  • Page 1 Digital Oscilloscope SMO1000E/SMO1000U User Manual...
  • Page 2 Information in this manual supersedes all corresponding previous released material. Scientific continues to improve products and reserves rights to amend part or all of the specifications, procedures, equipment at any time without notice. Ver_1.00/ 0523 Scientific Mes-Technik Pvt.

  • Page 3: Table Of Contents

    3.7 User Interface ....................37 3.8 Security Lock ....................39 4. Vertical System ...................... 40 4.1 Enable the Channel ..................41 4.2 Adjust Vertical Scale ..................42 4.3 Adjust Vertical Position ................. 43 4.4 Channel Coupling ..................43 4.5 Bandwidth Limit..................... 44 SMO1000E/SMO1000U 3/234...
  • Page 4 7.2 Trigger Mode ....................68 7.3 Trigger Level ....................69 7.4 Trigger Coupling ................... 70 7.5 Trigger Holdoff ....................71 7.6 Noise Rejection ..................... 72 7.7 Trigger Type ....................74 7.7.1 Edge Trigger ..................75 7.7.2 Slope Trigger ..................76 SMO1000E/SMO1000U 4/234...
  • Page 5 9.2 Display REF Waveform ................123 9.3 Adjust REF Waveform ................124 9.4 Clear REF Waveform ................. 124 10 Math Function ..................... 125 10.1 Units for Math Waveforms ................. 126 10.2 Math Operators ..................127 10.2.1 Addition or Subtraction ..............127 SMO1000E/SMO1000U 5/234...
  • Page 6 14.4.2 Delete a file or folder ............... 165 14.4.3 Rename a file or folder ..............165 15. Digital Channels (Option) ................... 166 15.1 Connect the Digital Probes................ 167 15.2 Acquire Digital Waveform ................168 15.3 Digital Channels Height ................168 SMO1000E/SMO1000U 6/234...
  • Page 7 16.9.2 Web Browser ................... 193 16.10 Counter ....................195 16.11 Data Logger .................... 198 16.11.1 Sample Logger ................198 16.11.2 Measure Logger ................202 16.12 Update Firmware and Configuration ............207 16.13 Do Self Test .................... 208 16.13.1 Screen Test ................... 208 SMO1000E/SMO1000U 7/234...
  • Page 8 18.1 Time Navigate ................... 227 18.2 History Frame Navigate ................227 18.3 Search Event Navigate ................227 19. History Function ....................228 20. Factory Setup ....................230 21. Troubleshooting ....................231 22. Dispatch procedure for Service, E-Waste Management & Warranty ....233 SMO1000E/SMO1000U 8/234...

  • Page 9: Safety Information

    Inadequate ventilation may cause increasing of temperature, which will eventually damage the instrument. So keep well ventilation and inspect the intake and fan regularly. Avoid Circuit or Components Exposed Do not touch exposed contacts or components when the power is on. SMO1000E/SMO1000U 9/234...
  • Page 10 To avoid the influence of dust and/or moisture in air, please keep the surface of device clean and dry. Handling Safety Please handle with care during transportation to avoid damages to buttons, knob interfaces and other parts on the panels. SMO1000E/SMO1000U 10/234...

  • Page 11: Safety Terms And Symbols

    Indicates potential injuries or hazards that may happen. CAUTION Indicates potential damages to the instrument or other property that may happen. Symbols on the product. These symbols may appear on the product: Hazardous protective Warning Test Power Voltage Earth Ground Switch Terminal SMO1000E/SMO1000U 11/234...

  • Page 12: Measurement Category

    Stationary motors with permanent connection to the fixed installation. Measurement category IV is for measurements performed at the source of the low-voltage installation. Examples are electricity meters and measurements on primary over current protection devices and ripple control units. SMO1000E/SMO1000U 12/234...

  • Page 13: Working Environment

    In these terminals, precautions are done to limit the transient voltage to the corresponding low level. Installation (overvoltage) category II refers to the local power distribution level which is applicable to equipment connected to the AC line (AC power). SMO1000E/SMO1000U 13/234...

  • Page 14: Ventilation Requirement

    To avoid damages to the surface of the instrument and probe, please do not use any corrosive liquid or chemical cleanser. WARNING Make sure that the instrument is completely dry before restarting it to avoid short circuits or personal injuries. SMO1000E/SMO1000U 14/234...

  • Page 15: Document Overview

    Introduce how to save and recall the measurement result and the setting of the oscilloscope. System Setting Introduce how to set the system setup. Default Introduce the Default setup of the oscilloscope Troubleshooting Introduce how to deal with common failures of the oscilloscope. SMO1000E/SMO1000U 15/234...

  • Page 16: Quick Start

    The contents of this chapter: Appearance and Dimensions To Prepare the Oscilloscope for Use Front Panel Overview Rear Panel Overview Front Panel Function Overview Help User Interface To Use the Security Lock SMO1000E/SMO1000U 16/234...

  • Page 17: Appearance And Dimensions

    Scientific 3.1 Appearance and Dimensions Figure 1 Front View (2-channel scope) Figure 2 Top View (2-channel scope) SMO1000E/SMO1000U 17/234...
  • Page 18 Scientific Figure 3 Front View (4-Channel Scope) Figure 4 Top View (4-Channel Scope) SMO1000E/SMO1000U 18/234...

  • Page 19: Prepare The Oscilloscope For Use

    The power requirements of the oscilloscope are 100-240 V, 50/60/440 Hz. Please use the power cord supplied with the accessories to connect the oscilloscope to the power source. 2-Channel Scope 4-Channel Scope Figure 6 To Connect to Power Supply SMO1000E/SMO1000U 19/234...

  • Page 20: Power-On Inspection

    Use the probe to connect the input terminal of CH1 of the oscilloscope and the “Compensation Signal Output Terminal” of the probe. Press the Auto Setup. Observe the waveform on the display. In normal condition, the display should be a square waveform as shown in the figure below: SMO1000E/SMO1000U 20/234...

  • Page 21: Probe Compensation

    Set the switch to 10X on the probe. Perform steps 1, 2, 3 and 4 of “Function Inspection” in the previous section. Check the waveforms displayed and compare them with the following: Over Perfectly Under Compensated Compensated Compensated SMO1000E/SMO1000U 21/234...
  • Page 22 Scientific Use a nonmetallic driver to adjust the low-frequency compensation adjustment hole on the probe until the waveform displayed is as the “Perfectly compensated” in the figure above. SMO1000E/SMO1000U 22/234...

  • Page 23: Front Panel Overview

    Figure 8 SMO1000E Front Panel Overview (2-Channel Scope) NO. Description NO. Description LCD Display Vertical Control Universal Knob Probe Comp Common Function Menus Analog Channel and Ext Input Run/Stop USB Host Auto Setup Menu Softkey Trigger Control Menu on/off Horizontal Control Power Button SMO1000E/SMO1000U 23/234...
  • Page 24 Trigger Control Common Function Menus Menu on/off Clear Sweeps Menu Softkey Run/Stop One-button shortcut for Save Decode Analog Channel Auto Setup Power Button Navigate USB Host History Digital Inputs Default Probe Compensation / Ground Terminal Vertical Control, Math, REF SMO1000E/SMO1000U 24/234...
  • Page 25 Scientific Figure 10 SMO1000U Front Panel Overview NO. Description NO. Description LCD Display Vertical Control, Math, REF Universal Knob Horizontal Control Common Function Menus Trigger Control Clear Sweeps Menu on/off Run/Stop Menu Softkey Decode One-button shortcut for Save Auto Setup...

  • Page 26: Rear Panel Overview

    The BNC port can output a signal that reflects the current waveform capture rate of the oscilloscope at each trigger or a pass/fail test pulse. USB Device The oscilloscope support SCPI remote control commands, user can control the oscilloscope through this interface. SMO1000E/SMO1000U 26/234...
  • Page 27 50/60/400 Hz. Use the power cord provided with the instrument to connect to AC power. Pass/Fail or Trigger Out The BNC port can output a signal that reflects the current waveform capture rate of the oscilloscope at each trigger or a pass/fail test pulse. SMO1000E/SMO1000U 27/234...
  • Page 28 Scientific Figure 13 SMO1000U Rear panel Overview Handle Pull up the handle vertically for easy carrying of the instrument. When you do not need the handle, press it down. Safety lock Hole You can lock the instrument to a fixed location using the security lock (please buy it yourself) via the lock hole.

