Scientific SMO5000X Series User Manual

Digital oscilloscope
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Digital Oscilloscope
SMO5000X
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMO5000X Series and is the answer not in the manual?

Questions and answers

Related Manuals for Scientific SMO5000X Series

Summary of Contents for Scientific SMO5000X Series

  • Page 1 Digital Oscilloscope SMO5000X User Manual...
  • Page 2 Information in this manual supersedes all corresponding previous released material. Scientific continues to improve products and reserves rights to amend part or all of the specifications, procedures, equipment at any time without notice.

  • Page 3: Table Of Contents

    Scientific Contents CONTENTS ........................3 INTRODUCTION ....................10 GENERAL SAFETY SUMMARY ............... 11 SAFETY TERMS AND SYMBOLS ..............11 WORKING ENVIRONMENT................12 COOLING REQUIREMENTS ................13 AC POWER ...................... 13 POWER AND GROUND CONNECTIONS ............14 CALIBRATION ....................15 CLEANING ....................... 15 ABNORMAL CONDITIONS ................
  • Page 4 Scientific TOUCH SCREEN DISPLAY ................24 OVERVIEW ....................... 24 MENU BAR ....................... 25 GRID AREA ...................... 25 CHANNEL DESCRIPTOR BOX ................ 26 TIMEBASE AND TRIGGER DESCRIPTOR BOXES ......... 28 DIALOG BOX ....................30 TOUCH GESTURES ..................31 MOUSE AND KEYBOARD OPERATION ............33 CHOOSING THE LANGUAGE ................
  • Page 5 Scientific HORIZONTAL AND ACQUISITION SETUP ............51 14.1 TIMEBASE SETUP ..................51 14.2 ACQUISITION SETUP ..................51 14.2.1 Overview ......................51 14.2.2 Acquisition ......................53 14.2.3 Roll Mode ......................55 14.2.4 Sequence ......................56 14.3 HISTORY ......................59 14.4 ZOOM ......................61 TRIGGER ......................
  • Page 6 Scientific 16.2.1 I2C Signal Settings ................... 90 16.2.2 I2C Trigger ....................... 91 16.2.3 I2C Serial Decode .................... 94 16.3 SPI TRIGGER AND SERIAL DECODE ............. 96 16.3.1 SPI Signal Settings ................... 96 16.3.2 SPI Trigger ....................... 97 16.3.3 SPI Serial Decode .................... 97 16.4...
  • Page 7 Scientific CURSORS ......................113 17.1 OVERVIEW ...................... 113 17.2 SELECT AND MOVE CURSORS ..............119 MEASUREMENT ..................... 121 18.1 OVERVIEW ...................... 121 18.2 SET PARAMETERS ..................122 18.3 TYPE OF MEASUREMENT ................124 18.3.1 Vertical Measurement ..................124 18.3.2 Horizontal Measurement .................. 126 18.3.3...
  • Page 8 Scientific 24.1 OVERVIEW ...................... 160 24.2 MODE ....................... 161 24.3 DIAGRAMS ...................... 162 HISTOGRAM ....................165 25.1 OVERVIEW ...................... 165 25.2 REGION SETTING .................... 167 DISPLAY ......................169 ARBITRARY WAVEFORM GENERATOR ............175 27.1 OVERVIEW ...................... 175 27.2 OUTPUT ......................177 27.3...
  • Page 9 Scientific 29.12 DEFAULT ......................200 29.13 POWER ON LINE .................... 200 29.14 DEBUG ......................200 REMOTE CONTROL ..................201 30.1 WEB BROWSER ....................201 30.2 OTHER CONNECTIVITY ................. 202 TROUBLESHOOTING ..................203 SERVICE AND SUPPORT ................205 SMO5000X User Manual...

  • Page 10: Introduction

    Scientific 1 Introduction This user manual includes important safety and installation information related to the SMO5000X series oscilloscopes and includes simple tutorials for basic operation of the oscilloscope. SMO5000X User Manual 10/205...

  • Page 11: General Safety Summary

    Scientific 2 General Safety Summary This chapter contains information and warnings that must be followed to keep the instrument operating under the appropriate safety conditions. In addition to the safety precautions specified in this section, you must also follow recognized safety procedures.

  • Page 12: Working Environment

    Scientific 2.2 Working Environment This instrument is intended for indoor use and should be operated in a clean, dry environment with an ambient temperature range of 0 ° C -50 ° C. Note: Direct sunlight, radiators, and other heat sources should be taken into account when assessing the ambient temperature.

  • Page 13: Cooling Requirements

    Scientific CAUTION: Protect the display touch screen of the scope from excessive impact. CAUTION: Do not exceed the maximum specified front panel terminal (CH1, CH2, CH3, CH4, EXT) voltage levels. Refer to Specifications for more details. CAUTION: Do not connect or disconnect probes or test leads while they are connected to a voltage source.

  • Page 14: Power And Ground Connections

    Scientific Note: The instrument automatically adapts to the AC line input within the following ranges: Voltage Range: 90 - 264 Vrms 90 - 132 Vrms Frequency Range: 47 - 63 Hz 380 - 420 Hz 2.5 Power and ground connections...

  • Page 15: Cleaning

    Scientific 2.7 Cleaning Clean only the exterior of the instrument, using a damp, soft cloth. Do not use chemicals or abrasive elements. Under no circumstances allow moisture to penetrate the instrument. To avoid electrical shock, unplug the power cord from the AC outlet before cleaning.

  • Page 16: First Steps

    First, verify that all items listed on the packing list have been delivered. If you note any omissions or damage, please contact your nearest SCIENTIFIC customer service center or distributor as soon as possible. If you fail to contact us immediately in case of omission or damage, we will not be responsible for replacement.

  • Page 17: Document Conventions

    Scientific 4 Document Conventions For convenience, text surrounded by a box border is used to represent the button of the front panel. For example, represents the "Print" button on the front Print panel. Italic sized text with shading is used to represent the touchable or clickable menu/button/region on the touch screen.

  • Page 18: Getting Started

    Scientific Getting Started 5.1 Power on SMO5000X provides two ways for power on, which are: Power on Line When the “Power on Line” option is enabled, once the oscilloscope is connected to the AC power supply through the power cord, the oscilloscope boots automatically.

  • Page 19: Probe

    Scientific 6 Probe The SMO5000X series oscilloscope package includes passive probes as standard accessories. Please contact us for technical data. Probe Compensation When a probe is used for the first time, you should compensate it to match the input channel of the oscilloscope. Non-compensated or poorly compensated probe may increase measurement inaccuracy or error.

  • Page 20: Quick Start

    Scientific Quick Start 7.1 Front Panel Overview A. Touch Screen Display: The display and major functions area. See "Touch Screen Display" chapter for more details. B. Front Panel: Includes knobs and buttons. See "Front Panel" chapter for more details. C. Probe Compensation/ Ground Terminal: Supplies a 0-3 V 1 kHz square wave for compensating the probes.

  • Page 21: Rear Panel Overview

    Scientific 7.2 Rear Panel Overview A. Auxiliary Out: Outputs the trigger indicator. When Pass / Fail isenabled, outputs the pass / fail signal. B. Ext Trigger Input C. 10MHz Clock Input/Output: Receives or outputs 10 MHz reference clock for synchronization between the oscilloscope and other instruments.

