DuPont™ IntegraTec™ P Series
PVDF-UF Out-In
XP 55 UXA Open Platform Modules
Assembly Manual
Version 1
September 2023
NOTICE: The information provided in this literature is given in good faith for informational purposes only. DuPont assumes
no obligation or liability for the information presented herein. NO WARRANTIES ARE GIVEN; ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED
Advertisement
Table of Contents
Related Manuals for Dupont IntegraTec P Series
Summary of Contents for Dupont IntegraTec P Series
- Page 1 Version 1 September 2023 NOTICE: The information provided in this literature is given in good faith for informational purposes only. DuPont assumes no obligation or liability for the information presented herein. NO WARRANTIES ARE GIVEN; ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED...
-
Page 2: Table Of Contents
Figure 6. Feed Clamp Orientation ......................................8 Figure 7. DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type I Installation Drawing .............. 10 Figure 8. DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type II Installation Drawing .............. 11 Figure 9. -
Page 3: Legal Notice
Legal Notice Product This manual applies to DuPont™ IntegraTec™ PVDF-UF Out-In P Series Modules for Open Platforms, parts and components for installation, assembly and disassembly. Duplication and archiving in any form whatsoever – including of excerpts – is only permitted with the written consent of the manufacturer. -
Page 4: About These Instructions
In the event of making a warranty claim, the customer agrees to automatically provide DuPont™ with a complete set of documentation. Please contact DuPont™ if you wish to deviate from any of the guidelines or specifications provided in this document and request written approval in advance. -
Page 5: Tools And Equipment
Tools and Equipment 3. Tools and Equipment Prepare following tools and equipment before module assembly and installation, Figure 1. Safety Goggle; Glove; Latex glove; Scissors; Screw driver Liquid collection basin; Shelf or platform for module placing; ... -
Page 6: End Cap Assembly
End Cap Assembly 4. End Cap Assembly Lift up module Open cardboard box, lift module out of it and place on the platform or shelf, keep two ends of module above the ground. Place liquid holder Place two liquid collection basin beneath the module ends, Figure 2. Figure 2 Liquid collection basin beneath the module ends Cautions: Each non-anti-freezing module (GMID 12091655，12091656) contains 4 L storage solution, the major ingredients... -
Page 7: Prepare End Caps
End Cap Assembly Wear safety goggle and latex glove before opening end caps, be careful of the liquid when dismounting the blind plates and concentrate plug. If storage solution splash to the operators’ hands and skid, please rinse with water immediately. -
Page 8: Install Feed End Cap
X-ring installed in position. Request the latest exploded drawing from your DuPont contact: • DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type I Technical Drawing (Form No 45-D02586-en) • DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type II Technical Drawing (Form No 45-D02587-en) •... -
Page 9: Install Module To Skid
Pre-install feed and filtrate connector to the opening of skid End cap assembly I Module: refer to Figure 7. DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type I Installation Drawing, install two compressions coupling 2"(13) to the feed and filtrate opening of skid. -
Page 10: Figure 7. Dupont™ Integratec™ Xp 55 Uxa - End Cap Assembly Type I Installation Drawing
Install Module to Skid Figure 7. DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type I Installation Drawing Page 10 of 13 Form No. 45-D04608-en, Rev 0 September 2023... -
Page 11: Figure 8. Dupont™ Integratec™ Xp 55 Uxa - End Cap Assembly Type Ii Installation Drawing
Install Module to Skid Figure 8. DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type II Installation Drawing Page 11 of 13 Form No. 45-D04608-en, Rev 0 September 2023... -
Page 12: Figure 9. Dupont™ Integratec™ Xp 55 Uxa - End Cap Assembly Type Iii Installation Drawing
Install Module to Skid Figure 9. DuPont™ IntegraTec™ XP 55 UXA - End Cap Assembly Type III Installation Drawing Page 12 of 13 Form No. 45-D04608-en, Rev 0 September 2023... - Page 13 DuPont or others is to be inferred. www.dupont.com/water/contact-us DuPont™, the DuPont Oval Logo, and all trademarks and service marks denoted with ™, SM or ® are owned by affiliates of DuPont de Nemours, Inc. unless otherwise noted. © 2023 DuPont. All right reserved Page 13 of 13 Form No.
