Panamorph STE-J1 Installation Manual

CEILING OR SHELF MOUNTING. Regardless of the projector orientation the
STE retainer should be installed with the prongs closer to the ceiling so the
Panamorph logo is upright after installation.
ABOUT GEOMETRIC DISTORTION AND CHROMATIC ADJUSTMENTS.
Anamorphic horizontal expansion lenses create a slight "pincushion" shaped
curvature especially at the edges of the image which decreases as the
projection distance is increased for a given screen size. See the Image
Geometry estimator in the Lens Selector at
approximate distortion to expect. Masking the edges of the image by the screen
border makes this distortion much less noticeable especially for dramatic content.
These lenses may also reveal a slight splitting of white test pattern lines into red,
green and blue components most visible at the far left and right sides. While this
splitting may not be noticeable at normal viewing distances, any misconvergence
can be reduced with the projector's Pixel Adjust feature.
CLEANING. Small amounts of dust and wipe marks are very noticeable on lens
surfaces with a high brightness projection beam but typically will not impact the
image as much as damage from excessive cleaning in pursuit of a "perfect"
optical surface. Occasionally blowing off the lens surfaces with clean air is the
best way to keep long term performance. If there is any excessive residue or
build-up then it is recommended that you clean the optics with professional lens
cleaning supplies such as from a camera store while the lens is in front of the lit
beam of the projector. This will allow you to quickly see if the cleaning process is
causing any damage. Note that the lens can be disassembled for cleaning by
removing the front two screws and then carefully removing the components.
However, any consequences of such disassembly is not covered by warranty or
support.
LIMITED WARRANTY. Panamorph, Inc. warrants this product against any
change in performance or functionality for a period of twenty-four months from
our ship date. During this period, a unit may be repaired or replaced, at the
discretion of Panamorph, Inc., by returning it in its original packaging with a copy
of your receipt. This warranty does not cover damage resultant from lack of
prudent care, accident or misuse (including use with other products in ways not
intended); any cosmetic damage not reported within 15 days of purchase; or any
performance change caused by the environment in which it is used. All damages
are limited to the cost of the product. This warranty is not transferable.
See www.panamorph.com
settings with illustrations for various content.
www.panamorph.com for the
for projector viewing mode
STE-J1 Instruction Guide Version 1.1
We bring cinema home
STE-J1
Direct Attach Cinema Format Conversion Lens
INSTALLATION GUIDE
(Phillips #2 screwdriver required)
See www.panamorph.com
Specifications: 6.3" (160mm) diam x 5" (127mm) depth. 2 lbs (0.9 kg). Allow 3.5"
(90mm) in front of projector for installation. See back page for warranty.
IMPORTANT THEATER GUIDANCE
1. Projection screen should be in the
minimum 2.5" border.
2. Projector should be horizontally centered on the screen +/- 3 inches
with minimal horizontal lens shift. Projector
ideally be between 3" below to 10" above the screen top for best
performance. Beyond these limits may prevent the beam from passing
through the lens at low throw ratios.
3. See the www.panamorph.com
screen size compatibility as well as projector viewing mode settings.
US Patent 11635676. Other US and international patents pending.
®
for JVC projector compatibility
2.4:1 aspect ratio with a
vertical position should
home page for throw distance and