  • Page 22: Connecting To External Devices/Systems

    The oscilloscope can now control the USB module to output specified waveforms. Press the WaveGen button on the front panel or touch the screen Utility＞AWG Menu to set the waveform. 7.3.7 Probes The SMO5000X series oscilloscope supports active probe and passive probes. SMO5000X User Manual 22/205...

  • Page 23: Logic Probe

    Scientific 7.3.8 Logic Probe To connect the logic probe: Insert the probe, with the correct side facing up, until you hear a “click”. To remove the logic probe: Depress the buttons on each side of the probe, then pull out it.

  • Page 24: Touch Screen Display

    Scientific Touch Screen Display 8.1 Overview The entire SMO5000X display is a capacitive touch screen. Use your fingers to touch, drag, pinch, spread, or draw a selection box. Many controls that display information also work as “buttons” to access other functions. If you using any mouse, you can click anywhere –...

  • Page 25: Menu Bar

    Scientific Cursors show where measurement points have been set. Move the cursors to quickly reposition the measurement point. Channel Descriptor boxes include analog channels (C1 ~ C4), digital channels (D), math (M) and reference (Ref). They are located under the grid area, showing the parameters of the corresponding traces.

  • Page 26: Channel Descriptor Box

    Scientific There are multiple indicators on the grid: Trigger Level Indicator shows the level where the waveform triggers on the vertical axis. Trigger Delay Indicator locates where the waveform triggers on the horizontal axis... When the trigger position is outside the screen, the direction of the triangle changes to point outside the screen.
  • Page 27 Scientific Invert Indicator--shows that the current channel is inverted: ： Invert has been turned on None : Invert has been turned off Coupling and Input Impedance: ：DC coupling, 1M impedance ：DC coupling, 50 impedance ：AC coupling, 1M impedance ：AC coupling, 50 impedance ：Ground...

  • Page 28: Timebase And Trigger Descriptor Boxes

    Scientific 8.5 Timebase and Trigger Descriptor Boxes A. Trigger delay B. Horizontal scale （timebase） C. # Samples D. SampleRate Trigger delay: The time offset of trigger position. When trigger delay is 0, the trigger delay indicator is in the center of the horizontal axis of the grid area.
  • Page 29 Scientific • AC：The signal is capacitively coupled. DC levels are rejected. See the datasheet for details of the cut-off frequency. • HFR：Signals are DC coupled to the trigger circuit, and a low-pass filter network attenuates high frequencies (used for triggering on low frequencies).

  • Page 30: Dialog Box

    Scientific 8.6 Dialog Box Dialog box on the right side of the screen is the main area for setting the parameters of the selected function. A. Title bar. Touching the bar can hide the dialog box, and touching again can open the dialog box.

  • Page 31: Touch Gestures

    Scientific Let’s use the operation of setting the “deskew” of a channel as an example: If the expected value is 65 ns, input “65” on the virtual keypad, and then choose the unit n to complete the operation. On the virtual keypad, touching the button Max, Min and Default quickly sets the parameter to its maximum, minimum and default values.
  • Page 32 Scientific Drag the waveform left and right to Pinch and spread the waveform move it on the horizontal axis horizontally to re-scale the timebase Drag the waveform up and down to Pinch and spread the waveform move it on the vertical axis...

  • Page 33: Mouse And Keyboard Operation

    Scientific Draw a rectangular box to create a zone or a histogram region. At the beginning of the gesture keep the angle close to 45° so it can be recognized as the drawing box gesture 8.8 Mouse and Keyboard Operation The SMO5000X user interface features mouse control as well as the touch screen.

  • Page 34: Front Panel

    Scientific Front Panel 9.1 Overview The front panel is designed to operate the basic functions without having to open the software menu. Most of the front panel controls duplicate functionality available through the touch screen display but the operation is more quickly achieved.

  • Page 35: Horizontal Control

    Scientific A. When a channel is disabled, push channel button to turn it on. When the channel is turned on and activated, push the button to disable it . B. Rotate the knob to adjust the DC offset or vertical position of the channel.

  • Page 36: Run/Stop Button

    Scientific 9.5 Run/Stop Button Press the button to switch the acquisition state between Run and Stop. When the state is Run, and the button is illuminated in yellow; when the state is Stop, the button is illuminated in red. 9.6 Auto Setup Button...

  • Page 37: Navigate Control

    Scientific F. Rotate the knob to adjust the vertical offset of Math or Ref, press down the knob to quickly reset the vertical offset to zero. It can also be used to adjust the position of selected digital channel on the screen.

  • Page 38: Other Buttons

    Scientific 9.11 Other Buttons Performs a screenshot save to an external storage device. The supported format includes.bmp\.jpg\.png. Clears the data or display in multiple sweeps, including display persistence, measurement statistics, average sweeps and Pass/Fail statistics. Enables/Disables the touch screen. The LED on the button lights to indicate that the touch screen is working.

  • Page 39: Multiple Approaches To Recall Functions

    Scientific 10 Multiple Approaches to Recall Functions The oscilloscope can recall functions through different approaches. 10.1 Menu Bar If you are familiar with common current computer programs, you may first choose to access a function by the drop-down menu from the menu bar at the top of the display.

  • Page 40: Quickly Capture The Signal

    Scientific 11 Quickly Capture the Signal This is an example about how to acquire a signal quickly. In this example we assume the signal is connected to channel 1 and channel 1is turned off. First, press channel 1 button to turn on channel1. The LED on the button lights, and the descriptor box of channel 1 is displayed at the bottom of the screen.

  • Page 41: Vertical Setup

    Scientific 12 Vertical Setup 12.1 Turn on/off a Channel From the Front Panel Push the channel button（1-4）to turn on the corresponding channel. Its channel descriptor box and dialog box will appear on the display. Push the same button again to disable the channel.
  • Page 42 Scientific F. Set the offset to zero G. Disable the channel H. Open the dialog box on the right side The vertical scale can be adjusted in coarse or fine mode. Fine mode can reach the full-scale display as close as possible, which can get the best measurement accuracy in the vertical direction.
  • Page 43 Scientific • GND: The channel is grounded by an internal switch. GND coupling is used to observe the zero offset error of the analog channels, or determine the source of noise in the waveform (from signal or from oscilloscope itself)
  • Page 44 Scientific Applied to With this setting, some common functions such as Cursor, Measure, FFT, Search, DVM, Histogram and Mask Test can be quickly applied to the selected channel. Once a function is specified, it will switch directly to the function menu and automatically set that channel as the source.
  • Page 45 Scientific Invert When invert is enabled, the waveform is 180 degrees opposite to the earth potential. Before invert After invert SMO5000X User Manual 45/205...

  • Page 46: Digital Channels

    Scientific 13 Digital Channels 13.1 Overview SPL2016 Probe The SPL2016 is a logic probe designed to monitor up to 16 digital signals at once. The 16 digital channels are separated into two groups and each group has its own threshold, making it possible to simultaneously view data from different logic families.

  • Page 47: Enable/Disable The Digital Channels

    Scientific The equipment shall be used only for the purposes specified by the manufacturer. The SPL2016 probe is used only for Scientific’s special series of oscilloscopes. Protection mechanisms can be compromised if the way the devices connected by the SPL2016 are not used for their intended purpose.
  • Page 48 Scientific A. Digital channel waveform display, which shares the same grid area with the analog channels. B. Digital channel descriptor box C. Dialog box D. Digital channel indicators. Up to 16 digital channels are organized in two groups with different thresholds: D15~D8 and D7~D0.Every channel can be turned on or off individually.