  • Page 29: Front Panel Function Overview

    Press down this knob to quickly turn on Zoom function. SMO1000E/SMO1000U 29/234...

  • Page 30: Vertical

    REF function menu. A reference waveform can be displayed and compared against other waveforms. press the button to open the digital channel function menu (optional function) SMO1000E (4-channel scope) supports 16 digital channels SMO1000E/SMO1000U 30/234...

  • Page 31: Trigger

    Press down the knob to quickly reset the trigger level to center of the waveform. SMO1000E/SMO1000U 31/234...

  • Page 32: Run Control

    : press the button to set the acquisition state to Run or Stop. In RUN state, the key is illuminated in yellow. In STOP state, the key is illuminated in red. SMO1000E/SMO1000U 32/234...

  • Page 33: Universal Knob

    Choose file or directory or input filename. After having entered the file system, turn the Universal Knob to select the desired file or directory. When inputting filename, turn the Universal Knob to select the desired character and the push the knob to confirm. SMO1000E/SMO1000U 33/234...

  • Page 34: Menu

    : Press the button to enter the MEASURE function menu to set the measurement parameters, all measurement, statistics and set the gate. : Press the button to enter the ACQUIRE function menu to set the acquisition mode, memory depth, wave interpolation and so on. SMO1000E/SMO1000U 34/234...
  • Page 35 I2C, SPI, UART/RS232, CAN and LIN serial bus decode. : Press the button to turn off or turn on the navigate function. SMO1000E (4- channel scope) and SMO1000U support the three navigating types: time. Search event, history frame. SMO1000E/SMO1000U...

  • Page 36: Help

    The oscilloscope has an on line help function that supplies multi-language help information. You can access the help function by pressing any button for 2 seconds and a help window will explain the function. Also all of the submenus include help information. Figure 14 Help Message SMO1000E/SMO1000U 36/234...

  • Page 37: User Interface

    Represent the time per grid on the horizontal axis on the screen. Use the HORIZONTAL SCALE Knob to adjust the parameter. The available range is from 1.0 ns to 100 s for SMO1000E while from 2.0 ns to 100 s for SMO1000U Horizontal Position (Delay) Turn the Horizontal Position Knob to adjust the parameter.
  • Page 38 Indicate that the LAN port is disconnected. Indicate that the WLAN port is connected. Indicate that the WLAN port is disconnected. 13. Menu Display the corresponding function menu of the selected button. Press the corresponding softkey to set the oscilloscope. SMO1000E/SMO1000U 38/234...

  • Page 39: Security Lock

    The method is as follows, align the lock with the lock hole and plug it into the lock hole vertically, turn the key clockwise to lock the oscilloscope and then pull the key out. Security lock hole Figure 16 To Use the Security Lock SMO1000E/SMO1000U 39/234...

  • Page 40: Vertical System

    This chapter introduces how to set the vertical system of the oscilloscope. The contents of this chapter: Enable the Channel Adjust Vertical Scale Vertical Position Channel Coupling Bandwidth Limit Probe Attenuation Factor Unit Deskew To Invert a Waveform Input Impedance To Specify Amplitude Unit To Specify SMO1000E/SMO1000U 40/234...

  • Page 41: Enable The Channel

    After the channel is turned on, modify the parameters such as the vertical scale, the horizontal time base and the trigger mode according to the input signal to make the waveform display easy to observe and measure. Note: to turn off the channel, press the channel button twice. SMO1000E/SMO1000U 41/234...

  • Page 42: Adjust Vertical Scale

    By default, the probe attenuation factor is 1X and the adjustable range of the vertical scale is from 500uV/div to 10 V/div. Note: push the VERTICAL Variable Knob to quickly switch between Coarse and Fine adjustments. SMO1000E/SMO1000U 42/234...

  • Page 43: Adjust Vertical Position

    1.02 V/div ~ 10 V/div ±200 V 1 mV/div ~ 200 mV/div ±2V SMO1000U 206 mV/div ~ 10 V/div ±200 V 4.4 Channel Coupling Set the coupling mode to filter out the undesired signals. For example, the signal under test is a square waveform with DC offset.

  • Page 44: Bandwidth Limit

    The table shows the probe attenuation factor Menu Attenuation Factor 0.1X 0.1 : 1 0.2X 0.2 : 1 0.5X 0.5 : 1 1 : 1 2 : 1 … … 5000X 5000 : 1 10000X 10000 : 1 Custom 1000000:1 ~ 0.000001:1 SMO1000E/SMO1000U 44/234...

  • Page 45: Amplitude Unit

    1. Press CH1button on the front panel to enter the CH1 function menu. 2. Press the Next Page softkey to enter the second page of the CH1 function menu. 3. Press the Trace softkey to visible or hidden the channel waveform SMO1000E/SMO1000U 45/234...

  • Page 46: Label

    20 characters. The characters beyond this length will not be displayed. When the “Display” option is set to “on”, the label will be displayed on the right side of the channel offset indicator. Figure 17 CH1 Label Display SMO1000E/SMO1000U 46/234...

  • Page 47: Horizontal System

    Scientific Horizontal System This chapter introduces how to set the horizontal system of the oscilloscope. The contents of this chapter: Horizontal Scale Horizontal Delay Roll Mode Zoom Function SMO1000E/SMO1000U 47/234...

  • Page 48: Horizontal Scale

    The range of the SMO1000E horizontal scale is from 1ns/div to 100s/div. The range of the SMO1000U horizontal scale is from 2ns/div to 100s/div. The Horizontal Scale Knob works (in the Normal time mode) while acquisitions are running or when they are stopped.

  • Page 49: Zoom Function

    To change the time base for the Zoom window, turn the Horizontal Scale Knob. The Horizontal Scale Knob controls the size of the box. The Horizontal Position Knob sets the left- to- right position of the zoom window. The delay value, which is the time displayed SMO1000E/SMO1000U 49/234...
  • Page 50 To change the time base of the normal window, turn off Zoom; then, turn the Horizontal Scale Knob. SMO1000E/SMO1000U 50/234...

  • Page 51: Sample System

    This chapter introduces how to use the run control and set the sampling system of the oscilloscope. The contents of this chapter: Run Control Overview of Sampling To Specify Memory Depth To Select Sampling Mode Waveform Interpolation Method Acquisition Mode Horizontal Format Sequence Mode SMO1000E/SMO1000U 51/234...

  • Page 52: Run Control

    , the equally spaced sampling frequency f must be greater than twice the maximum frequency f , in order to have the signal be uniquely reconstructed without aliasing. = Nyquist frequency (f ) = folding frequency SMO1000E/SMO1000U 52/234...

  • Page 53: Sample Rate

    Waveform Confusion: when the sample rate is lower than twice the actual signal frequency (Nyquist Frequency), the frequency of the waveform rebuilt from the sample data is lower than the actual signal frequency. The most common aliasing is the jitter on fast edge. SMO1000E/SMO1000U 53/234...

  • Page 54: Oscilloscope Bandwidth And Sample Rate

    However, digital signals have frequency components above the fundamental frequency (square waves are made up of sine waves at the fundamental frequency and an infinite number of odd harmonics), and typically, for 500 MHz bandwidths and below, oscilloscopes have a Gaussian frequency response. SMO1000E/SMO1000U 54/234...

  • Page 55: Memory Depth

    Since the SMO1000E series scope has two acquisition memories, when only one channel is on, the maximal memory depth is up to 14 Mpts. SMO1000U has only one acquisition memory, when only one channel is on, the maximal memory depth is up to 14 Mpts.

  • Page 56: Sampling Mode

    Scientific The maximum storage depth in single channel mode is twice that in dual channel mode as shown in following table: SMO1000E SMO1000U Single Dual Single Dual Three or Four Channel Mode Channel Mode Channel Mode Channel Mode Channel Mode 3.5k...
  • Page 57 When the sampling rate is 3 to 5 times the bandwidth of the system. Recommended Sinx/s interpolation method. Figure 19 Display Type Set to Dots Figure 20 x Interpolation SMO1000E/SMO1000U 57/234...

