Attop X-PACK 17 User Manual

X-PACK 17 User Manual
(Suitable for wide indoor environments operation)
Suitable for 14 years old and above
Get 24/7 assistance at
Use camera or QR scanner to scan
Or Visit: https://attop.afterservice.vip
www.attoptoys.com
Customer Service Email : attop@afterservice.vip

3. Package Contents

Drone X1 Remote X1
USB Cable X1 Propeller Guards X4

4. Charging

3
3 1
5V
a. Low battery warning
When the drone is flying, the indicator lights on the drone are flashing, and the remote
control handle emits a "beep" alarm sound, indicating that the drone power is too low.
At this time, the drone needs to return and charge.
b. Charging Guide for battery
1. Connect the USB cable with power supply, the USB LED is solid Green, indicating
the USB cable is powering on.
2. Connect the battery with USB cable. When USB LED is solid Red, indicating
charging status. When USB LED is solid Green, indicating charging was completed.
Note： The connected USB Adapter should be less than or equal to 5V 2A, the voltage should
not be greater than 5V, otherwise there is a risk of overloading the USB cable.
The flight time is apporximately 9 minutes (Battery is in a full charging state.) and the charging
time is about 60 minutes.
Phone Clamp X1 Battery X3
Spare Propellers X2
Screwdriver X1
2
1
2
2
4

1. Aircraft Parameters

Length of main wing:
Total weight:
Charging time:
Flight time:
Gyroscope:
Working temperature:
Remote controller:

2. Remote Controller Parameters

Effective control reange:
Wifi transmission range :
(in a wide open area with no electromagnetic interference)
Working frequency:

5. Installing

(1) Open up all 4 blades for the drone.
This aircraft is a folding structure, please do open up all four blades before powering on.
(2) Install blades protector.
Expand the buckle of the propeller guard, and install it onto the drone wings.
(3) Install battery.
Insert the battery into specified
1
position.
Keep pressing the buckle of battery,
2
and then pull the battery back to take
it out.
80 mm
Aircraft: 100X125X40 mm
73g±2g
Battery: 3.7V500mAh
About 90 mins
8-9 mins
built-in
14°F to 104°F
2.4G
Motor: 7*20 4pcs
50 meters
30-40 meters
2.4G
Battery: 3xAAA
1
Remote Controller:
Keep pressing the buckle of battery
case, and then pull the case to take
it out, insert 3xAAA battery into
specified position.
3
AAA 1.5V
AAA 1.5V
AAA 1.5V
Battery Case