  • Page 49: Digital Channel Setup

    Scientific 13.3 Digital Channel Setup Touch the digital descriptor box, then the quick menu of digital channel settings pops up above the descriptor box. In the menu height and position of digital channels can be set: A. Upper position limit of the digital channel display area.
  • Page 50 Scientific The quick menu only covers the height range and position of the digital channels display area. More setting can be found in the dialog box. A. Turn on/off the digital channels B. Labels, can be set to data, address or custom characters.

  • Page 51: Horizontal And Acquisition Setup

    Scientific 14 Horizontal and Acquisition Setup 14.1 Timebase Setup The timebase setup is used to adjust the scale and offset of the X (horizontal) axis. This setting applies to all analog, digital channels and all math traces except FFT. Touch the timebase descriptor box, the quick menu of the timebase settings will pop up.
  • Page 52 Scientific Acquisition: See the section "Acquisition" for details. Memory Depth: The maximum memory depth that can be supported. According to the formula "acquisition time = sample points x sample interval", setting a larger memory depth can achieve a higher sample rate for a given timebase, but more samples require more processing time, degrading the waveform update rate.

  • Page 53: Acquisition

    Scientific • Sinc: Sin(x)/x interpolation, the original point is interpolated according to the Nyquist reconstruction formula, which has a good time-domain recovery effect for sine wave. But for step signals/fast rise times, it will introduce false overshoot due to the Gibbs phenomenon.
  • Page 54 Scientific Normal mode Peak mode Average: The oscilloscope accumulates multiple waveform frames and calculates the average as the result. If a stable trigger is available, the resulting average has a random noise component lower than that of a single-shot record.

  • Page 55: Roll Mode

    Scientific Normal mode Eres mode (3-bit) Eres acquisition does not require the signal to be periodic, nor does it require stable triggering, but due to the digital filtering, the system bandwidth of the oscilloscope will degrade in Eres mode. The higher the enhanced bits, the lower the bandwidth.

  • Page 56: Sequence

    Scientific 14.2.4 Sequence Touch Acquire>Sequence to recall sequence dialog box. A. Turn on or off sequence B. Set the segment Sequence mode is a fast acquisition mode, which divides the memory depth to multiple segments (up to 100,000), each of which stores a single shot. In sequence mode the oscilloscope only acquires and stores data without processing and displaying, until the specified segments are acquired.
  • Page 57 Scientific Example: Input a pulse sequence with a period of 50 ms to C1. Rise time of the pulse is 2ns,while fall time is 100ns; pulse width is 108ns, and amplitude is 1.6Vpp. Press the AutoSetup button on the front panel.
  • Page 58 Scientific In Sequence mode, there is no waveform displayed on the screen until the acquisition is completed. During acquisition, there is a counter on the screen indicating the number of segments that have been acquired. In the example, 53969 pulses can be obtained with the sample rate of 5GSa/s at the maximum memory depth.

  • Page 59: History

    Scientific 14.3 History Press the History button on the front panel or touch Analysis>History to recall history dialog box. A. Turn on or off history Mode B. Specify the frame index C. Play backward automatically D. Pause E. Play forward automatically F.
  • Page 60 Scientific Observing the 5412th frame captured by Sequence in history mode Touch the List area, turn on the list, in which the time label corresponding to the 5412th waveform is displayed. The time resolution is microseconds. Time label types includes AcqTime or Delta T, AcqTime corresponds to the absolute time of the frame, synchronized with the real-time clock of the oscilloscope;...

  • Page 61: Zoom

    Scientific In addition to manually specifying a frame, history mode supports auto play: Press the softkey to replay the waveform from the current frame to the first. Press the softkey to stop replay. Press the softkey to replay the waveform from the current frame to the last.
  • Page 62 Scientific of Zoom window and the horizontal scale of main window can also be controlled by different gestures, as follows: Adjust the horizontal position of the zoom area by dragging left and right in the zoom area of the main window or waveform in Zoom window...

  • Page 63: Trigger

    Scientific 15 Trigger 15.1 Overview The oscilloscope only acquires waveforms of interest (i.e. the ones that satisfy the trigger condition) and aligns all trigger events at the trigger position to form a stable waveform display. The trigger is one of the most important features of any oscilloscope, since we can only analyze a signal that we are able to trigger in a reliable and stable manner.

  • Page 64: Trigger Setup

    Scientific 15.2 Trigger Setup Touch the trigger descriptor box to display the quick menu of trigger settings.The trigger setup dialog box is displayed on the right side of the screen. A. Touch the level region and rotate the Level knob on the front panel to adjust trigger level;...

  • Page 65: Trigger Level

    Scientific A. Select trigger type B. Select the trigger source C. Select the trigger slope (When the trigger type is "Edge", "Slope" and other specific types) D. Set holdoff (None/Time/Events) E. Set trigger coupling mode (DC/AC/LF Reject/HF Reject) F. Enable/disable Noise Rejection. When Noise...

  • Page 66: Trigger Mode

    Scientific In some special trigger, the system will automatically set the trigger level, such as using AC Line as the trigger source. 15.4 Trigger Mode The trigger mode determines how the oscilloscope acquires waveforms. Auto：An internal timer triggers the sweep after a preset timeout period if no trigger has been found, so that the oscilloscope continuously updates the display whether a trigger happens or not.

  • Page 67: Trigger Type

    Scientific 15.5 Trigger Type 15.5.1 Overview The trigger modes of the SMO5000X are digital designs. Compared with analog trigger circuits, digital triggers can not only greatly optimize trigger precision, trigger jitter, but also support multiple trigger types and complex trigger conditions.

  • Page 68: Edge Trigger

    Scientific 15.5.2 Edge Trigger Edge trigger distinguishes the trigger points by seeking the specified edge (rising, falling, rising & falling) and trigger level. Trigger source and slope can be set in the trigger dialog box. Touch the Source area to select trigger source, and touch the Slope area to select rising, falling or alter.
  • Page 69 Scientific Adjust Upper/Lower Level The slope trigger requires upper and lower trigger levels. When the trigger type is slope trigger, touch the trigger descriptor box, the pop-up quick menu will show two levels. The upper/lower level can be set in the following two ways: 1.

  • Page 70: Pulse Trigger

    Scientific 15.5.4 Pulse Trigger Trigger on a positive or negative pulse with a specified width. Trigger source, polarity (positive, negative), limit range and time value can be set in the trigger dialog box. Less than a time value（ （ （ （ ≤） ） ） ） -- Trigger when the positive or negative pulse time if the input signal is lower than the specified time value.

  • Page 71: Video Trigger

    Scientific 15.5.5 Video Trigger Video trigger can be used to capture the complicated waveforms of most standard analog video signals. The trigger circuitry detects the vertical and horizontal interval of the waveform and produces trigger based on the video trigger settings you have selected. The SMO5000Xsupports standard video...
  • Page 72 Scientific In the custom video trigger type, the corresponding "Of Fields" varies with the selection of the “Interlace” ratio. Therefore, the number of fields selected and the number of lines corresponding to each field can also be varied. If the "Of Lines"...
  • Page 73 Scientific To gain familiarization with the video trigger, try these two examples: • Trigger on specific line of video(NTSC standard) • Use “Custom” to trigger video signals Trigger on a Specific Line of Video Video trigger requires that any analog channel can be used as the trigger source with a synchronization amplitude greater than 1/2 grid.

