Appendix

Specifications

A
See page A-
safety.

Physical

Enclosure dimensions
(actual – see "Panel Cutout"
in chapter 3 for cutout
dimensions)
Bezel dimensions
Weight
Cutout dimensions
GFK-2328B
6 for a list of agency approvals for environmental service and
0 H
Height: 4.852 in. (123.2 mm)
Width: 6.14 in. (156 mm)
Depth: 2.026 in. (51.5 mm) – using small cutout
Height: 6.68 in. (169.7 mm)
Width: 8.50 in. (215.9 mm)
Depth: 1.13 in. (28.7 mm) – using large cutout
2.5 lb (1.16 kg)
Small:
Height: 4.86", +0.103", -0" (123.5mm, +2.6mm, -0mm)
Width: 6.14", +0.55", -0" (156mm, [+14mm, -0mm])
Large:
Height: 6.12", +/- 0.02" (155.45mm [+/-0.51mm])
Width: 7.95", +/- 0.02" (202mm, [+/- 0.51mm])
2.594in. (65.9mm) – using large cutout
0.28 in. (7.11mm) – using small cutout
1
A-