  • Page 58: Acquisition Mode

    6.6.1 Normal In this mode, the oscilloscope samples the signal at equal time interval to rebuild the waveform. For most of the waveforms, the best display effect can be obtained using this mode. It is the default acquisition mode. SMO1000E/SMO1000U 58/234...

  • Page 59: Peak Detect

    In this mode, signal confusion can be prevented but the noise displayed would be larger. In this mode, the oscilloscope can display all the pulses with pulse widths at least as wide as the sample period. Figure 23 Pulse With 0.1% Duty, Normal Mode SMO1000E/SMO1000U 59/234...

  • Page 60: Average

    The available range of averages is from 4 to 1024 and the default is 16. When Average mode is selected, press Averages and turn the universal knob or press the softkey continually to set the desired average time. Figure 25 With Random Noise, Normal Mode SMO1000E/SMO1000U 60/234...

  • Page 61: Eres

    This mode limits the oscilloscope's real- time bandwidth because it effectively acts like a low- pass filter. Note: “Average” and “High Res” modes use different averaging methods. The former uses “Waveform Average” and the latter uses “Dot Average”. SMO1000E/SMO1000U 61/234...

  • Page 62: Horizontal Format

    According to sinθ=A/B or C/D (wherein, θ is the phase deviation angle between the two channels and the definitions of A, B, C and D are as shown in the figure above), the phase deviation angle is obtained, that is: θ=±arcsin (A/B) or ±arcsin (C/D) SMO1000E/SMO1000U 62/234...

  • Page 63: Use Sequence Mode

    1. Press the Acquire button on the front panel to enter the ACQUIRE function menu; 2. Press the Sequence softkey to enter the SEQUENCE function menu. Figure 27 SEQUENCE Function Menu 3. Press the Segments Set softkey; and then turn the Universal Knob to select the desired value. SMO1000E/SMO1000U 63/234...
  • Page 64 4. Press the softkey to replay the waveform from the current frame to 1. 5. Press the softkey to stop replay. 6. Press the softkey to replay the waveform from the current frame to the last frame. SMO1000E/SMO1000U 64/234...

  • Page 65: Trigger

    These trigger types are edge, slope, pulse, video, window, interval, dropout, runt, pattern and serial trigger. This chapter will mainly introduce all these trigger functions which mentioned above in details and tell you how to set the trigger conditions to capture desired waveform. SMO1000E/SMO1000U 65/234...
  • Page 66 Scientific The contents of this chapter: Trigger Source Trigger Mode Trigger Level Trigger Coupling Trigger Holdoff Noise Rejection Trigger Type Edge Trigger Slope Trigger Pulse Trigger Video Trigger Window Trigger Interval trigger DropOut Trigger Runt Trigger Pattern Trigger SMO1000E/SMO1000U 66/234...

  • Page 67: Trigger Source

    (power supply device). For example, it is mainly used in related measurement of the power industry to stably trigger the waveform output from the transformer of a transformer substation. Note: to select stable channel waveform as the trigger source to stabilize the display. SMO1000E/SMO1000U 67/234...

  • Page 68: Trigger Mode

    To capture single event or aperiodic signal. To capture burst or other unusual signals. Note: You can force the oscilloscope to trigger by pressing the Single button twice. The trigger status in the upper left corner of the screen will be displayed as "FStop". SMO1000E/SMO1000U 68/234...

  • Page 69: Trigger Level

    The position of the trigger level for the analog channel is indicated by the trigger level icon (If the analog channel is on) at the left side of the display. The value of the analog channel trigger level is displayed in the upper- right corner of the display. SMO1000E/SMO1000U 69/234...

  • Page 70: Trigger Coupling

    Use LF Reject coupling to get a stable edge trigger when your waveform has low frequency noise. HF Reject: reject the high frequency components higher 1.27MHz) Note: trigger coupling has nothing to do with the channel coupling. SMO1000E/SMO1000U 70/234...

  • Page 71: Trigger Holdoff

    2. Press the Setup button on the front panel to enter the TRIGGER function menu. The default trigger type is edge. 3. Press the Holdoff Close softkey; and then turn the Universal Knob to set the desired holdoff time. Note: adjust the time scale and horizontal position will not affect the holdoff time. SMO1000E/SMO1000U 71/234...

  • Page 72: Noise Rejection

    Press the Setup button on the front panel, and then press the Noise Reject softkey continually to set the option to On or Off to turn on or off the noise rejection function. Figure 29 Turn off the Noise Reject SMO1000E/SMO1000U 72/234...
  • Page 73 1. Connect a signal to the oscilloscope and obtain a stable display. 2. Remove the noise from the trigger path by setting trigger coupling to LF Reject, HF Reject or turning on Noise Reject. 3. Set the Acquisition option to Average to reduce noise on the displayed waveform. SMO1000E/SMO1000U 73/234...

  • Page 74: Trigger Type

    Scientific 7.7 Trigger Type The oscilloscope provides abundant advanced trigger functions, including various serial bus triggers. Edge trigger Slope trigger Pulse trigger Video trigger Window trigger Interval trigger DropOut trigger Runt trigger Pattern trigger SMO1000E/SMO1000U 74/234...

  • Page 75: Edge Trigger

    Turn the Trigger Level Knob to adjust the trigger level to obtain stable trigger. Figure 31 Edge Trigger Note: Press the Auto Setup button will set the trigger type to Edge and slope to rising. SMO1000E/SMO1000U 75/234...

  • Page 76: Slope Trigger

    Trigger Level Knob to adjust the position. The trigger level values are displayed at the upper right corner of the screen. The lower trigger level cannot be upper than the upper trigger level. In the trigger state message box, L1 means the upper trigger lever while L2 means the lower trigger level. SMO1000E/SMO1000U 76/234...
  • Page 77 Coupling and noise reject can be set in slope trigger, see the sections "Trigger Coupling" and "Noise Rejection" for details. SMO1000E/SMO1000U 77/234...

  • Page 78: Pulse Trigger

    >= (greater than a time value): trigger when the positive or negative pulse time of the input signal is greater than the specified time value. For example, for a positive pulse, if you set t (pulse real width) >100ns, the waveform will trigger. SMO1000E/SMO1000U 78/234...
  • Page 79 --][-- (outside a range of time value): trigger when the positive or negative pulse time of the input signal is greater than the specified upper limit of time and lower than the specified lower limit of time value. Figure 33 Pulse Trigger SMO1000E/SMO1000U 79/234...

  • Page 80: Video Trigger

    25Hz, 30Hz, 50Hz, 60Hz Of Lines 300~2000 Of Fields 1, 2, 3, 4 Interlace 1:1, 2:1, 4:1, 8:1 Trigger Position Line Field (line value)/1 (line value)/2 (line value)/3 (line value)/4 (line value)/5 (line value)/6 (line value)/7 (line value)/8 SMO1000E/SMO1000U 80/234...
  • Page 81 Press the Sync softkey and set the option to Select; press the Line softkey and then turn the universal to select 022 and push the knob to confirm; press the Field softkey and then turn the Universal Knob to select 1 and push the knob to confirm SMO1000E/SMO1000U 81/234...
  • Page 82 Press the Type softkey to select Select or Any. If the Type option set to Select, press the Line softkey; turn the Universal Knob to select the desired value. Press the Field softkey; turn the Universal Knob to select the desired value. SMO1000E/SMO1000U 82/234...

  • Page 83: Window Trigger

    Level Knob to adjust the position. The trigger level values are displayed at the upper right corner of the screen. The Lower trigger level cannot be upper than the upper trigger level. In the trigger state message box, L1 means the upper trigger level while L2 means the lower trigger level. SMO1000E/SMO1000U 83/234...
  • Page 84 In the trigger state message box, C means Center, the center value of the lower and upper trigger levels; D means Delta, the difference between the lower (or upper) trigger level and the trigger level center. SMO1000E/SMO1000U 84/234...
  • Page 85 Scientific Figure 36 Relative Window Trigger Coupling and noise reject can be set in Window trigger, see the sections "Trigger Coupling" and "Noise Rejection" for details. SMO1000E/SMO1000U 85/234...

  • Page 86: Interval Trigger

    6. Press the Time Setting softkey (<=, >=, [--,--],--][--), turn the Universal Knob to select the desired value. SMO1000E/SMO1000U 86/234...
  • Page 87 Scientific Figure 37 Interval Trigger Coupling and noise reject can be set in interval trigger, see the sections "Trigger Coupling" and "Noise Rejection" for details. SMO1000E/SMO1000U 87/234...

