Attop X-PACK 18 Operation Manual

X-PACK 18 Operation Manual
(Suitable for wide indoor environments operation and
wind power less than Force 2 outdoor environments)
Suitable for 14 years old and above
Get 24/7 assistance at
Use camera or QR scanner to scan
Or Visit: https://attop.afterservice.vip
www.attoptoys.com
Customer Service Email : support@attoptoys.com
3.Install
(1) Open Up all 4 blades for the drone
This aircraft is folding structure, please do open up all four propellers before taking off.
(2) Battery Installing
1
2
1
Insert the battery into specified
position.
To disassembly, press the battery
2
buckle button, and pull back to take
it out.
(3) Mobile Device Holder Using
2
1
Remote Controller:
AAA 1.5V
AAA 1.5V
AAA 1.5V
battery
case
┐╠ ╚ 25.400
Insert 3xAAA battery into specified
position.
1
Pull up the position of controller.
2
Adjust the Mobile Device Holder up and
place the moblie onto the holder.
2
1. Package Contents
Drone X1
USB cable X1
2.Charging
3
3 1
5V
Low battery warning
When the drone is flying, the indicator lights on the drone are flashing, and the remote
control handle emits a "beep" alarm sound, indicating that the drone power is too low.
At this time, the drone needs to return and charge.
Charging Guide for battery
1. Connect the USB cable with power supply, the USB LED solid on, indicate the
USB cable is power on.
2. Connect the battery with USB cable. If the USB LED solid on, the charging is
completed. Otherwise, it means charging. Please use the drone when fully charged.
Note： Use an power supply with standard output voltage 5V and current greater than or
equal to 2A, otherwise there is a risk of overloading the USB cable and Battery.
The flight time is about 9-10 minutes and the charging time is about 120 minutes.
4. Remote Controller
1
2
3
4
5
6
7
15
1. Speed switch
2. Left stick (Altitude Control / Turn L/R)
3. Power switch
4. One key take off
5. Circle fly
6. One key landing
7. One key return
8. Headless function
Remote X1 Backup Propellers X4
Battery X2 Screw driver X1
2
CHA
1
2
1
8
9
10
11
12
13
14
16
9. Right stick (Movement control)
10. Gyro calibration
11. Forward trimming
12. Right trimming
13. Backward trimming
14. Left trimming
15. Filming
16. Take Photo
3
