Panasonic NN-ST34NBQPQ Service Manual

Service Manual
This service manual is strictly meant to be used by experienced professional repair technicians only and is not designed for use
by the general public. Products powered by electricity should be serviced and repaired only by experienced professional repair
technicians ( Professionals ). Any attempt to service or repair the product by anyone else could result in serious injury and
even death. Panasonic shall not be responsible to the extent permitted by applicable law. For any damages, losses, costs,
expenses, death, injury, claims, decree, proceedings, and/or judgment, arising out of, in connection with, or relating to, any use
and/or misuse of this service manual by user other than Professionals.
There are special components used in this equipment which are important for safety. These parts are marked by
Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these
critical parts should be
modify the original design without permission of manufacturer.
The specifications and the parts of this product are subject to change without notice for performance improvement or
other purposes.
Specifications
Power Requirement
Power Output
Microwave Frequency
Magnetron
Timer
Outside Dimensions
Cavity Dimensions
Net Weight
WARNING
IMPORTANT SAFETY NOTICE
230-240V, 50Hz
Microwave 1300-1400W
900 Watts full microwave power
2450 MHz
2M519J
0 ~ 99 min. and 50 sec.
469 mm (W) x 380 mm (D) x 280 mm (H)
329 mm (W) x 326 mm (D) x 236 mm (H)
12 kg
Specifications subject to change without notice.
Order No. MOD2212631CE
Microwave Oven
NN-ST34NBQPQ
Model No.
NN-ST34NWQPQ
Model No.
25L
Black/White
Australia, New Zealand