  • Page 74: Window Trigger

    Scientific 1. Press the Setup button on the front panel to open the trigger menu. 2. In the trigger menu, touch the Type, select the "Video". 3. Touch the Source and select CH1 as the trigger source. 4. Touch the Standard and select the "Custom".

  • Page 75: Interval Trigger

    Scientific If the upper trigger level is within the waveform amplitude range while the • lower trigger level is out of the waveform amplitude range, the oscilloscope will trigger on the rising edge only. If the lower trigger level is within the waveform amplitude range while the •...

  • Page 76: Dropout Trigger

    Scientific When the trigger condition is set as an interval between two neighboring rising edges and it is less than the set time value, the trigger diagram is as follows: Trigger source, slope (rising, falling), limit range and time value can be set in the trigger dialog box.

  • Page 77: Runt Trigger

    Scientific Trigger source, slope (rising, falling), dropout type and time value can be set in the trigger dialog box. Holdoff, coupling and noise reject can be set in dropout trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details.

  • Page 78: Qualified Trigger

    Scientific Logic (AND, OR, NAND, NOR),source, limit range and time value can be set in the trigger dialog box. When the logic is "OR" or "NAND", the setting of time limit is invalid. Source Setting Touch the Source Setting area to recall the following dialog box and set up for each channel separately.
  • Page 79 Scientific When the type is “Edge”, the oscilloscope triggers at the first edge after the specified edge (Rising or Falling) of the qualified source; when the type is “Edge with Delay”, time limit condition is available. Touch the Qualified Setting region to set the qualified source and threshold;...

  • Page 80: Trigger Source

    Scientific 15.6 Trigger Source The trigger sources supported by each trigger type are different. See the table below for details: Trigger Type C1~C4 EXT, EXT/5 AC Line D0~D15 √ √ √ √ Edge √ Slope × × × √ √...

  • Page 81: Trigger Coupling

    Scientific Holdoff by Event Holdoff event is the amount of events that the oscilloscope counts before rearming the trigger circuitry. The oscilloscope will not trigger until the counter tracking holdoff events reaches the set value. In the following figure, the holdoff event is set to 3, and the signal is triggered on the fourth edge.

  • Page 82: Noise Reject

    Scientific medium to high frequency signals. See the datasheet for details of the cutoff frequency. 15.9 Noise Reject Noise Reject adds additional hysteresis to the trigger circuitry. By increasing the trigger hysteresis, the noise immunity becomes better but the trigger sensitivity degrades.

  • Page 83: Zone Trigger

    Scientific 15.10 Zone Trigger The SMO5000X includes a zone trigger to help isolate elusive glitches. There are two user-defined areas: Zone1 and Zone2. Users can set the property of each zone as “intersect” or “not intersect” as an additional condition to further isolate the interested event quickly.
  • Page 84 Scientific Gesture When the zone trigger is turned on, touch-and-hold on any position within the waveform area and draw a rectangular box, as shown in the following figure: When the finger moves out of the screen, a menu pops up for selecting the zone and setting the zone properties: Once a zone is created, it can be moved by dragging.
  • Page 85 Scientific Select C1 as source, turn on zone1, Select C1 as source, turn on zone1, and set the property as "Intersect" and set the property as "Not Intersect" Dialog Box Touch Zone> Zone Setting to recall the dialog box. A. Set left border of the zone B.
  • Page 86 Scientific With a simple edge trigger, it is unlikely to trigger consistently on this anomaly. Thanks to the high waveform update rate of the SMO5000X, we can confirm there is bus contention happening by enabling the persistence display, as shown in the figure below: In this case zone trigger is a quick and simple way to capture the interested waveform.
  • Page 87 Scientific Now, we can accurately capture the exact bus contention waveform: SMO5000X User Manual 87/205...

  • Page 88: Serial Trigger And Decode

    Scientific 16 Serial Trigger and Decode 16.1 Overview The SMO5000X supports serial bus trigger and decode on the following serial bus protocols:I2C, SPI, UART, CAN, and LIN. Press the Setup button on the front panel or touch the trigger descriptor box, and then select the Type as Serial in the trigger dialog box to set serial trigger: A.
  • Page 89 Scientific Press the Decode button or touch the Analysis>Decode to turn on the serial decode dialog box: A. Turn on/off serial decode function B. Select the bus to set, Decode1 and Decode2 C. Select the serial bus protocol D. Touch to set the signal, including the mapping relation between channels and bus signals, and the thresholds.

  • Page 90: I2C Trigger And Serial Decode

    Scientific 16.2 I2C Trigger and Serial Decode This section covers triggering and decoding I2C signals. Please read the following for more details: "I2C Signal Settings", "I2C Trigger" and "I2C Serial Decode". 16.2.1 I2C Signal Settings Connect the serial data signal (SDA) and serial clock signal (SCL) to the oscilloscope, set the mapping relation between channels and signals and then set the threshold level of each signal.

  • Page 91: I2C Trigger

    Scientific Copy Setting Touch the Copy Setting in the decode dialog box to synchronize the settings between trigger and decode. A. Copy the decode settings to trigger B. Copy the trigger settings to decode C. Return to previous menu. Note: The synchronization is not automatic. If the settings at one place change, a copy operation is necessary to re-synchronize.
  • Page 92 Scientific Restart—The oscilloscope will be triggered when another “Start” occurs before a “Stop". No Ack—The oscilloscope will be triggered when the SDA line is high during any SCL’s ACK bit. EEPROM — The trigger searches for EEPROM control byte value 1010xxx on the SDA bus. And there is a Read bit and an ACK bit behind EEPROM.
  • Page 93 Scientific 10 Address&Data —If all bits match, then trigger on the Ack bit followed by the Data. Frame (Start: Address 1st byte: R/W: Ack: Address 2nd byte: Ack: Data) If you set the trigger condition to 7 address&data or 10 address&data: •...

  • Page 94: I2C Serial Decode

    Scientific 16.2.3 I2C Serial Decode Layout of the touch screen display when I2C decode enabled is as follows: A. Waveform display area, shows the original waveforms of the bus signals B. Bus display, shows the decode result of the bus. At most two buses can be decoded at the same time.
  • Page 95 Scientific indicates there is not enough space on the display to show the complete • content of a frame, and some content is hidden. List • TIME—The horizontal offset of the current data frame head relative to the trigger position.

  • Page 96: Spi Trigger And Serial Decode

    Scientific 16.3 SPI Trigger and Serial Decode This section covers triggering and decoding SPI signals. Please read the following for more details: "SPI Signal Settings", "SPI Trigger" and "SPI Serial Decode". 16.3.1 SPI Signal Settings Connect the CLK, MOSI, MISO and CS signals to the oscilloscope and set the mapping relation between channels and signals.

  • Page 97: Spi Trigger

    Scientific The CS signal should be set to correct CS Type, including CS, ~CS and Clock Timeout. • CS–Active high. • ~CS–Active low. • Clock Timeout– It is not necessary to specify the source and threshold level for the CS signal. The only parameter for the CS signal is the timeout Limit, which is the minimum time that the clock signal must be held idle for before the oscilloscope acquires valid data.

  • Page 98: Uart Trigger And Serial Decode

    Scientific 16.4 UART Trigger and Serial Decode This section covers triggering and decoding UART signals. Please read the following for more details: "UART Signal Settings", "UART Trigger" and "UART Serial Decode". 16.4.1 UART Signal Settings Connect the RX and TX signals to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal.

