NuWave OXYPURE ZERO 47251 Quick Start Manual

Button Name Function
Turns the OxyPure
POWER
Allows you to run the OxyPure at the lowest fan
AUTO
speed, raising it based on PM level.
ECO Allows you to save energy by turning the OxyPure
MODE
fan off when it is not needed.
Automatically switches to the highest fan speed
ULTIMATE
CLEAN when the PM level rises.
Allows you to connect the OxyPure to your Wi-Fi
Wi-Fi
MODE network
FLOW
Adjusts the louver angles.
ANGLE
MUTE &
Turns the beeping on or off.
UNMUTE
FAN
Adjusts the OxyPure's fan speed.
SPEED
Turns off the control panel LED lights but keeps the
SLEEP
MODE fan active.
Helps limit the amount of time the OxyPure is on.
TIMER
FILTER 2
Reset the Filter indicator
RESET
Operates at the highest fan speed for a set time
TURBO
(1/2 hour, 1 or 2 hours).
FILTER 4
Reset the Filter indicator
RESET
Customer Service: For Amazon Purchases: support@nuwavenow.com ● For All Other Purchases: help@nuwavenow.com
E1000
Use
on and off. Press POWER to turn the OxyPure
®
Press AUTO and the Auto back light will turn on. There is no time limit on the Auto Mode. Press
AUTO again to deactivate Auto Mode.
Press and hold AUTO for 1 second to activate Eco Mode. When the air quality is poor, the unit will
automatically run. When the air quality is good, the unit will turn off. Press AUTO and hold for 1
second to deactivate Eco Mode.
Press ULTIMATE CLEAN to activate the Ultimate Clean Mode.
Press and hold ULTIMATE CLEAN to initiate Wi-Fi pairing.
Press AIR FLOW ANGLE to adjust the louver angles from 30°, 60°, 90°.
Press and hold FLOW ANGLE to mute the OxyPure. Repeat to unmute.
There are 6 fan speed levels. Press FAN SPEED to adjust from Speed 1 (lowest) to Speed 6
(highest).
Adjust the Fan Speed prior to activating Sleep Mode. Press and hold FAN SPEED for 2 seconds to
activate Sleep Mode. Press any button to deactivate it.
Press TIMER to select from the 6 timer settings of 1/2, 1, 2, 4, 8 or 12 hours.
Press and hold TIMER for 2 seconds to reset the FILTER 2 indicator.
Press TURBO once to run the OxyPure at the highest speed for ½ hour.
Press and hold TURBO for 2 seconds to reset the FILTER 4 indicator.
Quick Start Guide
Refer to the Owner's Manual for more details
Model No: 47251 / 47261
Air/Odor Quality - Detects particles as small as 2.5/1000mm
Low PM Level
Particulate Matter (PM) with a diameter of 2.5 microns or less
0~5 5~10 10~20 20~30
Fan Speeds
1 2 3
See the Owner's Manual for details.
on and off.
®
High PM Level
30~50 Over 50
4 5 6