  • Page 88: Dropout Trigger

    Select channel with signal input as trigger source to obtain stable trigger. 4. Press the Slope softkey to select rising or falling edge. 5. Press the OverTime Type softkey to select Edge. 6. Press the Time softkey; turn the universal to select the desired value. SMO1000E/SMO1000U 88/234...
  • Page 89 3. Press the Source softkey; turn the Universal Knob to select CH1 or CH2 as the trigger source. 4. Press the Slope softkey to select rising or falling edge. 5. Press the OverTime Type softkey to select State. 6. Press the Time softkey; turn the Universal Knob to select the desired value. SMO1000E/SMO1000U 89/234...
  • Page 90 Scientific Figure 39 State DropOut Trigger Coupling and noise reject can be set in dropout trigger, see the sections "Trigger Coupling" and "Noise Rejection" for details. SMO1000E/SMO1000U 90/234...

  • Page 91: Runt Trigger

    Press the Next Page softkey to enter the second page of the TRIGGER system function menu. Press the Lower Upper softkey to select Lower or Upper trigger level, and the turn the Universal Knob to set the position. SMO1000E/SMO1000U 91/234...
  • Page 92 Scientific Figure 40 Runt Trigger Coupling and noise reject can be set in runt trigger, see the sections "Trigger Coupling" and "Noise Rejection" for details. SMO1000E/SMO1000U 92/234...

  • Page 93: Pattern Trigger

    Adjust the trigger level for the selected analog channel by turning the Trigger Level knob. Invalid doesn’t need to set trigger level. Press the Next Page softkey to enter the second page of the pattern trigger menu. SMO1000E/SMO1000U 93/234...
  • Page 94 Press the Holdoff Close softkey to turn on the Holdoff function; then turn the Universal Knob to select the desired value. Figure 41 Pattern Trigger Holdoff can be set in pattern trigger, see the sections "Trigger Holdoff" for details. SMO1000E/SMO1000U 94/234...

  • Page 95: Serial Trigger And Decode

    This chapter introduces the method of triggering and decoding these serial signals in details. The contents of this chapter: I2C Trigger and Decoder SPI Trigger and Decoder UART/RS232 Trigger and Decoder CAN Trigger and Decoder LIN Trigger and Decoder SMO1000E/SMO1000U 95/234...

  • Page 96: I2C Trigger And Serial Decode

    (Tips: SDA should keep stable during the whole high clock cycle, otherwise it will be interpreted as a start or stop condition (data transitioning while the clock is high).) 7. Press softkey to return previous menu. SMO1000E/SMO1000U 96/234...

  • Page 97: I2C Triggering

    Limit Range softkey to set the qualifier and Data1 softkey to set the data’s value. If EEPROM’s data is greater(less, equal) than Data1, the oscilloscope will be triggered at the edge of ACK bit behind Data byte. It’s unnecessary that the Data byte musts follow the EEPROM. SMO1000E/SMO1000U 97/234...
  • Page 98 If you have set both Data1’s and Data2’s value, the signal should has two consecutive data, the first data’s value is Data1, second data value is Data2. (Note: If the set value is 0xXX, any data value will be matched) SMO1000E/SMO1000U 98/234...
  • Page 99 Press the Addr softkey and turn the Universal Knob to select the 7- bit or 10-bit device address. Press the Data1 or Data2 softkey and set the value about them. Press The R/W bit softkey and select write-frame or read-frame to trigger the oscilloscope. SMO1000E/SMO1000U 99/234...

  • Page 100: I2C Serial Decode

    "Decoding to maximum frame number limitation!" Interpreting I2C Decode The frames of decoding result: The address value is displayed at the beginning of a frame. The write address is displayed in green, and read address in yellow. SMO1000E/SMO1000U 100/234...
  • Page 101 TIME — the horizontal displacement between current frame and trigger position. ADDRESS — the address of a frame. R/W — the type of a frame (write or read). DATA — the value of data. Figure 46 I2C Decode List Display SMO1000E/SMO1000U 101/234...

  • Page 102: Spi Triggering And Serial Decode

    Press softkey to return previous menu. Figure 48 SPI CLK Menu Set MISO: Press the MISO softkey to enter the MISO menu. Press the MISO softkey to select the channel that is connected to the SPI MISO signal. SMO1000E/SMO1000U 102/234...
  • Page 103 The range of clock timeout is 100ns-5ms. Timeout This setting is suitable for case where CS signal is not connected, or the number of oscilloscope channel is insufficient (such as 2 channel scope) Table 1 Menu Explanations of the Cs Type Parameters SMO1000E/SMO1000U 103/234...
  • Page 104 CS signal shown in the screen: When the CS type is set to Clock Timeout, the clock idle time between frames is T3, the clock period is T1, then set the timeout to a value between T1 and T3 ： SMO1000E/SMO1000U 104/234...

  • Page 105: Spi Triggering

    4. Press Trigger Setting softkey. Figure 51 SPI TRIG SET Menu Press the Trigger Type softkey to select the trigger condition. Function Settings Explanation Menu MISO Master-In, Slave-Out Trigger Type MOSI Master-Out, Slave-In Table 2 Menu Explanations of the SPI trigger type SMO1000E/SMO1000U 105/234...

  • Page 106: Spi Serial Decode

    Users can export the result list of the package to the external USB storage device in csv format (only when the USB flash disk is detected). Saving the data (*.csv) is similar to the operation of setup files, see the section "External save and recall" for details. SMO1000E/SMO1000U 106/234...
  • Page 107 The lists of decoding result: TIME (timestamp) — the horizontal displacement between current frame and trigger position. MISO — the decoding result of “Master-In, Slave-Out” line. MOSI —the decoding result of “Master-Out, Slave-In” line. Figure 52 SPI Decode List Display SMO1000E/SMO1000U 107/234...

  • Page 108: Uart Trigger And Serial Decode

    Press softkey to return previous menu. Press the Configure softkey to enter BUS CONFIG menu. Figure 55 BUS CONFIG Menu Press Baud softkey to set baud rate. The baud rate can be set as predefined value. SMO1000E/SMO1000U 108/234...

  • Page 109: Uart Triggering

    Press the Value softkey to set data’s value. Data’s value is in range of 0x00 to 0xff. ERROR — if the parity check has been set, and the bit of parity check is error, the oscilloscope will be triggered. SMO1000E/SMO1000U 109/234...

  • Page 110: Uart Serial Decode

    Press the Copy Setting to enter the COPY function menu to synchronize the corresponding bus configuration and trigger configuration. Press the Tips Info to turn on or off the decoding limit prompt. When the decoding frame number reaches the maximum, it will pop up "Decoding to maximum frame number limitation!" SMO1000E/SMO1000U 110/234...
  • Page 111 TIME — the horizontal displacement between current frame and trigger position. RX — the receiving channel. TX — the transmitting channel. RX Err— Parity error or unknown error in the data received. TX Err— Parity error or unknown error in the data transmitted. SMO1000E/SMO1000U 111/234...
  • Page 112 Scientific Figure 60 UART Decode List Display SMO1000E/SMO1000U 112/234...

  • Page 113: Can Trigger And Serial Decode

    The baud rate can be set as predefined value(from 5kb/s to 1Mb/s) or custom value (from 5kb/s to 1Mb/s). • If the desired baud rate is not listed, press Baud and select custom option, press the Custom and turn the Universal Knob to set the desired baud rate. SMO1000E/SMO1000U 113/234...

  • Page 114: Can Triggering

    Press Curr ID Byte softkey and use Universal Knob to select the byte that you want to modify. c. Press the ID softkey and set the ID’s value by Universal Knob. d. Press Data softkey and set the value of the first byte by Universal Knob. SMO1000E/SMO1000U 114/234...

  • Page 115: Can Serial Decode

    7. Press the Tips Info to turn on or off the decoding limit prompt. When the decoding frame number reaches the maximum, it will pop up "Decoding to maximum frame number limitation!" SMO1000E/SMO1000U 115/234...
  • Page 116 (11 bits or 27 bits). LENGTH — the length of data field. DATA — the value of data field. CRC — the value of CRC (Cyclic Redundancy Check) field. ACK — Acknowledgment bit. Figure 64 CAN Decode List Display SMO1000E/SMO1000U 116/234...