  • Page 99: Uart Trigger

    Scientific 16.4.2 UART Trigger Touch Trigger Setting in the dialog box to set the trigger condition: A. Source Type: RX or TX B. Trigger Condition: Start, Stop, Data or Error C. When the "trigger condition" is Data, set the compare type to: =, ＞, ＜...

  • Page 100: Can Signal Settings

    Scientific 16.5.1 CAN Signal Settings Connect the CAN_H and CAN_L signals to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of each signal. The process of specifying the source and threshold is similar to "I2C Signal Settings".

  • Page 101: Can Serial Decode

    Scientific 16.5.3 CAN Serial Decode The configuration of CAN decoding is similar to that of I2C decoding. On the bus: • ID, LEN (data length), DATA and CRC are all displayed in white. indicates there is not enough space on the display to show complete •...

  • Page 102: Lin Trigger And Serial Decode

    Scientific 16.6 LIN Trigger and Serial Decode This section covers triggering and decoding LIN signals. Please read the following for more details: “LIN Signal Settings”, “LIN Trigger” and “LIN Serial Decode”. 16.6.1 LIN Signal Settings Connect the LIN signal to the oscilloscope, and then set the threshold level of the signal.

  • Page 103: Lin Serial Decode

    Scientific 16.6.3 LIN Serial Decode The configuration of LIN decoding is similar to that of I2C decoding. On the bus: • ID, LEN (data length), DATA and CHK are all displayed in white. In the list view: • Time—The horizontal offset of the current data frame head relative to the trigger position.

  • Page 104: Flexray Trigger And Serial Decode

    Scientific 16.7 FlexRay Trigger and Serial Decode This section covers triggering and decoding FlexRay signals. Please read the following for more details: "FlexRay Signal Settings", "FlexRay Trigger" and "FlexRay Serial Decode". 16.7.1 FlexRay Signal Settings Connect the FlexRay signal to the oscilloscope, and then set the threshold level of the signal.

  • Page 105: Flexray Serial Decode

    Scientific 16.7.3 FlexRay Serial Decode The configuration of FlexRay decoding is similar to that of I2C decoding. On the bus: • The signatures (CAS/MTS, WUP) are displayed in white. • TSS transmission start sequence, displayed in white. N The null frame indicator, the Sync frame indicator, and the Startup frame indicator are displayed in the frame and displayed in white.

  • Page 106: Can Fd Trigger And Serial Decode

    Scientific 16.8 CAN FD Trigger and Serial Decode This section covers triggering and decoding CAN FD signals. Please read the following for more details: "CAN FD Signal Settings", "CAN FD Trigger" and "CAN FD Serial Decode". 16.8.1 CAN FD Signal Settings Connect the CAN FD signal to the oscilloscope, and then set the threshold level of the signal.

  • Page 107: Can Fd Serial Decode

    Scientific be set. Curr ID Byte is used to specify the byte to be adjusted when using the universal knob. • ID— The oscilloscope triggers on the data frame that matches the specified ID. ID, ID Bits (11-bit or 29-bit), and Curr ID Byte (1st, 2nd, 3rd, or 4th byte) can be set.

  • Page 108: I2S Trigger And Serial Decode

    Scientific In the list view: • Time— The horizontal offset of the current data frame head relative to the trigger position. • Type— Type of the frame. Standard CAN frame is represented by "Std", CAN FD frame is represented by "FD", extended frame is represented by "Ext"...

  • Page 109: I2S Trigger

    Scientific In addition to specifying the source and the threshold level, WS signals also require specification of the Left CH. • Low–Select left channel when WS is low and right channel when WS is high. • High–Select right channel when WS is low and left channel when WS is high.

  • Page 110: I2S Serial Decode

    Scientific Trigger Condition • Data— Trigger on data. Touch Compare Type to select "=", ">" or "<". Touch Value to set the data value by the universal knob or virtual keypad. The range of data value is related to the number of Data Bits.

  • Page 111: Mil-Std-1553B Trigger And Serial Decode

    Scientific Type— Channel type, left channel is represented by "Left CH" and right • channel is represented by "Right CH". Data— Data bytes • Error— Error • 16.10 MIL-STD-1553B Trigger and Serial Decode This section covers triggering and decoding MIL-Standard 1553B signals.
  • Page 112 Scientific In the decoding list view: Time— The horizontal offset of the current data frame head relative to • the trigger position. RTA— The RT address • Type— Type of the word • Data— Data values • Error— Error type •...

  • Page 113: Cursors

    Scientific 17 Cursors 17.1 Overview Cursors are important tools when measuring signals. Rapid measurements can be performed using cursors in both horizontal and vertical directions. The cursor types includesX1, X2, X1-X2, Y1, Y2 and Y1-Y2, used to indicate X-axis values(time or frequency) and Y-axis values(amplitude) on a selected waveform(CH1/CH2/CH3/CH4/MATH/REFA/REFB/REFC/REFD).
  • Page 114 Scientific Cursors Mode Manual -- Manually set the cursors’ position. Cursors type (horizontal, • vertical, horizontal+vertical) is available in this mode. Track -- The cursor type is automatically set to "horizontal+vertical". In this • mode, only horizontal cursors are adjustable, while the vertical cursors automatically attach to the cross-point of the cursor and the source waveform.
  • Page 115 Scientific Cursors Type X (horizontal) -- Vertical dotted lines that measure horizontal time (when the source is an FFT waveform, X cursors measure frequency). X cursors (time) X cursors (frequency) X1—The left (default) vertical dotted line. It can be manually moved to •...
  • Page 116 Scientific Y2—The lower (default) horizontal dotted line. It can be manually moved • to any vertical position on the screen. Y1- Y2—The difference between Y1 and Y2. After this option is selected, • turn the universal knob to move both Y1 and Y2 simultaneously.
  • Page 117 Scientific Curosrs Reference X cursors reference: Fixed Delay– When the timebase is changed, the value of X cursors • remain fixed. Fixed Position– When the timebase is changed, the X cursors remain • fixed to the grid position on the display.
  • Page 118 Scientific Fixed position, timebase is changed to 100ns/div, the grid number of X cursors -1div, 2div) remains fixed. The value of X1 and X2 are changed to -100ns, 200ns. Fixed delay, timebase is changed to 100ns/div, the value of X cursors (-50ns, 100ns) remains fixed.

  • Page 119: Select And Move Cursors

    Scientific 17.2 Select and Move Cursors The cursors can be selected and moved directly by gestures and the universal knob on the front panel, in addition they can be selected in the cursors dialog box. Gestures Directly touch the cursor and drag it, as shown below: Touch the display area of △X(or△Y) in M1 mode and drag it to move the two...
  • Page 120 Scientific Universal Knob Move the cursor position by turning the universal knob on the front panel. Press the knob to select different cursor lines. For example, if the current cursor is X1, press to select X2, and press again to select X1-X2.

  • Page 121: Measurement

    Scientific 18 Measurement 18.1 Overview The SMO5000X features a strong automatic measurement list. These parameters can be automatically measured without cursors. Included are common measurements such as rise time, fall time, peak-peak, and period. The SMO5000X can also measure multiple channels at the same time, showing up to 5 parameter measurements with and statistics at one time.

