Sauder County Line 417771 Manual

Side table/night stand
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Side Table/Night Stand
County Line Collection | Model 417771
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Sweet stand.
Sweet dreams.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 374576
06/29/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder County Line 417771

Summary of Contents for Sauder County Line 417771

  • Page 1 County Line Collection | Model 417771 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-15 Hammer Not actual size Français 16-18 Español 19-21 Safety Warranty Page 2 417771 www.sauder.com/services...
  • Page 3 DRAWER RIGHT SIDE (1) BOTTOM (1) LEFT REAR LEG (1) DRAWER LEFT SIDE (1) BACK (1) LONG FRONT/BACK SKIRT (2) D154 DRAWER BACK (1) RIGHT FRONT LEG (1) SHORT SIDE SKIRT (2) D960 DRAWER BOTTOM (1) D154 D960 www.sauder.com/services 417771 Page 3...

  • Page 4: Table Of Contents

    CAM COVER - 8 PULL - 1 BRACKET - 1 3S GOLD 5/16" FLAT HEAD SCREW - 8 BLACK 9/16" LARGE HEAD SCREW - 10 30S BLACK 1-9/16" FLAT HEAD SCREW - 4 SILVER 1/4" MACHINE SCREW - 2 Page 4 417771 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1725...
  • Page 6 Fasten four METAL BRACKETS (4G) to the SKIRTS (I and J). å Use four BLACK 9/16" LARGE HEAD SCREWS (1S). (24 used) The BRACKET should be even with the edge. BLACK 9/16" LARGE HEAD SCREW (4 used in this step) Page 6 417771 www.sauder.com/services...
  • Page 7 Fasten the LEGS (E, F, G, and H) to the ENDS (A2) and å SHORT SIDE SKIRTS (J). Tighten twelve HIDDEN CAMS. These surfaces must be even. Metal bracket These surfaces must be even. Finished edge Metal bracket Finished edge www.sauder.com/services 417771 Page 7...
  • Page 8 ENDS (A2). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. NOTE: Use the holes shown. å *patent pending glide system å GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Glide end Glide end Page 8 417771 www.sauder.com/services...
  • Page 9 Fasten the LONG FRONT SKIRT (I) to the LEFT FRONT å LEG (F). Tighten one HIDDEN CAM. S u r f a c w i t h H I D D E N Finished edge Metal bracket Metal bracket www.sauder.com/services 417771 Page 9...
  • Page 10 å (4 used in this step) the SKIRTS (I and J). (8 used) To cover the HIDDEN CAMS on the SKIRTS. f a c S u r h o l w i t h Long edge Page 10 417771 www.sauder.com/services...

  • Page 11: Hidden Cam

    Step 7 Carefully stand your unit upright. å Fasten the TOP (B) to the ENDS (A2). Tighten four å HIDDEN CAMS. Long edge www.sauder.com/services 417771 Page 11...

  • Page 12: Black 1-9/16" Flat Head Screw

    BLACK 1-9/16" FLAT HEAD SCREW (4 used in this step) D154 Groove Be sure the DRAWER BOTTOM inserts into the DRAWER BACK groove. D154 D960 With the palm of your hand, tap the DRAWER BOTTOM into the grooves. Page 12 417771 www.sauder.com/services...

  • Page 13: Black 9/16" Large Head Screw

    å easy identifi cation. Fasten the DRAWER FRONT (K) to the DRAWER FRONT BRACKETS (7G). å Use two BLACK 9/16" LARGE HEAD SCREWS (1S). Push down BLACK 9/16" LARGE HEAD SCREW (2 used in this step) www.sauder.com/services 417771 Page 13...

  • Page 14: Pull

    Fasten the PULL (98K) to the DRAWER FRONT (K). å Use two WASHERS (10I) and two SILVER 1/4" MACHINE SCREWS (61S). Glide end SILVER 1/4" MACHINE SCREW (2 used for the PULL) Glide end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 14 417771 www.sauder.com/services...
  • Page 15 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? 40 lbs. 10 lbs. 30 lbs. www.sauder.com/services 417771 Page 15...
