Summary of Contents for Tiger Tigercub Groovy Garage
- Page 1 TIG/INS63 TIGERCUB GROOVY GARAGE GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. - Page 3 Please retain instructions for future reference CAUTION: CAUTION: All buildings should be erected It is advisable to wear gloves by two competent adults. during building installation. MADE IN THE UK SINCE 1913. We have been making our high quality, great value garden buildings here in Britain for decades.
- Page 4 BEFORE YOU GET STARTED - PRE ASSEMBLY TOOLS REQUIRED: We recommend using the following tools (not supplied): HAMMER RUBBER MALLET LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW SPANNER FIXING KIT GUIDES: FX02 - NAIL KITS SMALL FX03 - NAIL KITS MEDIUM For Shed Products Up To 6ft Sides: For Shed Products With 7ft to 9ft Sides:...
- Page 5 Please retain instructions for future reference • Assembly is straightforward if you follow these step-by-step instructions. • We recommend getting everything aligned properly before screwing together and that screw holes should be pre-drilled to avoid splitting the timber. (Do not come pre-drilled). IMPORTANT •...
- Page 6 TIGERCUB GROOVY GARAGE - GENERAL ASSEMBLY INSTRUCTIONS Step 1: LAYING THE FLOOR • SINGLE FLOOR - Lay floor down in the desired position. (Detail A1) Step 2: INSTALLING SIDE AND GABLE PANELS • Position one end gable and side panel as shown.
- Page 7 Please retain instructions for future reference Step 3: SECURING SIDE AND GABLE PANELS • Locate pre-drilled holes in gable panels. (Detail C1) NOTE: THESE MAY HAVE COVERED OVER DURING PANEL COATING PROCESS. THEY MAY RESEMBLE NAILS HEADS. • Use 4x CB80 per gable, through the pre-drilled holes in each gable, from the outside. (Detail C2) NOTE: DO NOT FULLY TIGHTEN.
- Page 8 TIGERCUB GROOVY GARAGE - GENERAL ASSEMBLY INSTRUCTIONS Step 3b: SECURING SIDE AND GABLE PANELS • Secure panels to the floor using 2x N65 per panel. Ensure the N65 are driven through the panels and into the floor bearers. (Detail C4) NOTE: PANELS HAVE BEEN REMOVED FOR CLARITY.
- Page 9 Please retain instructions for future reference Step 4: FIT CORNER STRIPS AND COVER STRIP • Secure the corner strips at each corner of the shed with 4x N40 per corner strip. NOTE: THESE CORNER STRIPS MAY NEED CUTTING TO SIZE. NOTE: NOT TO BE CONFUSED WITH WINDOW BEADING.
- Page 10 TIGERCUB GROOVY GARAGE - GENERAL ASSEMBLY INSTRUCTIONS Step 6: TOP TIP You may need someone to hold roof panels together while you secure SINGLE PIECE ROOF INSTALLATION roof panels at the apex. • Attach roof panels as shown. There will be a slight gap between the roof panels at the apex of shed.
- Page 11 Please retain instructions for future reference Step 7: INSTALL INTERNAL VERANDA RAIL • Secure through veranda framing into gable panel framing using 2x N65 per panel. (Detail F1) • Secure through veranda framing into internal floor using 5x N65. (Detail F2) NOTE: ROOF PANELS REMOVED FOR CLARITY.
- Page 12 TIGERCUB GROOVY GARAGE - GENERAL ASSEMBLY INSTRUCTIONS Step 9: FELTING THE ROOF - MEASURE AND CUT BEFORE FITTING • Roll felt out onto a clean flat surface 30 minutes before you need it so it has a chance to flatten out.
- Page 13 Please retain instructions for future reference Step 10: FITTING FASCIA BOARDS & FINIAL (BARGEBOARDS) • Fit bargeboards to the roof panels, trapping overhanging end of the felt in between the roof panel and bargeboard. • Secure using 2x N40 per bargeboard through apex and low side purlins. NOTE: THERE ARE NO BARGEBOARDS SUPPLIED FOR LOW SIDE OF ROOF AS THIS WILL PREVENT EFFECTIVE WATER DRAINAGE.
- Page 14 TIGERCUB GROOVY GARAGE - GENERAL ASSEMBLY INSTRUCTIONS Step 11: INSTALL PLAYHOUSE FRETS AND GLAZING • Insert styrene from inside of playhouse. • Optional: Insert playhouse frets and butt up to styrene. • Secure frets to panel with 2x N40 nails on bottom, left and right sides.
- Page 15 Please retain instructions for future reference...
- Page 16 TIG/INS63 Display Agent Woodlands DIY Store Station Yard, Horsforth, Leeds, LS18 5NZ Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com...
