: Step 7: After end arched beams are in- Lay col u mns on l e vel surface. Once header beams are in- stall e d, Tall Corbel Post Braces Bol t l e dger beams assem- stall e d and bolts are ti g ht-...
- Page 6 Step 8: Carefully posi t i o n posts in final l o cati o n. Check for square. Install canopy beam assembli e s wi t h screw “R” at intersecti o ns wi t h arch beams. The use of a l e vel or simil a r tool i s hi g hly suggested.
- Page 7 Dimensi o nal and Post Locati o n Informati o n NOTE 1: Dimension Sonoma 16 (in) Sonoma 1216 (in) Recommended 12-18” DIA footing (12” mini- mum). Check local codes for depth minimums. Footing typically 24” minimum depth, 42” for ex- 151 1/2 treme cold climates.
- Page 8 The Outdoor GreatRoom Company. Any of the circumstances described in the previous sentence voids this warranty. This warranty is void if the Product or any component has been removed, repaired, or replaced before The Outdoor GreatRoom Company has been afforded a rea- sonable opportunity to inspect the Product.
