Summary of Contents for Saunum Spa Session
- Page 1 Saunum Spa Session all in one sauna heater to create a spa atmosphere...
- Page 2 THE BEST SAUNA EXPERIENCE TO HAVE! am very glad that you have invested in the Saunum device, and I believe that our innovative technology will offer you a wonderful and extraordinary sauna experience. I have a degree in thermal engineering and come from the Southern Estonia, where my love for saunas began.
- Page 3 A moist steamy sauna, a therapeutic salt sauna, or a healthy aroma sauna – all of these functions are available on Saunum’s devices to create a truly relaxing sauna experience. When...
- Page 4 Saunum Saunas Ltd congratulates you on choosing a heater with an innovative sauna room indoor climate device!
-
Page 5: Table Of Contents
CONTENTS Safety information ___________________________________ Safety distances _____________________________________ Dimensions _______________________________________ Product completeness _______________________________ INSTALLING Before the installation _________________________________ Installation instructions _______________________________ Electrical connections ________________________________ Electric heater insulation resistance ______________________ Installing and replacing the heating elements _______________ INSTRUCTIONS FOR USE Heating the sauna room ______________________________ Using the sauna climate device _________________________ Adjusting the temperature _____________________________ Regulation of the sauna climate _________________________... -
Page 6: Safety Information
NB! To connect the sauna climate device to the power network, a control device for the control of electric heaters is required. Before using the Saunum Spa Session The control device must correspond to heater with an indoor climate device (here- the power of the heater used according to inafter ‘sauna climate device’), read the in-... - Page 7 To ensure the longevity of the device, make sure that the temperature of the sauna room at the height of the lower part of the device does not exceed 80 °C. If it is exceeded, the thermal protection will be applied and the fan will stop; the fan will start running again if the temperatuure drops below the fuse limit of application.
-
Page 8: Safety Distances
SAFETY DISTANCES Safety distances of the Spa Session sauna Safety distances: unit and the recommended location in the A (minimum distance from sides) 50 mm, sauna room. B (minimum distance from back side) 20 mm, C (minimum distance from side) 50 mm. - Page 9 minimum distance from minimum distance from temperature sensor 300 mm temperature sensor 300 mm supply Temperature supply sensor Non-combustile material supply minimum distance from temperature sensor 300 mm supply Temperature sensor Non-combustile material supply...
-
Page 10: Dimensions
490 mm Saunum Spa Session... -
Page 11: Product Completeness
PRODUCT COMPLETENESS Elements required for operation that All parts of the product are supplied in are not part of the Spa Session compo single package. sition: power supply cables and stones. A - Front panel E - Stone basket top grille... -
Page 12: Before The Installation
Saunum Spa Session room. model used in accordance with Table 1 (see • The device works most efficiently pages 6–7) may be used to control the sau-... -
Page 13: Installation Instructions
INSTALLATION Saunum Spa Session has been designed with ease of installation in mind – everything has been pre-assembled. During installation the main steps are loading the stones and mak- ing the electrical connections. LOADING THE STONES NOTE! Do not drop any stone... - Page 14 NO STONES AREA! DISTANCE BETWEEN 150–200 mm Do not stack stones with force, start with bigger stones and put smaller on the top. When you have filled the basket with stones like shown in graph, reposition the top grille and then add stones to it on and ensure that the air can move freely.
- Page 15 Front view Side view Side view NO STONES AREA!!! DISTANCE BETWEEN 150–200 mm Working principle and explanation when the device heats up.
-
Page 16: Electrical Connections
ELECTRICAL CONNECTIONS Do the electrical connections according to The sauna climate device is already the schematic on page 30. Feed the cable equipped with the control device. The control device is integrated within the through the openings in bottom of the heater, located behind the bottom rear heater near the cable terminals. - Page 17 Figure 2 Temperature sensor SIHF 3 x min 0,25 mm Incoming Lighting Door sensor power (optional) SIHF 2 x min 0,25 mm Control panel KLMA 4 x 0,8 LED power supply Grid voltage max 25 W 240 V 5 x 2,5 mm2 (or 5 x 4 mm2)
-
Page 18: Electric Heater Insulation Resistance
NB! Due to the potential danger of ther- below 1000 mm must withstand a mal embrittlement, it is forbidden to use temperature of at least 90 °C. a PVC-insulated cable as the connection • The recommended cross-section cable for the sauna climate device. of the connection cable grooves is given in Table 1 (see pages 6–7). - Page 19 Door sensor 2 x min 0,25 mm Electric panel 5 x 2,5...
