Tiger TIGERFLEX TIG/INS39 Assembly Instructions Manual

Pent log cabin
Hide thumbs

Advertisement

Quick Links

Download this manual
TIG/INS39
TIGERFLEX®
PENT
LOG CABIN
GENERAL ASSEMBLY
INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the TIGERFLEX TIG/INS39 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tiger TIGERFLEX TIG/INS39

Summary of Contents for Tiger TIGERFLEX TIG/INS39

  • Page 1 TIG/INS39 TIGERFLEX® PENT LOG CABIN GENERAL ASSEMBLY INSTRUCTIONS...

  • Page 2: Before You Get Started

    BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. For the duration of heavy or extended periods of rain, swelling of the wood logs may occur. Warping of the wood may also occur during excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be mitigated. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine and sheltered as much as possible during rain or snow. SUMMER WINTER WOOD WARPING CONTRACTION EXPANSION MAY OCCUR Please do not paint or treat your cabin timbers before assembly as they must stay dry for a snug tongue and groove fit. To validate your guarantee and ensure longevity of the product, it is ESSENTIAL that your building is treated with an appropriate high-quality oil or solvent based preservative AFTER assembly, both internally and externally, then annually thereafter. BUILDING A BASE Care must be taken to ensure the product is placed on a suitable base. When thinking about where the building and base is going to be constructed, ensure that there will be access to all sides for maintenance work and annual treatment. Ensure the base is firm and level and is built on firm ground, to prevent distortion. The constructed base must be at least the size of tanalised floor bearers as referenced in supplied construct diagram. It is also recommended that the floor be at least 25mm above the surrounding ground level to avoid flooding.
  • Page 3 Whilst all products manufactured are made to the highest standards of safety, we cannot accept responsibility for your safety whilst erecting or using this product. MADE IN THE UK SINCE 1913. We have been making our high quality, great value garden buildings here in Britain for decades. TO VIEW GENERAL ASSEMBLY GUIDE FOR TIGERFLEX PRNT ROOF CABIN ® GO WITH THE PRO!: We understand how busy life can be. Our Pro-Installation service can take the stress and strain out of assembling your quality Tiger building for you. We recommend using professional and dedicated installers to erect your building. With their knowledge and experience, they will ensure that your cabin is put properly in place ready for you to enjoy your space for years to come. If you have not booked our Pro-Installation service and would like to arrange an installation, please contact our friendly customer support team on 0113 205 4189 (Mon – Fri 9am-5pm) or email sales@tigersheds.com. • The pro-install team will contact you to arrange a suitable time and date for the fitting. • Sit back, relax and let our professional home installation service do all the hard work for you! • Please view our Pro Installation page on our website for full terms and conditions.
  • Page 4 BEFORE YOU GET STARTED TOOLS REQUIRED We recommend using the following tools (not supplied): HAMMER RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW FIXING KIT CONTENTS: Clout Nails Screws (13mm Galvanised - QTY 80) (35mm - QTY 192) Nails Screws (30mm Galvanised - QTY 140) (40mm - QTY 24) Nails Screws...
  • Page 5 Please retain instructions for future reference BUILDING PACK CONTENTS: For full details of what should be included please see the Module Pack List that is supplied with the delivery. They are also available on request in pdf form from our helpful Customer Support team – please call 0113 205 4189 for Customer Support or use the Items Delivered Query form at tigersheds.com/contact. Cross Brace Unpacking supplied cabin. • From the outside working in, cut banding holding all components together and remove the Module Packs. NOTE: PARTS MAY HAVE BECOME LOOSE OR MOVED DURING TRANSPORTATION. • Large items like doors and windows are screwed into cross brace. Remove screws as you come to corresponding Module Pack to reduce the risk of falling components. • All Module Packs are individually banded together. For ease, remove from vertical position on pallet and cut Module Pack banding when on a dry, horizontal surface.