  • Page 117: Lin Triggering And Serial Decode

    Break — The oscilloscope will be triggered at the position of break field’s break delimiter. ID (Frame ID) — The oscilloscope will be triggered at the position of identifier field’s stop bit, if the value of a frame’s ID is equal to specified value. SMO1000E/SMO1000U 117/234...
  • Page 118 Press ID softkey and set its value by turning the Universal Knob. b. Press DATA1 softkey and set its value by turning the Universal Knob. c. Press DATA2 softkey and set its value by turning the Universal Knob. SMO1000E/SMO1000U 118/234...

  • Page 119: Lin Serial Decode

    "External save and recall" for details. 5. Press Format to change the character encoding format of the decoding’s result. 6. Press the Copy Setting to enter the COPY function menu to synchronize the corresponding bus configuration and trigger configuration. SMO1000E/SMO1000U 119/234...
  • Page 120 TIME — the horizontal displacement between current frame and trigger position. ID — the value of frame’s Protected Identifier Field. Data length — the length of Data Field. ID Parity — the two check bits of Protected Identifier Field. SMO1000E/SMO1000U 120/234...
  • Page 121 Scientific DATA — the value of Data Field. Checksum — the value of Checksum Field. Figure 69 LIN Decode List Display SMO1000E/SMO1000U 121/234...

  • Page 122: Reference Waveform

    Four reference waveforms can be displayed at a time. The contents of this chapter: To Save REF Waveform to Internal Memory To Display REF Waveform To Adjust REF Waveform Display To Clear REF Waveform Display SMO1000E/SMO1000U 122/234...

  • Page 123: Save Ref Waveform To Internal Memory

    3. Press the Display softkey to select On to display the REF waveform on the screen. Only saved location can be displayed. The oscilloscope can display all four reference waveforms at a time. SMO1000E/SMO1000U 123/234...

  • Page 124: Adjust Ref Waveform

    The oscilloscope does not have the “Clear” option under the REF WAVE function menu. To clear the appointed reference waveform, you can save a new reference waveform to the same location to cover it. Or follow the Save/Recall→Recall→type and select Security Erase to clear the stored waveform. SMO1000E/SMO1000U 124/234...

  • Page 125: Math Function

    Math Operators To Adjust the Math Waveform Scale and Offset Note: if the analog channel or the math function is cut off (waveforms do not display on the screen completely), the resulting math will also be cut off. SMO1000E/SMO1000U 125/234...

  • Page 126: Units For Math Waveforms

    2, A 2 or W (Volt-Amp) SMO1000E: None, (Resistance unit Ohms) or S (Conductance unit Siemens) division (/) SMO1000U: None, V*A^-1 or V^-1*A dBVrms, Vrms, dBm, dBArms, Arms SMO1000E: V/S or A/S (V/second or A/second) differential (d/dt) SMO1000U V *S^-1or A*S^-1 ：...

  • Page 127: Math Operators

    The resulting math waveform is displayed in white and labeled with “M”. Figure 71 C1+C2 Waveform 4. If you want to invert the math waveform, press the Invert button and set the option to On to invert the display of the math waveform. SMO1000E/SMO1000U 127/234...

  • Page 128: Multiplication And Division

    The resulting math waveform is displayed in white and labeled with “M”. Figure 72 C1*C2 Waveform 4. If you want to invert the math waveform, press the Invert button and set the option to On to invert the display of the math waveform. SMO1000E/SMO1000U 128/234...

  • Page 129: Fft Operation

    Spectral leakage can be considerably decreased when a window function is used. The oscilloscope provides five windows ( Rectangle, Blackman, Hanning, Hamming and Flattop) which has different characteristics and are applicable to measure different waveforms. You need to select the window function according to different waveforms SMO1000E/SMO1000U 129/234...
  • Page 130 Exclusive: Only the frequency-domain waveform is displayed. • Press the Mode softkey to select Normal, Max-Hold or Average. When you select Average, it is necessary to set the average times. Press the Vertical softkey to enter VERTICAL menu. SMO1000E/SMO1000U 130/234...
  • Page 131 Press the Sort By softkey continuously to set the table sorting by Amplitude or Frequency. • Press the Search Config softkey to set search configuration. Figure 78 SEARCH Menu SMO1000E/SMO1000U 131/234...
  • Page 132 Frequency softkey to show the frequency value of the markers, and press the Show Delta softkey to show the delta amplitude between markers. The following figure shows the FFT waveform displayed on the split screen and the peak tool is turned on: SMO1000E/SMO1000U 132/234...
  • Page 133 ( Y). You can find the frequency value at the first occurrence of the waveform maximum by using the X at Max Y measurement. Note: please refer to the cursors chapter to obtain the method of using cursors. SMO1000E/SMO1000U 133/234...

  • Page 134: Math Function Operation

    The oscilloscope has 50 pixel points per division. Take 0.2div as an example: 0.2*50=10. It means to calculate the ten point’s discrete time derivative of the selected source, and the t is the ten point’s point- to- point time difference. Figure 82 Differential Function Operation SMO1000E/SMO1000U 134/234...
  • Page 135 Small DC offset in the integrate function input (or even small oscilloscope calibration errors) can cause the integrate function output to "ramp" up or down. This DC offset correction lets you level the integrate waveform. SMO1000E/SMO1000U 135/234...
  • Page 136 Scientific Figure 83 Integral without Offset Integral with Offset Figure 84 SMO1000E/SMO1000U 136/234...
  • Page 137 Scientific Square Root Square root (√) calculates the square root of the selected source. Where the transform is undefined for a particular input, holes (zero values) appear in the function output. Figure 85 Square Root SMO1000E/SMO1000U 137/234...

  • Page 138: Cursors Measurements

    Y1 and Y2 ( Y ). △ When set cursor type to Y2-Y1, use Universal Knob will move the Y1 and Y2 cursors together. The value under the menu option is the difference between the Y1 and Y2 cursors. SMO1000E/SMO1000U 138/234...

  • Page 139: Make Cursor Measurements

    Transparence (20% to 80%) softkey and then turn the Universal Knob to adjust the transparence to the desired value. Cursor examples: Use cursors to measure pulse width: Figure 86 Measure Pulse Width SMO1000E/SMO1000U 139/234...

  • Page 140: Measure

    Delay parameters are under the All Measure submenu. Set the Delay option to On to display all the delay parameters. The contents of this chapter: Type of measurements Automatic measurement Clear measurements All measurement Gate measurement SMO1000E/SMO1000U 140/234...

  • Page 141: Type Of Measurement

    12. Cycle RMS: Root mean square of all data values in the first cycle. 13. Overshoot: Overshoot is distortion that follows a major edge transition expressed as a percentage of Amplitude. ROV means rising edge overshoot and FOV means falling edge overshoot. SMO1000E/SMO1000U 141/234...
  • Page 142 Amplitude. The X cursors show which edge is being measured (edge closest to the trigger reference point). Figure 89 Preshoot 15. Level@X: the voltage value between the trigger point and the vertical position of the channel SMO1000E/SMO1000U 142/234...

  • Page 143: Time Measurements

    8. Delay ： ： ： ： Time from the trigger to the first transition at the 50% crossing. 9. T@L ： ： ： ： Time from trigger of each transition at a specific level and slope, include: Current, Max, Min, Mean, Std-dev. SMO1000E/SMO1000U 143/234...

  • Page 144: Delay Measurements

    FFLR: Time from the first falling edge of channel A to the last rising edge of channel B. FFLF: Time from the first falling edge of channel A to the last falling edge of channel B. 10. Skew: Time of source A edge minus time of nearest source B edge. SMO1000E/SMO1000U 144/234...

  • Page 145: Automatic Measurement

    The measurement display area can display 4 measurement parameters at most, and the measurements will arrange according to the selecting order. If add a fifth measurement parameter, it will delete the first measurement. Figure 91 Select the Measurement Parameter SMO1000E/SMO1000U 145/234...
  • Page 146 Scientific Figure 92 Added the Measurement Note: if the parameter does not match the measure condition, it will display as “****”. SMO1000E/SMO1000U 146/234...

