X-PACK 3 Operation Manual
(Suitable for wide indoor environments operation)
Suitable for 14 years old and above
Get Assistance & Extended Warranty
Use camera or QR scanner to scan
Or Visit: https://attop.afterservice.vip
www.attoptoys.com
Customer Service Email : support@attoptoys.com
3.Install
(1) Open Up all 4 blades for the drone
This aircraft is folding structure, please do open up all four blades before power on.
(2) Blades Protector Installing
Expand the buckle of the propeller guard, and install it onto the drone wings.
(3) Battery Installing
1
Insert the battery into specified
position.
Keep press the buckle of battery
2
then pull the battery back to take it out.
Remote Controller:
AAA 1.5V
AAA 1.5V
AAA 1.5V
Battery Case
Keep pressing the buckle of battery
case then pull the case to take it out,
insert 3xAAA battery into specified
position.
2
1. Package Contents
Drone X1
Remote X1
USB cable X1 Propeller guards X4
2.Charging
3
3
1
5V
Low battery warning
When the drone is flying, the indicator lights on the drone are flashing, and the remote
control handle emits a "beep" alarm sound, indicating that the drone power is too low.
At this time, the drone needs to return and charge.
Charging Guide for battery
1. Connect the USB cable with power supply, the USB LED solid Green, indicate the
USB cable is power on.
2. Connect the battery with USB cable. When USB LED solid Red indicate charging
status. USB LED solid Green, when charging was completed.
Note: The connected USB Adapter should be less than or equal to 5V 2A, the
voltage not be greater than 5V, otherwise there is a risk of overloading the USB
cable. The flight time is about 8-9 minutes and the charging time is about 90 minutes.
(4) Phone clamp installing
Put the phone clamp to specified position on the remote, and make sure
fasten the phone clamp.
4. Remote Controller
(2)
(4)
(6)
(8)
(1) Power switch
(2) Left joystick
(Altitude Control, L/R turning)
(3) Right joystick
(Movement Control)
(4) Left function switch
(Take off/Landing, Emergency stop)
Phone clamp X1
Battery X2
Spare propellers X2
Screwdriver X1
2
1
2
1
(1)
(3)
(5)
(7)
(9)
(5) Right function switch
(Headless mode, Return)
(6) Take photo
(7) Video
(8) Speed switch
(9) 360° Stunt
3