  • Page 122: Set Parameters

    Scientific Press the Measure button on the front panel or touch Measure>Menu to open the dialog box. A. Turn on or off measure B. Type of measure: All Measurement or Custom. If select as "All Meas", It will show all measurements of the specified channel. If select as "Custom", add measurement...
  • Page 123 Scientific A. Indicates the source of the current setting. B. Measurement parameter classification tabs, including vertical measurement, horizontal measurement and channel delay(CH Delay) measurement. Touch a tab and in the area will display the corresponding parameters C. Parameters. Touch the parameter to be measured to activate it, and touch it again to close the parameter.

  • Page 124: Type Of Measurement

    Scientific In the parameter selection area, the channel corresponding to Source A is specified first, and then the channel corresponding to Source B. Finally, the measurement parameter is selected. For example, to activate the skew between C1 and C2, you can follow the following steps: Source A>C1>Source B>C2>Skew...
  • Page 125 Scientific Max: Highest value in the input waveform • Min: Lowest value in the input waveform • Pk-Pk: Difference between maximum and minimum data values • Top: Value of most probable higher state in a bimodal waveform • Base: Value of most probable lower state in a bimodal waveform •...

  • Page 126: Horizontal Measurement

    Scientific Preshoot (FPRE):Overshoot before a falling edge. • Equal to 100%*(max-top)/amplitude. Preshoot (RPRE):Overshoot before a rising edge. • Equal to 100%*(base-min)/amplitude. L@T: Level measured at trigger position • 18.3.2 Horizontal Measurement Horizontal measurement includes 12 parameters: SMO5000X User Manual 126/205...

  • Page 127: Delay Measurement

    Scientific Period: Time between the middle threshold points of two consecutive • like-polarity edges. Freq: Reciprocal of period • +Width: Time difference between the 50% threshold of a rising edge to • the 50% threshold of the next falling edge of the pulse -Width: Time difference between the 50% threshold of a falling edge to •...

  • Page 128: Measurement Statistics

    Scientific Phase: Phase difference between two edges • FRFR：The time between the first rising edge of source A and the • following first rising edge of source B at the 50% crossing FRFF：The time between the first rising edge of source A and the •...

  • Page 129: Statistics Histogram

    Scientific Stdev –Standard deviation of all historical measurements • Count –The number of historical measurements • Press the Clear Sweeps button or touch Reset Statistics in the measure dialog box, or touch the symbol in the statistics display area to clear and restart statistics.

  • Page 130: All Measurement

    Scientific D. Current value E. The bin that includes the maximum value and the probability of a value falling into it F. Close the enlarged histogram 18.6 All Measurement Enabling All Measurement displays all vertical and horizontal measurement parameters of the specified channel at the same. The font color of the measurement parameters is consistent with the color of the specified source.
  • Page 131 Scientific The figure below shows a scenario in which the gate function is used to measure the peak-peak parameter of the trough of an amplitude modulated waveform: SMO5000X User Manual 131/205...

  • Page 132: Math

    Scientific 19 Math 19.1 Overview The SMO5000X supports math operation on the analog channels (f(x)) and on math traces (g[f(x)]). Multiple operators are supported: Addition (+), subtraction (-), multiplication (x), division (/), differential (d/dt), integral (∫dt), square root (√) and FFT. The math trace is displayed in white and labeled with an “M” icon. It can be measured by the cursors or as the source of auto measurement.
  • Page 133 Scientific When the function is g[f(x)], the math dialog box is displayed as: A. Touch to configure f(x) B. Touch to configure g[f(x)] C. Set the vertical scale of the g[f(x)] trace D. Set the vertical position of the g[f(x)] trace.

  • Page 134: Addition/Subtraction/Multiplication/Division

    Scientific 19.2 f(x) 19.2.1 Addition/Subtraction/Multiplication/Division The SMO5000X can perform arithmetic operations including addition, subtraction, multiplication or division on any two analog input channels. The values of Source A and Source B are computed point-by-point. The following figure shows an example of MATH = C1 + C2: 19.2.2 Differential...

  • Page 135: Integral

    Scientific The range of “dx” in the d/dt menu is 1~20. The measurement units are point and the corresponding time difference range is 0.01~0.20 div. “div” indicates the number of the pixel points that each division has and is 100 for the SMO5000X.

  • Page 136: Square Root

    Scientific In addition, the integral operation can be performed within a specified gate. Touch Gate area in the math dialog box, and enable Gate function, then set Gate A and Gate B to define the gate. The setting of the gate cursors is similar to that of normal cursors.

  • Page 137: Fft

    Scientific 19.2.5 FFT The result of FFT (Fast Fourier Transform) calculations is the frequency spectrum of the source signal. The horizontal axis of the FFT display is labeled using frequency (Hz) units instead of time (seconds). In addition, the vertical axis provides the option of logarithmic scaling (dBVrms/dBArms or dBm).
  • Page 138 Scientific When N is greater than 2 Mpts, FFT first decimates N by D, and then takes the first 2 Mpts for the calculation. In this case, FFT sample rate = sample rate in time domain/D. For example, in the case of sample rate in time domain is 5 GSa/s and the number of samples is 5 Mpts, the FFT first decimates the samples by 2, to 2.5 Mpts, and then takes the first 2 Mpts to calculate the...
  • Page 139 Scientific to the maximum frequency component in the previous frame Note: The FFT dialog box is longer than the display. Slide the dialog box area up and down by gestures, or scroll the mouse wheel to the view non-displayed areas.
  • Page 140 Scientific Blackman Poor 12π/N -58 dB 1.1 dB frequency resolution Better amplitude resolution Flattop Poor 23π/N -93 dB < 0.1dB frequency resolution The best amplitude, resolution Display Mode Split: Time domain waveform and frequency domain waveform are • displayed separately. The time domain waveform is on the upper half screen, while the frequency domain waveform is located within the lower half of the display.
  • Page 141 Scientific FFT Mode Normal: Displays the FFT result of each frame directly. • Max-Hold: Holds the maximum value in the historic frame on the display • until cleared. This mode is suitable for detecting discontinuous waves, such as sporadic pulse signals, or frequency hopping signals. Press the Clear Sweeps button on the front panel to clear the max-hold waveform.

  • Page 142: G[F(X)]

    Scientific Measure the FFT waveform Press the Cursors button on the front panel to turn on the cursor function, and then specifying the source as "Math". X1 and X2 cursors can be used to measure the frequency value at the cursor position.
  • Page 143 Scientific g[f(x)]=(C1*C1)+C1, meaningless operation SMO5000X User Manual 143/205...

  • Page 144: Reference

    Scientific 20 Reference Data from analog channels or math can be saved to the reference locations (REFA/REFB/REFC/REFD) in the built-in nonvolatile memory. The saved reference waveform can be recalled to be compared with current waveform. A. Channel waveform B. Reference waveform C.
  • Page 145 Scientific Adjust the Reference Waveform Set the vertical position of the reference waveform by the offset knob shared by Decode, Digital, Math and Ref on the front panel, and set the vertical scale of the reference waveform by the scale knob.

  • Page 146: Search

    Scientific 21 Search The SMO5000X can search for the specified events in a frame. Location of the events are displayed with white triangle indicators. In YT mode or Roll mode with the acquisition stopped, up to 1000 events is supported. In Roll mode with acquisition in run, the number of search events is unlimited.
  • Page 147 Scientific Press the Search button on the front panel or touch the menu Analysis>Search to recall the search dialog box and turn on it. Setup Menu Select and set the search type in the Setup Menu. The SMO5000X provides five search conditions: Edge, Slope, Pulse, Interval and Runt.
  • Page 148 Scientific Search setup is similar to the corresponding trigger type. See the sections “ Edge Trigger”, “Slope Trigger”, ”Pulse Trigger”, ”Interval Trigger” and ”Runt Trigger” for details. Copy The SMO5000X supports replication between search settings and trigger settings. Copy from Trigger: Synchronize the current trigger settings to the search •...

