Summary of Contents for Creda C60THX
- Page 1 60CM T SHAPED COOKER User Manual HOOD MODEL/S V 1.0 C60THX...
- Page 2 User Manual You’ll soon be enjoying your new Creda Cooker Hood! It all begins here, with your instructions. Don’t worry, there’s nothing too technical coming up. Just simple, step-by-step guidance to get you up and running quickly. Sound good? Then let’s get started.
-
Page 3: Table Of Contents
Contents — PAGE SAFETY INTRODUCTIONS INTRODUCTION AND TECHNICAL DRAWING OF THE CHIMNEY HOOD INSTALLATION OF CHIMNEY HOOD MOUNTING THE CHIMNEY HOOD ON THE WALL FUNCTIONS OF THE CHIMNEY HOOD OPERATING THE CHIMNEY HOOD REPLACING THE BULB MAINTENANCE OF THE CHIMNEY HOOD TROUBLE SHHOTING GUIDE HELP AND ASSISTANCE... -
Page 4: Safety Introductions
INSTRUCTION MANUAL SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE • This product is designed for domestic use. • Product Voltage is 220-240 Volts 50Hz. • Power cord of your product is fitted with grounded plug. This cord must be plugged into a grounding socket. •... -
Page 5: Introduction And Technical Drawing Of The Chimney Hood
INSTRUCTION MANUAL INTRODUCTION AND TECHNICAL DRAWING OF THE CHIMNEY HOOD Location of the Chimney Hood INSTALLATION OF CHIMNEY HOOD LOCATION OF THE CHIMNEY HOOD Fix the 2 (two) Mounting brackets among the installation accessories to the chimney hood with one 1 screw nut as shown in Figure 1. -
Page 6: Mounting The Chimney Hood On The Wall
INSTRUCTION MANUAL Installation of Wall Mounting Bracket 3 drywall (8mm) anchors are nailed into the holes drilled according to installation template (A,B,C). They are fixed into the wall with 2 brackets as shown in Figure 2. Installation of Inner Duct Mounting Bracket 2 fixing holes are drilled on the wall with Ø6mm electric drill at a suitable height and place to fix the inner duct hanger plate onto the wall. -
Page 7: Functions Of The Chimney Hood
INSTRUCTION MANUAL Mounting the Aluminum Pipe Place the aluminum pipe on the plastic duct. Place the other end of the pipe into the air outlet in the kitchen. Figure 6 Twists and bends on the aluminum pipe may cause minimizing the air suction so avoid unnecessary bends and twists as much as possible. - Page 8 INSTRUCTION MANUAL SYMBOLS FUNCTIONS Note: When the product operates for a certain time, the aluminum filters get dirty and the digital display shows "C" Clean sign. This means the filters should be cleaned. Press the speed reduction key for 5 secs in order to delete "C"...
-
Page 9: Operating The Chimney Hood
INSTRUCTION MANUAL OPERATING THE CHIMNEY HOOD Chimney hood is used in ducted and non-ducted kitchens. In ducted use; In ducted use, extractor fan should be connected to an air outlet to send the air out. To use your chimney hood efficiently, make sure length of the pipe system between the chimney hood and the air outlet should be short. -
Page 10: Replacing The Bulb
INSTRUCTION MANUAL REPLACING THE BULB Always switch off the electrical supply before carrying out any operation. • LED bulb does not operate is possible to remove as shown in Figure 12 • A new bulb to be supplied from service points is replaced with the same reoperation. •... -
Page 11: Trouble Shhoting Guide
INSTRUCTION MANUAL TROUBLE SHOOTING GUIDE Before contacting the service, make sure the product is plugged and the fuse in the electrical installation is working. Do not do anything that may harm the product. When you contact your service or dealer to ask for any spare parts, notify them of product model name shown in the product label. -
Page 12: Help And Assistance
Local call rates apply* Lines open 9am-5:30pm Monday to Friday *Calls to Creda enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tariff. Mobile and other providers costs may vary, see www.bt.com/pricing for details. - Page 13 • Specifications are subject to change without notice. • Creda disclaim any liability for loss or damage arising from the breakdown of the product. • This guarantee is in addition to and does not diminish your statutory or legal rights.
- Page 14 INSTRUCTION MANUAL Declaration of conformance to product standards This appliance conforms to all relevant standards applicable to domestic appliances sold in the UK. Disposal This appliance/fitting is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
