Parameter
Battery
Power consumption at
rated voltage
Fuse
Power supply
Display
Active area of display
Pixel errors
Backlight brightness
Backlight lifetime
Operating temperature
Storage temperature
Relative humidity in
operation
Vibration
Mechanical shock
Approvals and
certifications
UL approval
Marine certificates
4.1. Compass Safe Distance
Variant
X2 control 21
Non-energized
Non-energized after
magnetization
Energized and operating
Beijer Electronics, MAEN269
BR 2032 lithium battery
replaceable
45.6 W
Internal DC fuse, 4 AT, 5 × 20 mm
+24 VDC (18–32 V DC)
CE: The power supply must conform with the requirements
according to EN/IEC 60950 and EN/IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class 2 power supplies.
TFT-LCD with LED backlight
1920 × 1080 pixels, 16.7M colors
21.5" diagonal
Class I (ISO 9241-307)
250 Cd/m2
50,000 hours
0°C to +50°C
-20°C to +70°C
5 - 85% non-condensation
1g, according to IEC 60068-2-6, Test Fc
15g, half-sine, 11ms according to IEC60068-2-27
CE/FCC/KCC Information is available on
www.beijerelectronics.com
Information is available on
UL.com
Information is available on
Condition
15
X2 control 21 - B2
www.beijerelectronics.com
www.beijerelectronics.com
Standard Compass
Steering Compass
40 cm
20 cm
80 cm
50 cm
40 cm
15 cm
Technical Data
and
2023-09
