Installation, Operation, and Maintenance Manual
Low Profile Roof/Sidewall and Roof Downblast
READ AND SAVE THESE INSTRUCTIONS
The purpose of this manual is to aid in the proper installation and operation of fans
manufactured by Soler & Palau USA. These instructions are intended to supplement good
general practices and are not intended to cover detailed instruction procedures, because of
the wide variety and types of fans manufactured by Soler & Palau USA.
6393 Powers Avenue
Jacksonville, FL 32217
P: 800.961.7370
F: 800.961.7379
Models LPD and RED
Direct Drive Centrifugal Exhausters
Advertisement
Table of Contents
Related Manuals for S&P RED
Summary of Contents for S&P RED
- Page 1 Models LPD and RED Installation, Operation, and Maintenance Manual Direct Drive Centrifugal Exhausters Low Profile Roof/Sidewall and Roof Downblast READ AND SAVE THESE INSTRUCTIONS The purpose of this manual is to aid in the proper installation and operation of fans manufactured by Soler &...
-
Page 2: Installation
INSTALLATION, OPERATION AND MAINTENANCE MANUAL INTRODUCTION: DO NOT INSTALL, USE OR OPERATE THIS EQUIPMENT UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE USE. It is the responsibility of the purchaser to assure that the installation and maintenance of this equipment is handled by qualified personnel experienced in such work and equipment. - Page 3 1. CAUTION! This fan contains rotating parts and requires special service. Appropriate safety precautions should be taken during installation, operation and maintenance. 2. WARNING! Do not install or operate this fan in an environment or atmosphere where combustible or flammable materials, gasses or fumes are present, unless it was specifically designed and manufactured for use in that environment.
-
Page 4: Maintenance
Lock out the power source before the installation of all accessories. Fan electrical power can now be applied and special attention should be given to determine if motor is working properly. At this time, with air system in full operation, with guards attached, it is well for the electrician to measure the operating amperage of the motor and compare with the nameplate rating to determine that the motor is operating under safe load conditions. -
Page 5: Repair Parts
REPAIR PARTS: 3. Fan Blades – Repair of individual fan blades or propeller assemblies is not recommended. Contact factory with blade size, number of blades, bore size, motor HP, air flow direction, rotation, fan RPM or sheave sizes and any order/tag information that is available for replacement. 4. - Page 6 Replacement Parts Model RED Support Motor Cover Rubber Grommets Motor Windband Legs Brackets Wheel Skirt Cover Birdscreen (4 Required (4 Required Model per unit) per unit) 4 Required 1 Required per unit per unit Part # Part # Part #...
-
Page 7: Warranty
WARRANTY: Soler & Palau USA warrants this equipment to be free from defects in material and workmanship for five (5) years from date of shipment. Any units or parts which prove to be defective and are reported during the warranty period will be replaced at our option when returned to our factory, transportation prepaid.