  • Page 6 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 1: FLOOR BEARER ASSEMBLY: • Position floor bearers as shown. • Assemble inner tanalised floor bearers & floor joists using 4x S80. (Detail A) • Use floor jointing piece as a guide for spacing between inner tanalised floor bearers. • Assemble outer tanalised floor bearer & floor jointing piece using 4x S80. (Detail A) 6x6w FLOOR 8x6w FLOOR 10x6w FLOOR 12x6w FLOOR 14x6w FLOOR S80 S80 S80 S80 FLOOR JOIST INNER BEARER FLOOR JOINTING...
  • Page 7 Please retain instructions for future reference Step 2: FLOOR ASSEMBLY (CHECK WHAT SIZE YOU HAVE AND THE MODULES SUPPLIED) • Place half logs as shown. • Secure to tanalised floor bearer through notch at end using 1x S40 per notch. (Detail B) • Using a utility knife or similar, cut a slight notch in the top tongue of each half log and screw through log into tanalised floor bearer using 1x S80 per cut notch. (Detail C) TOP TONGUE...
  • Page 8 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 3: FLOOR ASSEMBLY (REFERENCE MODEL IS 12X6 THE MODA 19MM TIGERFLEX LOG CABIN WITH DOOR ON GABLE END.) • Take full logs and slot them into place as shown. Do not secure with screws. • For 6x6 models, use 2x full logs. • For 8x6, 10x6 & 12x6 models, use 3x full logs. • For 14x6 & 18x6 models, use 4x full logs. • Decide at this point where you would like your door to be positioned. If you plan to install the door on one of the gable ends, place your first floorboard at the door end chosen. This is referred to as the “Door Board”.
  • Page 9 Please retain instructions for future reference Step 5: FLOOR ASSEMBLY • Measure corner to corner diagonally to make sure cabin floor is square. If both values are equal, your frame is square. Realign the floor until square. Do not trim. Step 6: FLOOR ASSEMBLY (MODULE PACKS: H/J & Q*) • From the “Door Board” (see Step 3) work your way across the frame, securing remaining floorboards using 10x N30 per floorboard. NOTE: YOU WILL NEED TO REMOVE THE 2 FLOORBOARDS AND LOGS THAT WERE USED TO HOLD THE FRAME TOGETHER AS YOU COME TO THEM. • Final floorboard may need to be trimmed. Measure as shown and cut to size.
  • Page 10 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 7: POSITIONING OF DOORS & WINDOWS • Lay out the module packs supplied in the position you would like them to be constructed. See examples for some inspiration. All following instructions will be based on configuration shown below. Reference model is 12x6 The Moda 19mm TigerFlex Log Cabin with door on gable end. tigersheds.com 0113 205 4189 sales@tigersheds.com...
  • Page 11 Please retain instructions for future reference...
  • Page 12 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® tigersheds.com 0113 205 4189 sales@tigersheds.com...
  • Page 13 Please retain instructions for future reference...
  • Page 14 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 8: WALL ASSEMBLY STAGE 1 (MODULE PACKS: A, B & Q*) • For central sections, use notched logs from Module Pack Q, which have a removed section as shown. (No “Q” pack supplied with 6x6 Models) • Secure through notch into log below using 1x S40 per notch, then secure into floorboards. Drill pilot hole at an angle through log into floorboard, then secure in place as shown using 1x S40 per cut log. (Detail E) ADDITIONAL STEPS FOR DOOR POSITIONING OR FULL PANE WINDOWS ON GABLE. • If you are having a door or full pane window on the end, remove the full log used for boarding the floor and replace with 2x cut logs as shown. Insert 2x 190mm spacers under the edge of cut logs.
  • Page 15 Please retain instructions for future reference Step 9: BUILDING A WALL FOR ¾ WINDOW • Build 6 logs high using 1750mm / 1150mm full logs depending on size of building. Then use 274mm cut logs to start building window frame. Use supplied construct diagram for reference. • Secure 274mm cut log through notch into log below using 1x S40. Drill a pilot hole at an angle through the cut log into the full log below and screw into place as shown using 1 x S40. (Detail E In Step 8 For Reference) • Continue to build upwards. Secure built walls using 190mm spacers every five logs high using 2x S35. (Detail H & H1) 190MM SPACER...
