- Page 1 <At horizontal installation> ENGLISH Before operating the unit, read these operating instructions thoroughly and keep them for future reference. <At vertical installation> Model No. INDOOR UNIT Middle Static Pressure Duct (Type F3) S-15MF3E5A S-60MF3E5A S-22MF3E5A S-73MF3E5A S-28MF3E5A S-90MF3E5A S-36MF3E5A S-106MF3E5A S-45MF3E5A...
-
Page 2: Table Of Contents
Safety Precautions Thank you for purchasing this Panasonic product. This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents The following symbols used in this manual, alert you to potentially dangerous conditions to users, service personnel or... - Page 3 WARNING If the refrigerant comes in contact Do not use modified with a flame, it produces toxic cord, joint cord, gases. extension cord or unspecified cord to prevent For safety, be sure to turn the overheating and fire. air conditioner off and also to disconnect the power before cleaning or servicing.
- Page 4 CAUTION This appliance is intended to be used This appliance is intended to be used Do not turn the air conditioner on Do not turn the air conditioner on by expert or trained users in shops, by expert or trained users in shops, and off from the power mains switch.
-
Page 5: Precautions For Use
Precautions for Use Installation Information for Users on Collection and Disposal of Old Equipment and Used Batteries This air conditioner must be installed properly by qualified installation technicians in accordance with the Installation hese symbols on the products, packaging, Instructions provided with the unit. and/or accompanying documents mean that Before installation, check that the voltage of the electric used electrical and electronic products and... -
Page 6: Names Of Parts
Names of Parts INDOOR UNIT Type F3 (Middle Static Pressure Duct) At standard installation (Horizontal installation in the ceiling, rear side air intake) Air outlet duct * Suspension bolt * Label (attached to the lid of electrical component box) This air conditioner incorporates a biocidal product. Ionized air generated by a device incorporated in the air conditioner deactivates bacteria and Indoor unit... -
Page 7: Maintenance
Maintenance WARNING The internal coil and other components of the „ outdoor unit must be cleaned periodically. • Consult your dealer or service center. For safety, be sure to turn the air conditioner off and disconnect the power before cleaning. (Otherwise, electric shock or injury may result because the fan is rotating at high speed.) Do not pour water on the indoor unit. -
Page 8: Nanoe™ X Function
nanoe™ X Function Display during operation of nanoe™ X Example: Initial screen of remote controller CZ-RTC5B CZ-RTC6 series room A room A 20:30 (THU) 20:30 (THU) SET TEMP. SET TEMP. MODE MODE FAN SPEED FAN SPEED COOL COOL °C °C FLAP °C FLAP : Under operation of nanoe™... -
Page 9: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation •... -
Page 10: Before Requesting Services
Troubleshooting Before Requesting Services Symptom Cause Action The air Power failure or after power failure Press the power ON/OFF button on the remote controller. conditioner does • If the breaker is turned off, turn the power on. not operate The operation (power) button is turned off. •... - Page 11 Connectable outdoor unit lineup Europe Outdoor unit type 4 HP 5 HP 6 HP 8 HP 10 HP 1-phase U-4LE2E5 U-5LE2E5 U-6LE2E5 – – 3-phase U-4LE2E8 U-5LE2E8 U-6LE2E8 – – 3-phase – – – U-8LE1E8 U-10LE1E8 3-phase – – – U-8ME2E8 U-10ME2E8 3-phase...
-
Page 12: Specifications
Specifications Indoor unit Middle Static Pressure Duct Model Name S-15MF3E5A S-22MF3E5A S-28MF3E5A S-36MF3E5A S-45MF3E5A S-56MF3E5A Power source 220 - 230 - 240 V～ 50 - 60 Hz Cooling capacity 5,100 7,500 9,600 12,300 15,400 19,100 BTU/h Sensible Latent Heating capacity... - Page 13 Model Name S-60MF3E5A S-73MF3E5A S-90MF3E5A S-106MF3E5A S-140MF3E5A S-160MF3E5A Power source 220 - 230 - 240 V～ 50 - 60 Hz 10.6 14.0 16.0 Cooling capacity 20,500 24,900 30,700 36,200 47,800 54,600 BTU/h 11.0 Sensible Latent 10.0 11.4 16.0 18.0 Heating capacity 24,200 27,300 34,100...
-
