Water Solutions
DuPont™ IntegraTec™ P Series
Ultrafiltration T-Rack™

Assembly Instructions

Version 7
October 2022
NOTICE: The information provided in this literature is given in good faith for informational purposes only. DuPont assumes no
obligation or liability for the information presented herein. NO WARRANTIES ARE GIVEN; ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED
Powered by
