Attop W10 Quick Start Manual

W10 QUICK START GUIDE
3.Install and disassemble
(1) Stander installing
1
2
(2) Protective frames installing
2
1
(3) Camera installing
1
2
3
Insert the stander into specified position.
1
Pull the standers to take them out.
2
Insert the frames into specified position.
1
2 Press up the frame buckle, and pull
back to take it out.
Insert the camera onto the bottom
1
of the drone.
Plug the camera cable into specified
2
position.
To take it out, pull out the connecting
3
cable then pressing the button and pull
the camera
2

1. Package contents

X1 X1
X1 X4
2.Charging
5V
Low battery warning
When the drone is flying, the LED indicator on the drone flashes, and the remote
control handle emits a "beep" alarm sound, indicating that the drone power is too low.
At this time, the drone needs to return and charge.
Charging guide for drone
Step1. Connect the USB cable to the adapter.
Step2. Connect the other end of USB cable to battery.
Step3. Connect the adapter to the socket. If the LED light of the USB plug is on, the
charging is completed. Otherwise, it means charging. Please use the drone
when fully charged.
Note： The connected USB Adapter should be less than or equal to 5V 2A, the voltage
not be greater than 5V, otherwise there is a risk of overloading the USB cable.
The flight time is approx 9 minutes (Battery full charge state) and the charging time
is about 60 minutes.
(4) Drone battery installing
1
2
(4) Remont controller battery installing
+ +
+
(6) Mobile device holder installing
2
1
X2 X1
X4 X4 X1
1
Insert the battery into specified position.
1
Press the battery buckle button, and
2
pull back to take it out.
Open the controller's battery case
1
with the screw driver.
Accurately insert 3xAA battery into it
2
and lock the base up.
Insert the Mobile Device Holder into
1
specified position.
Press the Mobile Device Holder and
2
pull back to take it out.
3