  • Page 149: Navigate

    Scientific 22 Navigate Press the Navigate button on the front panel or touch the menu Analysis>Navigate to recall the navigate dialog box. The SMO5000Xprovides three navigate types: Search Event, Time and History Frame. Navigate by Time The oscilloscope automatically adjusts the trigger delay according to the direction set by the user.
  • Page 150 Scientific Touch the Event List Switch area to turn on or off the list. The list contains time labels for each event. Touching a row in the list automatically jumps to the corresponding event. This operation is equivalent to specifying an event in the Event Num area.
  • Page 151 Scientific The input signal is a 5V periodic square wave, in which every 200ms there is a dwarf pulse with a height of 1/3 of the normal amplitude: First, set the trigger type to Runt to trigger on the dwarf pulse. See the section “Runt Trigger”...
  • Page 152 Scientific Turn on Zoom function to observe the full view of the frame and the detail of the third dwarf pulse at the same time: Press the Run/Stop button on the front panel to stop the acquisition, and then follow the steps Navigate>Type to select “Search Event”. The following figure shows the first dwarf pulse.
  • Page 153 Scientific SMO5000X User Manual 153/205...

  • Page 154: Mask Test

    Scientific 23 Mask Test 23.1 Overview Users can create masks and define the rule used to evaluate Pass/Fail operations. An event violating the rule is defined as a failure and a pulse can be generated from the "Aux Out" port on the back panel. This is very useful to find and quantify anomalies in production tests or similar batch measurements.

  • Page 155: Mask Setup

    Scientific Perform Analysis> Mask Test to open the Mask Test dialog box: A. Turn on/off the test B. Select the source（C1~C4） C. Select the rule（All In, All Out, Any In and Any Out） D. Turn on/off the Pass/Fail operation. Turning off the operation when the test...

  • Page 156: Create Mask

    Scientific A. Create mask automatically according to the waveform B. Create custom mask using the Mask Editor tool C. Specify the location of the mask to be loaded D. Load the mask from the location specified at E. Return to previous menu 23.2.1 Create Mask...

  • Page 157: Mask Editor

    Scientific Set the values for Mask X and Mask Y (in divisions of display graticules), and then perform Create Mask to generate the mask. The horizontal and vertical adjustment range is 0.08~4.00 div. X=0.2div, Y=0.2div X=1div, Y=1div Saving and recalling mask files (*.msk) is similar to the operation of setup files, see the chapter "Save/Recall"...
  • Page 158 Scientific E. Coordinate edit area. Set the X ordinate and Y ordinate by the virtual keypad and then touch the “Input” button the perform the ordinate update F. Display or hide coordinate of polygon vertices on the display G. Exit the tool Menu bar There are 2 menus on the menu bar.

  • Page 159: Pass/Fail Rule

    Scientific To edit a vertex, side or polygon object, firstly select it, and then move it by a dragging gesture or by entering the desired value in coordinate edit area. For a side, the value is for its middle point. For a polygon, the ordinate is for its geometric center.

  • Page 160: Dvm

    Scientific 24 DVM 24.1 Overview The DVM (Digital Voltage Meter) function can be used to measure parameters such as DC and AC amplitudes. The SMO5000X measures the specified parameter of the input signal and can display it in various formats, including: Bar, Histogram and Trend.

  • Page 161: Mode

    Scientific Touch the menu Analysis>DVM to open DVM dialog box: A. Turn on or off the DVM B. Select the source (C1~C4) C. Select the Mode: DC Mean, DC RMS, AC RMS, Peak-Peak, Amplitude, Freq, Period D. Turn on or off the Auto Range E.

  • Page 162: Diagrams

    Scientific AC RMS: Root mean square of the data at AC coupling • Peak-Peak: Difference between maximum and minimum data value • Amplitude: Difference between top and base in a bimodal waveform. If • not bimodal, difference between max and min.
  • Page 163 Scientific A. Mode B. Histogram display area C. Current value D. The bin including the maximum value and probability with which values falling into it E. Statistics counts F. Reset statistics Trend Trend diagram indicates the trend of the measured values over time. Touch trend in the DVM dialog box to display it.
  • Page 164 Scientific C. Extend the range of time. Touch it to expand the time range. D. Current value E. Maximum value F. Minimum value G. Average value H. Reset statistics Press the Clear Sweeps button on the front panel to restart counting and statistics.

  • Page 165: Histogram

    Scientific 25 Histogram 25.1 Overview The SMO5000X supports waveform histograms for observing probability distributions of the waveform in the specified region. The statistics can be performed in both horizontal and vertical directions. The histogram continues to update as long as acquisition is active.
  • Page 166 Scientific Horizontal Vertical Both Region Setting See section “Region Setting” for details. Histogram Statistics When histogram statistics is turned on, the oscilloscope will show statistics parameters of the histogram on the display. SMO5000X User Manual 166/205...

  • Page 167: Region Setting

    Scientific Sum – Total samples falling in the histogram region Peak – Samples in highest bin Max – Maximum value of the samples Min – Minimum value of the samples Pk-Pk – Maximum - Minimum Mean – Mathematical expectation (or average) value of the samples Median –...
  • Page 168 Scientific When the finger moves out of the touch screen, a menu pops up. Select "Histogram" in the menu: After the region is created, it can be moved by dragging gesture. Dialog Box Touch Histogram> Region Setting to recall the dialog box.

  • Page 169: Display

    Scientific 26 Display Display settings include display type of waveform, color, persistence, grid type, trace brightness, graticule brightness etc. Press the Display/Persist button, or touch the menu Display>Menu to recall the display dialog box. A. Switch the waveform display type to Vectors (line display) or Dots B.
  • Page 170 Scientific Vector Display Dot Display Note: In the Run state, due to the high waveform update rate of the oscilloscope, the waveform displayed is the superposition of multiple frames. Therefore, what is seen using the dots display is not the discrete sampling points, but the display effect similar to equivalent sampling.
  • Page 171 Scientific Dots display in Run state Color Grade Color grade uses color temperature to map the probability of the waveforms. The greater the probability that the waveform appears in a pixel, the warmer the color of the pixel. The smaller probability, the colder the color temperature of that pixel.
  • Page 172 Scientific Set Persist With persistence, the oscilloscope updates the display with new acquisitions but does not erase the results of previous acquisitions in specified period. All previous acquisitions are displayed with reduced intensity. New acquisitions are shown in their normal color with normal intensity. In combination with...
  • Page 173 Scientific Set Grid M1:Display 8*10 grid • M2:Display 2*2 grid • M3:Display without grid • M1 Mode M2 Mode SMO5000X User Manual 173/205...
  • Page 174 Scientific M3 Mode SMO5000X User Manual 174/205...