-
Page 20: Installing And Replacing The Heating Elements
INSTALLING AND REPLACING THE HEATING ELEMENTS NB! Before proceeding to replace the heating elements, make sure that the device is disconnected from the mains!. 1. Remove the top grille. 2. Remove the front panel by releasing the front panel bolts and pulling the front panel upwards. - Page 21 5. Release all the heating element cables. 7. Remove the heating element module. 6. Undo the bolts holding the heating element module in place. NB! Each heating element is fixed with special gaskets, starwashers and nuts. 8. Replace the heating element module and re-position all components in reverse order.
-
Page 22: Heating The Sauna Room
When switching the sauna climate device The operating time of the sauna climate on, check: device model Saunum Spa Session may be adjusted by a separate control device. • the direction of the air flow – the air intake from the upper and the out- put from the lower opening;... -
Page 23: Adjusting The Temperature
REGULATION OF THE • Children should not be allowed to access or play with the sauna climate SAUNA CLIMATE device. • When switching the sauna climate The amount of air circulation generated by device on and off, refer to the in- the device is regulated by the same control structions for the use of the control unit that is used for heating control. - Page 24 The air deflector can be positioned to the sides or by sliding the deflector. See the graphs below to see how the air deflector affects the direction of air output. Centered Right...
- Page 25 After moving the air deflector to the desired position, add 2 Himalayan saltball and reposition the bottom front panel. NB! Sauna users must not keep their feet or other body parts closer than 50 cm in front of the working fan! Please keep children away minimal 100 cm if the fan works with any speed, the sauna steam may cause burn skin!
-
Page 26: Use Of Himalayan Salt Balls
USE OF HIMALAYAN SALT BALLS The sauna climate device comes with Hima- layan salt balls. The use of salt balls in the device is optional and does not affect the main function of the device. To use the salt balls, they must be installed in the sockets between the air outlet grille and the fan. -
Page 27: Throwing Water On The Heater
The effects of heat and steam on people are different. When testing the different settings of the SAUNUM climate de- vice, you will find the most suitable combi- nation of temperature and humidity. -
Page 28: Loading The Stones
• Wash any dust off the stones before placing them in the heater. NB! When using Saunum equipment, we always recommend doing so with high- quality polished sauna stones! When loading the stones, note: •... -
Page 30: Warnings
WARNINGS • Make sure you have proper ventila- tion in the sauna room. Saunum is not responsible for possible salt cor- rosion of equipment and machinery. • Staying in the sauna room for a long If necessary, consult a specialist! time raises your body temperature, •... -
Page 31: Solving Problems
Saunum. • Make sure that the ventilation of THE SAUNA CLIMATE DEVICE DOES NOT the sauna room is correct. - Page 32 the wrong type of stone may inter- THE SAUNA CLIMATE DEVICE IS MAKING fere with the air flow through the NOISE. heater and cause the surrounding • There is always a certain noise materials to overheat. when the fan is running. If it is not •...
-
Page 33: Maintenance
The fan may only be cleaned by a person autho Before servicing and cleaning the sauna rised by Saunum. climate device, make sure that: • the sauna climate device is discon- Using compressed air to clean the fan can... -
Page 34: Sauna Room
1.5. The optimal sauna room If the air outlet is in the washroom, there sizes for the sauna climate device Saunum must be a gap of at least 100 mm under the Luxury Experience are given in Table 1 (see sauna room door. -
Page 35: Warranty
1. Routine maintenance and cleaning due to the use of substandard materials of the device and replacement of or the quality of the assembly, Saunum’s the components due to normal recom mended repair partners will repair or wear and tear. - Page 36 You can find the list of Saunum Saunas OÜ’s recommended installation and maintenance professionals on the Saunum Saunas OÜ website www.saunum.com or by contacting us at info@saunum.com Saunum’s device maintenance instructions can be found in the instructions for use. Please note! The sauna climate device may...
-
Page 37: Installation Report
INSTALLATION REPORT Date of purchase: _________________________________________________________ Heater type: ____________________________________________________________ Sticker/serial number: Date of installation: ___________ Place of installation: _______________________________________________________ Installed by: ____________________________________________________________ Checked by: _____________________________________________________________ Date, signature: __________________________________________________________ Description of the work done: ________________________________________________ All the details are available for the installation ____________________________________ There are no colour defects or dents __________________________________________ Installed on the wall or on the floor according to the instructions _____________________ The electrical connections are made according to the installation instructions ___________... - Page 38 EC declaration of conformity Manufacturer: Saunum Saunas OÜ Address: Suur-Paala 19 11415 Tallinn, Estonia certifies that the product: Saunum Spa Session complies with the requirements of the following directives of the Council of Europe, provided that the installation has been performed in accordance with the installation instructions issued by the device manufacturer and the instructions EN 60 204-1 “Safety of the machinery.
