GLASS-CERAMIC SPECIFICATIONS

®
KERA LITE glass-ceramic is specially manufactured for use in high temperature applications. This glass-
ceramic has a thermal endurance far exceeding that of normal tempered glass. KERA LITE
operate at temperatures ranging from -400
®
LITE stove windows should be treated with care. This glass-ceramic can still be scratched or broken by
mechanical abuse. When cleaning the window, use only non-caustic, non-abrasive cleaners.
Flame gas fireplace doors use a KERA LITE
Country Flame custom cuts each KERA LITE
occur or should the glass-ceramic ever need replacement, contact Country Flame or a local authorized
dealer for assistance. The glass-ceramic specifications are as follows:
Manufacturer
Window Type

GLASS REPLACEMENT

1. Turn off gas valve.
2. Unlock four door latches (2 each side), refer to door installation section and FIGURE 23.
WARNING: Once door latches are unhooked, nothing holds door assembly to Bayvue DV. Do not
let the door assembly drop, handle with care.
3. Remove the door assembly from the Bayvue DV guide pins and lay it on a padded flat surface.
4. From the inside of the door remove the door rope gasket, FIGURE 22, left view, Item E. Undo twenty
#6 nuts and four #10/32 screws, FIGURE 22, right view, Item J that holds glass retainer strips in place.
Store all loose parts in a safe location as they will be required during reinstallation. Remove the glass
retainers, FIGURE 22, right view, Item I.
caution. Use leather gloves and wear safety glasses when removing broken glass.

GASKET SPECIFICATIONS

GASKET
BAYVUE DOOR SYSTEM
Fiberglass tape side glass
Fiberglass tape center glass
Rope gasket, front door
Version 1.0h
0
F to +1400
®
®
WARNING:
FIGURE 22: GLASS REPLACEMENT
_____ LENGTH
36"
41"
88"
0
F. Despite its superior thermal properties, KERA
glass-ceramic that is 0.197 inches thick +/- 0.008 inches.
glass at its factory to fit the fireplace door. If problems
Broken glass is extremely sharp. Use extreme
QUANTITY
2
1
1
34
®
is designed to
Euro Kera
Glass-Ceramic, Kera Lite
DESCRIPTION
¾" by 1/16" fiberglass tape
¾" by 1/16" fiberglass tape
3/4" diameter rope, high density
Country
®
