Installation Overview
Attaching the Bracket onto the DIN Rail
Step 2 Push up on the AP so that the spring of the DIN clip compresses against the lower section of DIN rail, and then rotate
the AP so that the top hook of the DIN clip clamps to the top section of DIN rail.
Figure 8: Bracket Attached to the DIN Rail
1 DIN rail bracket 2 DIN rail
Note The procedure to attach the unit to the rail is the same with both orientations.