  • Page 16 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 10: BUILDING A WALL FOR A FULL PANE WINDOW • Start with 274mm cut logs. • Secure 274mm cut logs through notch into log below using 1x S40. Drill a pilot hole at an angle through the cut log into the half log below and screw into place as shown using 1x S40. (Detail E In Step 8 For Reference) • Continue to build upwards. Secure built walls using 190mm spacers every five logs high using 2x S35. (Detail H & H1 In Step 9 For Reference) Use supplied construct diagram for reference.
  • Page 17 Please retain instructions for future reference Step 11: BUILDING A BLANK WALL • Start building using 1750mm / 1150mm full logs depending on size of building. Use supplied construct diagram for reference. • Secure full bottom log through notch into log below using 1x S40. Drill a pilot hole at an angle through the cut log into the half log below and screw into place as shown using 1x S40. (Detail E In Step 8 For Reference) • Continue to build upwards. Secure built walls using 190mm spacers every five logs high using 2x S35. (Detail H & H1 In Step 9 For Reference)
  • Page 18 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 12: WALL ASSEMBLY STAGE 2 (MODULE PACKS: G, T & Z/BB) • Take the pent gable top apart by unscrewing the logs. NOTE: KEEP SCREW IN SAFE PLACE. WILL BE REQUIRED TO COMPLETE GABLE TOP INSTALL. • Install bottom piece of pent gable tops as shown. (Detail I) • Install high side log supplied in Module Z/BB. • Install top piece of pent gable tops as shown.
  • Page 19 Please retain instructions for future reference • Secure pent gable tops into walls using 2x S35 per gable top. • Secure 190mm spacers to central gable tops using 2x S35 per spacer as shown. Screw through gable tops into spacer from either side. (Detail K & L) • Pent gable top removed to show 190mm spacer. (Detail L) • Repeat processes to build up remaining walls as shown.
  • Page 20 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 13: ROOF PANEL INSTALLATION (MODULE PACKS: M/AA & T) • “Hook” roof panels into notches pre-cut into pent gable tops. • Roof panels should be flush with outer edges of the logs. (Detail M) • Use 3x S40 evenly spaced along length to secure roof panels together. (Detail N) • Tie roof panels together on both sides using 190mm spacers. Secure using 2x S40 per joint.. (Detail O) • Secure roof to walls and gable tops using the following steps: • 4x S35 evenly spaced along length into gable tops. (Detail M & P) •...
  • Page 21 Please retain instructions for future reference Step 14: FULL PANE WINDOW FASCIA ASSEMBLY (MODULE PACKS: FCW1 & U) • Open Module Pack “U”. • Take window frame and attach the external fascia only. On a window, the external side fascia is the longer of the two supplied. (1770mm) • Attach side fascias first. Secure using 3x S35 evenly spaced per fascia. Angle pilot hole first and then screw through fascia board into frame. • Repeat the process for the header and bottom fascia board using 3x S35 evenly spaced per fascia.
  • Page 22 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 15: 3/4 WINDOW FASCIA ASSEMBLY (MODULE PACKS: FCW2/3/4 & V/X) • Open window fascia packs. • Take window frame and attach the external fascias only. • Attach side fascias first. Secure using 3x S35 evenly spaced per fascia. Angle pilot hole first and then screw through fascia board into frame. • Repeat the process for the header and bottom fascia board using 3x S35 evenly spaced per fascia. tigersheds.com 0113 205 4189 sales@tigersheds.com...
  • Page 23 Please retain instructions for future reference Step 16: DOOR FASCIA ASSEMBLY (MODULE PACKS: FXCD1/2/3 & U) • Open Module Pack “U”. • Take door frame and attach the external fascias only. On a door, the external side fascias are the longer of the two supplied. (1770mm) • Attach side fascias first. Secure using 3x S35 evenly spaced per fascia. Angle pilot hole first and then screw through fascia board into frame. • Repeat the process for the header and bottom fascia board using 3x S35 evenly spaced per fascia.