  • Page 147: Clear Measurement Parameters

    Scientific 12.3 Clear Measurement Parameters SMO1000E (4-channel) supports selective clearing of measurement parameters that are displaying on the screen. SMO1000E (2 channel) and SMO1000U only support one key to clear all measurement items. Figure 93 Clear Measurement Press the Clear softkey to call up the clear measurement box. Rotate and press the Universal Knob to clear a measurement or all measurement.

  • Page 148: Make All Measurement

    Do the following steps to make all parameters measurement. Press the Measure button on the front panel to enter the MEASURE function menu. Press the All Measure softkey to select On. Press the Source softkey to select the measure source. SMO1000E/SMO1000U 148/234...

  • Page 149: Gate Measurement

    Scientific 12.5 Gate Measurement The SMO1000E/SMO1000U support gate measurement and perform the selected measurement within the upper and lower limits of the gate. Setting the gate will affect the measurement of all voltage, time, and delay parameters. Press Measure→Gate→On to open the gate measurement.

  • Page 150: Display Setting

    The contents of this chapter: To Set Display Type To Set Color Grade To Set and Clear Persistence To Clear the Display To Select Grid Type To Adjust the Waveform Intensity To Adjust the Grid Brightness The Adjust the Transparence SMO1000E/SMO1000U 150/234...

  • Page 151: Display Type

    Dots: display the sample points directly. You can directly view each sample point and use the cursor to measure the X and Y values of the sample point. Figure 96 Vectors Display Figure 97 Dots Display SMO1000E/SMO1000U 151/234...

  • Page 152: Color Display

    Color Grade softkey and set the option to On to turn on the color temperature function. You can compare the waveform’s color with the picture below to just the probability that the waveform appears. Cold Color Warm Color Figure 98 Color Temperature SMO1000E/SMO1000U 152/234...

  • Page 153: Persistence

    3. When the Persist is On, to erase the results of previous acquisitions from the display, press the Clear Persist softkey. The oscilloscope will start to accumulate acquisitions again. 4. To return to the normal display mode, turn off persist and the previous acquisitions will be clear at once. SMO1000E/SMO1000U 153/234...

  • Page 154: Clear Display

    Increasing the intensity lets you see the maximum amount of noise and infrequently occurring events. Reducing the intensity can expose more detail in complex signals as shown in the following figures. Note: Waveform intensity adjustment affects analog channel waveforms only (not math waveforms, reference waveforms, digital waveforms, etc.). SMO1000E/SMO1000U 154/234...

  • Page 155: Grid Brightness

    2. Press the Next Page softkey to go to the second page of the Display function menu. 3. Press the Transparence softkey; and then turn the Universal Knob to select the desired value. The default value is 80%, and the range is from 20% to 80%. SMO1000E/SMO1000U 155/234...

  • Page 156: Save And Recall

    The oscilloscope provides an USB Host interface on the front panel to connect an USB device for external storage. The contents of this chapter Save Type Internal Save and Recall External Save and Recall Disk Management SMO1000E/SMO1000U 156/234...

  • Page 157: Save Type

    The recall of CSV file is not supported. Set the save type to CSV, and set the Para Save option to On or Off to turn on or of the parameters storage function. SMO1000E/SMO1000U 157/234...
  • Page 158 The recall of Matlab file is not supported. 9. To Default Key The oscilloscope saves the factory config and user set config. Then you can select the default function is the factory config or user set config SMO1000E/SMO1000U 158/234...

  • Page 159: Internal Save And Recall

    Press the Press to Recall softkey to recall the current setup form the appointed location. After a few seconds, it will pop-up the message “Recalled file successfully!” Note: if need to delete a setup file in the memory, please save a new setup to the same location to overwrite it. SMO1000E/SMO1000U 159/234...

  • Page 160: External Save And Recall

    Press the Press to Save softkey to enter the SAVE/RECALL file system. Figure 100 SAVE/RECALL File System Use the Universal Knob to select the desired location. File can be stored under the root directory or in a certain folder under the root directory of the USB storage device. SMO1000E/SMO1000U 160/234...
  • Page 161 Refer to the descriptions in “To Create a new file or fold” to create a new file name. Figure 102 File Name Dialogue Press the Press to Save softkey to save the current setup to the external USB storage device, SMO1000E/SMO1000U 161/234...
  • Page 162 Press the Recall from softkey to select External. Press the Press to Recall softkey to enter the SAVE/RECALL file system. Turn the Universal Knob to select the file to be recalled, press the Press to Recall softkey to recall the reference or setup. SMO1000E/SMO1000U 162/234...

  • Page 163: Disk Management

    USB storage device. Before using external disk, make sure that the USB storage device is connected correctly. Execute the following operations through the disk management menu: To Create a New File or Folder To Delete a File or Folder To Rename a File or Folder SMO1000E/SMO1000U 163/234...

  • Page 164: Create A New File Or Folder

    Name Input Area Keyboard Area Figure 103 Input Keyboard 5. To delete the name in the name input area, press the Backspace softkey continuously to delete the character one by one. SMO1000E/SMO1000U 164/234...

  • Page 165: Delete A File Or Folder

    3. Press the Press to Save or Press to Recall softkey to enter the SAVE/RECAL file system. 4. Turn the Universal Knob to select the file or folder to be rename, and then press the Rename softkey. For details, see the instructions in "Create a New File or Folder." SMO1000E/SMO1000U 165/234...

  • Page 166: Digital Channels (Option)

    Connect the Digital Probes • Acquire Digital Waveform • Digital Channels Height • Digital Channels Position • Single Digital Channel • All Digital Channels • Logic Threshold • Digital Bus • Deskew • System Setting • Remove Device SMO1000E/SMO1000U 166/234...

  • Page 167: Connect The Digital Probes

    The green indicator: When the SLA1016is connect to the oscilloscope, this indicator turns on for seconds then turns off, and then blinks, and finally keeps the light on. When data is transferred between the SLA1016 and the oscilloscope, the indicator blinks. SMO1000E/SMO1000U 167/234...

  • Page 168: Acquire Digital Waveform

    15.3 Digital Channels Height Press the Digital button on the front panel to open the DIGITAL function menu. Figure 104 Digital Interface menu Press the Channel High softkey to select Low, Middle, High display type. Figure 105 Middle Display Type SMO1000E/SMO1000U 168/234...

  • Page 169: Digital Channels Position

    Press the Channel Control softkey, then turn the Universal Knob to select the desired channel such as Dx and push down the knob to confirm. Press the Dx softkey to select On or Off to switch the selected channel on or off. SMO1000E/SMO1000U 169/234...

  • Page 170: All Digital Channels

    Values greater than the set threshold are high (1) and values less than the set threshold are low (0). • If the D0~D7or D8~D15softkey is set to Custom, press the Custom softkey, then turn the Universal Knob to select the desired value and push down the knob to confirm. SMO1000E/SMO1000U 170/234...

  • Page 171: Digital Bus

    • Under the DIGITAL function menu, press the System Display softkey to select Binary or Hex to display the bus values. The Sampling rate of digital channels is displayed at the right of the display. SMO1000E/SMO1000U 171/234...

  • Page 172: Deskew

    Figure 109 Digital Bus 15.9 Deskew Press the Digital button on the front panel to open the DIGITAL function menu and display the digital channel waveforms. Press the Deskew softkey, and then turn the Universal Knob to select to change Deskew. SMO1000E/SMO1000U 172/234...

  • Page 173: System Setting

    Then a message “USB Flash Drive detected! “will be displayed. Press Digital→NextPage2/2→System→Update Expand the U disk directory, Select the firmware file (*.ads), then press the Press to update, an upgrade progress bar will be display on the interface. SMO1000E/SMO1000U 173/234...

  • Page 174: Remove Device

    “Update completed, please reconnect Digital device!” Note: Don't cut off the power during the Digital device is being updated ！ 15.11 Remove Device Press Digital→NextPage2/2→Remove Device and the oscilloscope interface display "Digital device removed!", the device can be pulled. SMO1000E/SMO1000U 174/234...

  • Page 175: System Function Setting

    To do Pass/Fail Test Arbitrary Waveform generator (Option) IO Set Web Server Counter Data Logger To Update Firmware or configuration To Do self Test To Specify the Screen Saver Time Date/Time Reference Position Power On line Option management SMO1000E/SMO1000U 175/234...

