- Page 1 INVERTER Generator PMi 2000 User's manual Please read the manual carefully before using the generator. This guide contains important guidance for safe operation.
- Page 3 PMi 2000 INVERTER Generator - Preface Thank you for buying INVERTER Generator. PMi 2000. This book includes the operation and maintenance instructions for the AII the contents of this book аге consistent with the print of the latest product. The Company retains its right to amend this guide, thus will not notify later ог...
- Page 4 PMi 2000 INVERTER Generator- Catalogue Safety matters Label position of safety matters Components identifier Check before operation Start the engine (operation at high altitudes) Usage Turn off the engine maintenance Transport/storage Examine and repair the breakdown 1 О. Technical specification...
- Page 5 Warning • lf you operate the PMi 2000 generator according to the guide, the generator will run safely. Please read and understand the guide without fail before you use it, ог else casualties ог damage of the equipment will Ье caused Ьу...
- Page 6 Please read carefully the words оп the labels, the safety warnings and the notes recounted in the guide. lf the labels have fallen off ог аге illegiЬle, please contact the Powermate Ьу Pramac agent and change them.
- Page 7 PMi 2000 INVERTER Generator- З. Components identifier В- ventilating pole А- of gas-burning lid pulling pole of air-Ыocking valve H-repair cover F - switch of the engine E-display (V/Hz/W) repair cover of the spark plug muffler...
- Page 8 PMi 2000 INVERTER Generator - Controlling panel: outputting overloading indicator light indicator light gas а arm1ng indicator light switch of the intelligent gas-saving valve direct current socket direct current alternating loop protector current socket display ground end (V/Hz/W) Attention: Tip: We have а smart display: when the machine is running it the state of voltage, frequency, and power used Ьу...
- Page 9 PMi 2000 INVERTER Generator - Warning • When the electrical equipment needs disconnecting from the electric power, the intelligent gasoline-saving system can not run effectively. • When the generator is connected with а high electric charge, turn off the intelligent gasoline-saving valve to minimize the change of middle pressure.
- Page 10 PMi 2000 INVERTER Generator - 4. Check before operation Warning • Check the generator, keep it оп а horizontal surface without fail, and ensure that the engine is turned off. 1. Check the oil Jevel Warning • Usiпg oil without cleaпser ог 2-strokes eпgiпe's oil may shorteп the geпerator's service life.
- Page 11 PMi 2000 INVERTER Generator - Note: The oil alarming system will turn off the engine before the oil level descends to the security line. But to avoid the inconvenience caused Ьу unexpected machine halt, we advise you to check the oil level regularly.
- Page 12 PMi 2000 INVERTER Generator - The gasoline containing alcohol lf you decide to use the gasoline containing alcohol (Ьioethanol), its octane value сап not below the level recommended Ьу manufacturer. There are two kinds of alcoholic gasoline: one contains ethanol, and the other contains methanol.
- Page 13 PMi 2000 INVERTER Generator - cover of the air filter screw of the air filter соге of the air filter...
- Page 14 PMi 2000 INVERTER Generator - Start the engine Before starting the engine, cut off the load from the alternating current socket оп the engine. Totally turn the valve to the "OPEN" position clockwise. а) Note: when transporting the engine, you should turn the ventilating pole of the gasoline-burning lid to the "CLOSE"...
- Page 15 PMi 2000 INVERTER Generator- switch of the engine Turn the pulling pole of the air-Ыocking valve to the "CLOSE" position с ) Note: when the engine is hot ог the environmental temperature is relatively high, do not use the starter.
- Page 16 PMi 2000 INVERTER Generator- A-Starting hold е) When the engine is warming up, turn the pulling pole of the air-Ьlocking valve to the "START" position. (!-____ 1-run /operate v � \ start � 2- pulling pole of the air-Ыocking valve Note : make sure to put to ON the ventilating pole of fuel filling lid ;...
- Page 17 PMi 2000 INVERTER Generator- authorized agent to modify the carburetor. Even though you use the proper nozzle, the horsepower of the engine will still decline 3.5% as the altitude increases every ЗOOmeters ( 1 ООО feets ). lf these adjustments are not made, the altitude will have greater influence on power.
- Page 18 PMi 2000 INVERTER Generator- 6. Usage of the engine lf all the installations that are connected have been earthed, make sure to earth the engine. Warning • ln order to prevent getting an electric shock because of incorrect operation, the engine should Ье earthed. The earth port of the engine and the outside earth source аге...
- Page 19 PMi 2000 INVERTER Generator - Please comply with the following regulations: • lf you need to lengthen the саЫе, please use the soft саЫе with rubber cover (according to IEC245 or relevant requirements). • The length requirement of the lengthened саЫе: 60 meters for 1.5 square millimeters one, and 100 meters for 2.5 square millimeters one.
- Page 20 PMi 2000 INVERTER Generator - examine it to find out the breakdown. The outputting and overloading indicator lights lf the generator is in а good working order, the outputting indicator light (green) is on. If the generator overloads ( over its rated power), or in case of а short circuit inside the electrical machine it links to, the outputting indicator light (green) will turn off, while the overloading indicator light (red) will lighten.
- Page 32 PMi 2000 INVERTER Generator - 1 О. Technical specifications Size and weight • model PMi 2000 • length*width*height(mm) 555*305*460 • net weight(kg) Engine • model 160F stroke 4, overhead аiг valve, one cylinder • engine type • exhaust quantity(diameter of cylinder * stroke) 60*40mm •...