  • Page 24: Window Installation

    TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 17: WINDOW INSTALLATION • Once external fascias have been fitted, offer window up to the opening as shown. • Make sure window is positioned centrally, resting on the last full log within the opening. NOTE: THERE WILL BE A GAP EITHER SIDE TO ALLOW FOR MOVEMENT OF LOGS. • Secure the window to the walls using 7x S35 evenly spaced. • Internal fascias can be installed at this point. These are fixed to the window frames only. NOTE: DO NOT ATTACH TO THE LOGS. (See Step 14 &15 For Reference) tigersheds.com 0113 205 4189...

  • Page 25: Door Installation

    Please retain instructions for future reference Step 18: DOOR INSTALLATION • Once external fascias have been fitted, offer door up to the opening as shown. • Make sure door is positioned centrally, resting on the last tanalised bearers on the floor within the opening. NOTE: THERE WILL BE A GAP EITHER SIDE TO ALLOW FOR MOVEMENT OF LOGS. • If door is on side of cabin, rest door on the half log. • Secure the door to the walls using 7x S35 evenly spaced. • Internal fascias can be installed at this point. These are fixed to the door frames only. Do not attach to the logs. (See Step 14 &15 For Reference) NOTE: DOORS DO NOT HAVE AN INTERNAL LOWER FASCIA. Ongoing: As timber is a natural product, any log or board can expand and contract.
  • Page 26 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 19: INTERNAL FIXINGS (MODULE PACKS: H & Z/BB) • Secure roof battens in place as shown using 2x S35 per batten. (Detail Q) • Secure corner battens in place as shown. Battens in 2 pieces so need to be butted together. (Detail R). • Secure battens to side walls using 4x S35 per corner (x2 per batten) • Secure side skirting as shown using 3x S35 equally spaced per skirting piece. • 6x6, 12x6 & 18x6 Models – Skirting @ 1430mm (x2, x4, x6) • 8x6, 10x6 & 14x6 Models – Skirting @ 1430mm (x0, x2, x2) & 830mm (x4, x2, x4) • Secure gable skirting (1467mm) using 3x S35 equally spaced per skirting piece. tigersheds.com 0113 205 4189 sales@tigersheds.com...
  • Page 27 Please retain instructions for future reference ROOF PANELS, DOORS & WINDOWS REMOVED FOR CLARITY: Roof battens in place - 2 places - Floor skirting in place - 2 places LOW SIDE INTERNAL HIGH SIDE INTERNAL...
  • Page 28 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 20: JOINTING FASCIA BOARDS (MODULE PACKS: N & P*) • Secure jointing fascias internally & externally as shown between the side module joins. Module Packs P to be used on the high side. • Butt top fascia flush with roof and secure in place using 4x S35. NOTE: ANGLE EDGE MUST BE AS SHOWN TO STOP WATER INGRESS. (Detail S) • Butt bottom fascia board against top fascia board as shown and secure in place using 4x S35. (Detail S & T) • Repeat for internal fascia boards and remaining exterior fascia board. Secure into 190mm spacers.
  • Page 29 Please retain instructions for future reference Step 21: FELTING THE ROOF (MEASURE AND CUT BEFORE INSTALLING THE FELT) • Roll felt out onto a clean flat surface 30 minutes before you need it so it has a chance to flatten out. • Measure length of roof and allow 75mm overhang at each end. Cut each strip of felt to size. Use a straight edge to guide cutting. • Roll cut felt piece along low side of roof, Section 1, leaving sufficient overhang to fold down onto roof edge. NOTE: DO NOT FOLD UNDERNEATH ROOF. (Detail V1 & V2) • Once felt is rolled out, fix to roof using CN13 at approx. 100mm intervals. Ensure the felt is tight, (Detail V3) then secure the top side of felt using CN13 at approx. 100mm intervals. • Repeat for remaining felt, working from the low side of roof to the high side, overlapping the felt by 75mm until the roof is fully covered. • Fold the overhanging felt at ends under roof panel and tack in place. CORRECT INCORRECT FELT...
  • Page 30 TIGERFLEX PENT LOG CABIN GENERAL INSTRUCTIONS ® Step 22: BARDGEBOARDS & FINIAL (MODULE PACKS: S & Z/BB) • Fit barge boards to the roof panels, trapping overhanging end of the felt in between the roof panel and fascia board. Secure using 3x N40 per barge board. • Barge boards may need trimming. NOTE: THERE ARE NO BARGEBOARDS SUPPLIED FOR LOW SIDE OF ROOF. • Secure finial over the top of the barge boards using 2x N40 per finial. (Optional) tigersheds.com 0113 205 4189 sales@tigersheds.com...
  • Page 31 Please retain instructions for future reference...
  • Page 32 TIG/INS39 Head Office TO VIEW GENERAL ASSEMBLY GUIDE FOR TIGERFLEX PRNT ROOF CABIN Calverley Lane, ® Rodley, Leeds, West Yorkshire, LS13 1NP Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com TO SEE GENERAL ACCESSORY & INSTALLATION VIDEO LIBRARY...