  • Page 176: View The System Status

    Product Type: display the product type of the oscilloscope. Serial NO.: list the serial number of the oscilloscope. Scope ID: display the scope identification of the oscilloscope. Figure 112 System Status 3. Press the Single button on the front panel to exit. SMO1000E/SMO1000U 176/234...

  • Page 177: Do Self Calibration

    3. Press the Single button on the front panel to perform the self calibration program. During the calibration, most of the keys are disabled. 4. When the self-calibration program is finished, it will pop-out the message “press Run/Stop key to exit”. Press the Run/Stop button on the front panel to exit the calibration interface. SMO1000E/SMO1000U 177/234...

  • Page 178: Quick-Cal

    2. Press the Language softkey; and then turn the Universal Knob to select the desired language. Then push down the knob to select the language. The languages that currently available are Simplified Chinese, Traditional Chinese, English, French, German, Spanish, Russian, Italian, and Portuguese. SMO1000E/SMO1000U 178/234...

  • Page 179: Pass/Fail Test

    2. Press the Next Page softkey to go to the second page of the UTILITY function menu. 3. Press the Pass/Fail softkey to enter the PASS/FAIL function menu. 4. Press the Enable Test softkey to select On to enable the pass/ fail test. 5. Press the Source softkey to select the desired channel. SMO1000E/SMO1000U 179/234...
  • Page 180 14. Press the Next Page softkey to return to the first page of the PASS/FAIL function menu. 15. Press the Operate softkey to perform the test. : Current state is stop; press the softkey to start the pass/fail test. : Current state is running; press the softkey to stop the pass/fail test. SMO1000E/SMO1000U 180/234...

  • Page 181: Save And Recall Test Mask

    6. Press the Location softkey to select Internal. 7. Press the Load softkey to recall the saved interval memory. 8. A few second later, it will pop-out the message “Recalled Successfully!” and the saved mask will be displayed on the screen. SMO1000E/SMO1000U 181/234...
  • Page 182 6. Press the Location softkey to select External 7. Press the Load softkey to enter the file SAVE/RECALL system. 8. Select the desired test mask file with a RGU postfix using the Universal Knob; and then press the Load softkey. SMO1000E/SMO1000U 182/234...

  • Page 183: Arbitrary Waveform Generator(Option)

    Math, Engine, Window, and Trigo. Users may also edit the arbitrary waveform by PC which has installed the EasyWave, or import the waveform by U disk that had stored edited waveform. The contents of this chapter: Output Wave Setting System Remove Device SMO1000E/SMO1000U 183/234...

  • Page 184: Output

    Then press the knob to select the interface shown as below: Figure 116 Wave Type Interface The following table shows the waveform type and its corresponding characteristics. According to the selected waveform, to set the waveform parameters through Universal Knob and the corresponding function software under the menu. SMO1000E/SMO1000U 184/234...
  • Page 185 Built-in Arb Choose WaveType→Arb→ArbType→Built-in to enter the following interface, Rotate the knob to move the cursor, press the knob to select to the desired waveform and then return back to Built-in waveform interface. SMO1000E/SMO1000U 185/234...

  • Page 186: Setting

    [Aux In/Out] connector on the rear panel. When the Sync Output is on, the port can output a CMOS signal with the same frequency as basic waveforms (except the Noise and DC), arbitrary waveforms, and modulated waveforms (except external modulation). SMO1000E/SMO1000U 186/234...
  • Page 187 Press the Manual and rotate the knob to adjust the waveform, so that the mean value of the observed CH2 will be in the range of ±1mv, and then press the Save, the oscilloscope displays "Zero Adjust Success!". SMO1000E/SMO1000U 187/234...

  • Page 188: System

    Then a message “USB Flash Drive detected!” will be displayed. Press Utility→NextPage4/4→AWG→System→Update. Expand the U disk directory, Select the firmware file (*.ads), then press the Press to update, an upgrade progress bar will be display on the interface. SMO1000E/SMO1000U 188/234...

  • Page 189: Remove Device

    “Update completed, please reconnect AWG device!” Note D on't cut off the power during the AWG is being updated ： ！ 16.7.5 Remove Device Press Utility→NextPage4/4→AWG→Remove Device and the oscilloscope interface display "AWG device removed!", the device can be pulled. SMO1000E/SMO1000U 189/234...

  • Page 190: Io Set

    3. Press the IO Set softkey to enter the I/O SET function menu. 4. Press the Net Inerfacing softkey, then select LAN. 5. Press the IP Set softkey to softkey to enter the IP setting interface, see the picture below: Figure 121 LAN Setting Interface SMO1000E/SMO1000U 190/234...

  • Page 191: Wlan

    Press Connect softkey when your SSID and PSK configuration finished. Return to the I/O SET menu. Press the IP Set softkey to finish the IP configuration (see “To Set the LAN”) Use EasyScopeX or NI Vista to communicate with the oscilloscope. SMO1000E/SMO1000U 191/234...

  • Page 192: Webserver

    SMO1000E (4-channel) provide the web server function; you can access and control the oscilloscope using a web browser. Connect the oscilloscope to your LAN (or WLAN), then type the oscilloscope's IP address in the web browser. The oscilloscope's web interface is displayed. Figure 123 WEB Server Interface SMO1000E/SMO1000U 192/234...

  • Page 193: Set Password

    Reset: press this softkey to reset the password. Save: After setting a new password, press this softkey to make the password effective. 16.9.2 Web Browser Input the IP address of the instrument Information of the instrument Click here to enter the instrument control interface. SMO1000E/SMO1000U 193/234...
  • Page 194 Click here to save the waveform data as a bin file and download it to the local computer Click here to download the mini tool for converting bin file to csv file Click here to perform a firmware upgrade SMO1000E/SMO1000U 194/234...

  • Page 195: Counter

    Press the Statistics softkey to turn on or off statistics. Press the Reset Statistics softkey to clear and restart the statistics. Press Next Page1/2→Level, turn the Universal Knob to set the level of the counter. Figure 124 Counter Setting Interface SMO1000E/SMO1000U 195/234...
  • Page 196 When the gate type is level, set the polarity (Positive or Negative) of the gate source. When the gate type is edge, set the slope (Rising or Falling edge) of the gate source. 5 Press the Level softkey and turn the Universal Knob to set the gate level. SMO1000E/SMO1000U 196/234...
  • Page 197 Max: The maximum of all historical counts Stdev: The standard deviation of all historical counts, used to judge the distribution of historical count parameters Count: Number of counts obtained Press the Clear Sweeps button or Reset Statistics softkey to clear and restart statistics. SMO1000E/SMO1000U 197/234...

  • Page 198: Data Logger

    Press the Sample Logger softkey to enter the sample logger interface. At this time, all the buttons on the front panel will not respond (except for the menu softkey, Print and Universal Knob). Press the Exit softkey to exit the sample logger. Figure 128 Sample Logger Interface SMO1000E/SMO1000U 198/234...
  • Page 199 External: Record the data to external storage device, and set the external storage path. Figure 129 Settings Interface Press the Return softkey to return to the RECORD function menu. Press the Start softkey to start to record, and the record status in the top information bar is displayed as "Run". SMO1000E/SMO1000U 199/234...
  • Page 200 Press the Recall softkey to enter the RECALL function menu. Press the Recall from softkey to select the storage path. Press the Press to Recall softkey to recall the recorded waveform data and enter the CONTROL menu automatically. SMO1000E/SMO1000U 200/234...
  • Page 201 The oscilloscope provides a tool named file converter to convert the waveform file (*.slg) to CSV format. You can download it from the Save/Recall menu or the webserver. Press the Delete Internal Data softkey to delete the internal record. SMO1000E/SMO1000U 201/234...

  • Page 202: Measure Logger

    (Auto/manual) Time value of the first point (centered on horizontal reference point) Horizontal Reference Point Record Interval Start Time Number of recorded points, Recorded time, Used Memory Remaining recordable time The current value of measurement items Upper and lower scale of measurement items SMO1000E/SMO1000U 202/234...
  • Page 203 Figure 134 Start to Record Measurement Data Press the Stop softkey to stop recording, the record status in the top information bar is displayed as "Stop". SMO1000E/SMO1000U 203/234...
  • Page 204 Peak: Track the data with the maximum deviation from the overall average value in a pixel where T-Cursors relocated. When two cursors are at the same position, T1 will track the maximum value and T2 will track the minimum value. SMO1000E/SMO1000U 204/234...
  • Page 205 Scientific Figure 135 Cursors of Measure Logger Storage Measurement Record Press the Save/Recall softkey to enter the SAVE/RECALL function menu. Figure 136 Save/Recall of Measure Logger SMO1000E/SMO1000U 205/234...
  • Page 206 Press the Press to Recall softkey to recall. Manage Internal Record Export or delete the internal record, it is similar to “Manage Internal Record" of Sample Logger. SMO1000E/SMO1000U 206/234...

  • Page 207: Update Firmware And Configuration

    Press to Update softkey to start update the firmware. The process needs about 30 seconds. 7. After finish the update, the screen will pop-out the message “Firmware decompressed. Please restart and wait…” 8. Restart the oscilloscope to finish the configuration update. SMO1000E/SMO1000U 207/234...

  • Page 208: Do Self Test

    The screen displays green, blue and red again. It is easy to check chromatic aberration, stain and scratch of the screen under the condition. 7. Press the Run/Stop button on the front panel to exit the screen test program. SMO1000E/SMO1000U 208/234...

  • Page 209: Keyboard Test

    • Keys test: the first time to press the key to light it up, and a second press to die out. Test every button randomly. 7. Press the Run/Stop button 3 times to exit the keyboard test program. SMO1000E/SMO1000U 209/234...

  • Page 210: Led Test

    Run/Stop button displays red, and the second press the Run/Stop button displays green. Then the other button lights will be lighted one by one. At last all the lights will be lighted at the same time. 6. Press the Run/Stop button to exit the LED test program. SMO1000E/SMO1000U 210/234...

  • Page 211: Screen Saver Time

    The screen saver time can be set to 1min, 5min, 10min, 30min, and 1hour. Also you can select Off to turn off the screen saver function Figure 141 Screen Saver Interface 4. Press the any button on the front to exit the screen saver program. SMO1000E/SMO1000U 211/234...

  • Page 212: Date/Time

    Press the Date/Time softkey to enter the Data/Time setting menu. Press the Date softkey and press the Universal Knob to select year, month or day, then rotate the Universal Knob to change value. Modifying the time is similar to the date. Figure 143 Setting Date/Time SMO1000E/SMO1000U 212/234...

  • Page 213: Set Time Zone

    Press the Power On Sync softkey to select On or Off. When set to On, the oscilloscope will automatically synchronize the time after the power on. Press the Periodic Sync softkey to select On; press the Interval softkey and rotate Universal Knob to set the value. SMO1000E/SMO1000U 213/234...
  • Page 214 Scientific Figure 145 NTP Setting Interface SMO1000E/SMO1000U 214/234...

  • Page 215: Reference Position

    Enable or Disable. Enable: when the oscilloscope is energized, the oscilloscope will start automatically by itself. Disable: when the oscilloscope is energized; then; press the power key at the lower-left corner of the front panel to start the oscilloscope. SMO1000E/SMO1000U 215/234...

  • Page 216: Option Management

    Scientific 16.18 Option Management The SMO1000E and SMO1000U provide multiple options to fulfil your measurement requirements. Please contact your sales representative or technical support to order the corresponding options. You can view the options currently installed on the oscilloscope or activate the newly purchased option license codes through this menu.
  • Page 217 Scientific Press the Information softkey to view the option information. Figure 148 Option Information SMO1000E/SMO1000U 217/234...

  • Page 218: Bode Plot Ii

    17. Bode Plot II The bode plot application for the SMO1000E (4-channel) control an external arbitrary waveform generator(only Scientific arbitrary waveform generator can be supported)to sweep a sine wave across a range of frequencies while measuring the input to and output from a device under test (DUT).
  • Page 219 4) Press the Set Stimulus softkey to enter STIMULUS menu. Press the Amplitude softkey (Offset softkey) and turn the Universal Knob to set the amplitude, or press the Universal Knob directly to enter the parameter value in the pop-up virtual keyboard. SMO1000E/SMO1000U 219/234...
  • Page 220 Knob directly to enter the value in the pop-up virtual keyboard. Press the Unit softkey continuously to switch the phase unit to Deg or Rad. Press the Auto Set softkey to automatically adjust the vertical direction parameters based on the Bode plot data. SMO1000E/SMO1000U 220/234...
  • Page 221 Scroll soft key and turn the Universal Knob to select the frequency point, as shown below. Figure 154 Bode Plot List On 2) Press Save softkey (Recall softkey) to enable the bode plot save (recall) function. See the chapter “Save and Recall” for details. SMO1000E/SMO1000U 221/234...

  • Page 222: Example

    Figure 157 Set Sweep Parameters Menu Press Set Stimulus to enter Set Stimulus menu. Press Amplitude and use the Universal Knob to set the signal amplitude to 2 V. All the other options remain their default setting. Then return to the Configure menu. SMO1000E/SMO1000U 222/234...
  • Page 223 Channel Gain to “Auto”. Then return to the Configure menu. Figure 159Set Channel Menu Configuration was done. Return to root menu and press Run, and wait for the sweep to complete. Figure 160 Bode Plot Sweep Curve SMO1000E/SMO1000U 223/234...

  • Page 224: Vari-Level Sweep Operation

    The profile is a 4-joint-polylinewith large stimulus amplitude in low frequency and small amplitude in high frequency, and gradual amplitude in intermediate frequency. Press Joints and use the Universal Knob to set the number of joint to 4. SMO1000E/SMO1000U 224/234...
  • Page 225 11. Return to Configure menu and press Set Channel. Set DUT Input to “CH1” and DUT Output 1 to “CH2”, and Channel Gain to “Auto”. 12. Configuration was done. Return to the root menu and press Run and wait for the sweep to complete. SMO1000E/SMO1000U 225/234...
  • Page 226 Scientific Figure 165 Bode Plot Sweep Curve SMO1000E/SMO1000U 226/234...

  • Page 227: Navigate

    Scientific 18. Navigate SMO1000E(4-channel a nd SMO1000U provide three navigate type: Search Event, Time, ） History Frame. 18.1 Time Navigate Press the Navigate on the front panel to enter the NAVIGATE function menu. Press the Type softkey In the NAVIGATE function menu, then select Time.

  • Page 228: History Function

    The format of the Frame is A/B; A is the frames number that displaying on the screen and B is the maximal frame number you can set. The maximal frame number is determined by the current sampling point (Curr value) and sampling rate. SMO1000E/SMO1000U 228/234...
  • Page 229 Press the softkey to replay the waveform from the current frame to 1. Press the softkey to stop replay. Press the softkey to replay the waveform from the current frame to the last frame. SMO1000E/SMO1000U 229/234...

  • Page 230: Factory Setup

    Press Save/Recall function key, then press Save menu select To Default Keyset the type to Factory Setup. Then press the Default button on the front to set the oscilloscope to the leave factory setup. Another way is press Save/Recall function key, then press Recall menu select Factory Default to recall. SMO1000E/SMO1000U 230/234...

  • Page 231: Troubleshooting

    2) Check the trigger type: general signals should use “Edge” trigger and video signal should use “Video” trigger. Only when the proper trigger type is used, can the waveform be displayed stably. 3) Change the trigger holdoff setting. SMO1000E/SMO1000U 231/234...
  • Page 232 3) Make sure that the USB storage device being used is flash storage type. This oscilloscope does not support hardware storage type. 4) Restart the instrument and then insert the USB storage device to check it. 5) If the USB storage device still cannot be used normally, please contact your sales. SMO1000E/SMO1000U 232/234...

  • Page 233: Dispatch Procedure For Service, E-Waste Management & Warranty

    Scientific warrants all its Instruments to be free from defects in material and workmanship when used under normal operating conditions in accordance with the instructions given in the manual for a period of 12 (Twelve) months from date of purchase from Scientific or its authorized dealers.
  • Page 234 Your Scientific instrument is a complex electronic device and deserves the best service available by technicians thoroughly familiar with its service and calibration procedures. SMO1000E/SMO1000U...

This manual is also suitable for:

Smo1000e

Table of Contents