  • Page 175: Arbitrary Waveform Generator

    Scientific 27 Arbitrary Waveform Generator 27.1 Overview SMO5000X supports arbitrary waveform/function generation incorporating an external USB Arbitrary Waveform Generator accessary combined with the software activation using option SMO5000X-FG. The AWG functions include: 6 basic waveforms: Sine, Square, Ramp, Pulse, Noise and DC •...
  • Page 176 MHz and amplitudes up to ±3 V. Its output terminals are isolated from the ground of the oscilloscope. Users can edit and import arbitrary waveforms using the SCIENTIFIC EasyWave software or import edited waveforms through a U-disk. Hardware Connection: Connect the SAG1021I to any USB host port of SMO5000X using a standard USB cable.

  • Page 177: Output

    Scientific 27.2 Output For safety, pressing the Wave Gen button does not automatically turn on the output of AWG. To turn on the output, touch Output in the AWG dialog box after pressing Wave Gen. When the output is enabled, the Wave Gen button lights 27.3 Wave Type...

  • Page 178: Other Setting

    Built-in waveforms are stored in Common, Math, Engine, Window, and Trigo. Stored waveforms are located in the Stored menu. Users can edit arbitrary waveforms using SCIENTIFIC EasyWave PC software, and send the stored waveforms to the instrument through the remote interface, or import the stored waveforms through a U disk.

  • Page 179: System

    Scientific Sync Output When the Sync Output is turned on, the Aux In/Out port of AWG outputs a CMOS signal with the same frequency as the basic waveform (except Noise and DC) and arbitrary waveform. The maximum supported frequency is 10MHz.
  • Page 180 Scientific Device Info – includes Model, Serial Number, Firmware Version and Hardware Version of the AWG module. Upgrade The firmware here refers to the firmware of the SAG1021I module. The SMO5000X supports firmware and configuration file upgrades for the SAG1021I via a U disk.

  • Page 181: Save/Recall

    Scientific 28 Save/Recall The SMO5000X supports saving setups, reference waveforms, screen shots, and waveform data files to internal storage or external USB storage devices (e.g. U disk).Saved setups and reference waveforms can be recalled as needed. 28.1 Save Type SMO5000X supports save types: Setup, Reference, Image (*.bmp/*.jpg/*.png), Waveform Data (binary/csv/matlab), and Calibration Files.
  • Page 182 Scientific Matlab Data Saves the waveform data to external memory in *.dat format which can be imported by Matlab directly. To Default Key The oscilloscope provides two options for the default setting. When the Default Type is set to “Factory”, the factory default setting will be recalled by pressing the Default button on the front panel;...

  • Page 183: Internal Save And Recall

    Scientific 28.2 Internal Save and Recall "Setup" can be saved/recalled to/from the internal memory. In this section the save/recall operations of Setup is introduced. Save oscilloscope setupto internal memory Follow the steps below: A. Select Mode as "Save" B. Select Type as "Setup"...

  • Page 184: External Save And Recall

    Scientific 28.3 External Save and Recall Before performing an external save or recall, make sure the USB storage device is connected correctly. A. Select Save Path as "External" B. Touch the File Manager and open the file manager. If the U disk is not properly connected, the system will prompt "USB flash...
  • Page 185 Scientific Left window: Displays a list of available drives and internal folders. The selected folder has an icon with blue background. • The triangle tag on the left of the folder indicates that the folder includes • subfolder(s). Clicking the tag expands the folder to show the subfolder(s) in the left window.

  • Page 186: External Save And Recall Instance

    Scientific 28.3.2 External Save and Recall Instance Save the screen shot to the path “Udisk0\sds5kx\” in the format of BMP First, Insert the U disk. Secondly, set the parameters of the Save operation: • Select Mode as "Save" • Select Type as "BMP"...
  • Page 187 In step 4, if Save is selected instead of Save As, the system saves the file as the default file name SMO5000X_n.bmp, where n is an integer incrementing from 1. The default save path is \SCIENTIFIC\. Note: Pressing the Print button on the front panel quickly saves a screen shot to the U disk.
  • Page 188 Scientific Recall the setup file "uart_decode.xml" stored in path “Udisk0\sds5kx\” First, insert the U disk with the file "uart_decode.xml" stored folder “\sds5kx\”. Second, set the parameters of the Recall operation: • Select Mode as "Recall" • Select Type as "Setup"...

  • Page 189: System Setting

    Scientific 29 System Setting Most of the system setting can be found in the Utility dialog box, such as system status, language, sound, self-calibration, firmware upgrading. 29.1 System Status Operate Utility>System Setting>System Status to check the system status. System information includes the contents shown below.
  • Page 190 Scientific Click Browse to open the file manager, select the correct upgrade file and click Click Upgrade in the upgrade dialog box to start the upgrade. The oscilloscope first copies the upgrade file (*.ads) to the local memory and parses it. If the parse succeeds, it will show the following dialog.

  • Page 191: Language

    Scientific After the reboot, check if version number in "System Status". Warning: Do Not turn off the power during upgrading. Otherwise, the oscilloscope may not boot up any more! 29.4 Language The SMO5000X supports multiple languages, including: Simplified Chinese, Traditional Chinese, English, French, Japanese, German, Spanish, Russian, Italian, Portuguese, and so on.

  • Page 192: I/O Setting

    Scientific 29.6 I/O Setting 29.6.1 LAN Operate the following steps to set the LAN port: Perform Utility>System Setting>I/O Setting>LAN Config to open the LAN Config dialog box. A. Check Automatic (DHCP) to enable dynamic IP. In this case oscilloscope must connected to the local area network with a DHCP server.

  • Page 193: Vnc Port

    Scientific 29.6.3 VNC Port When accessing more than two SCIENTIFIC instruments through the web browser, it is necessary to set a different VNC port number for each instrument. Perform Utility>System Setting>I/O Setting>VNC Port to set. Touch the VNC Port area and use the universal knob or the virtual keyboard to set the port number, the range is from 5900 to 5999.

  • Page 194: Reference Position Setting

    Scientific A. Option information display area. When the option is not activated, the license type is displayed as "Temporary" and can be tried up to 30 times. B. Select the option to install. C. The option key input area, touch or click the text box and enter the key by the virtual keyboard.
  • Page 195 Scientific • Fixed Position: When the timebase is changed, the horizontal delay remains fixed to the grid position on the display. As the horizontal timebase scale is changed, the waveform expands/contracts around the position of the horizontal display. Vertical Ref •...

  • Page 196: Perform Self Test

    Scientific Fixed position, timebase is changed to 5ns/div, the grid number of delay (-2div) remains fixed, while the horizontal delay changes to -10ns Fixed delay, timebase is changed to 5ns/div, the horizontal delay value remains fixed, while the grid number of delay changes to -4div 29.10 Perform Self Test...
  • Page 197 Scientific Screen Test The screen test is used to find out whether the oscilloscope display has serious color distortion, bad pixels or screen scratches. Perform Utility>Do Self Test>Screen Test, and the oscilloscope will enter the screen test interface as shown below. The screen displays in blue at first.
  • Page 198 Scientific Knob test: Turn each knob clockwise, counter-clockwise, and press down. Observe whether the value on the corresponding knob (default 0) on the screen increases or decreases in real time and whether the knob lights up when it is pressed.

  • Page 199: Do Self Cal

    Scientific Press the "Single" button and the first LED on the front panel will light. The corresponding position of the key on the screen will also change color. Press the "Single" button to check the next button. Press the "Single" button consecutively until all the backlights are tested.

  • Page 200: Default

    Scientific 3. The oscilloscope will not response to any operate until the self-cal is finished. After the self-cal is completed, touch the screen or press any button to exit. 29.12 Default Pressing the Default button on the front panel has an equivalent effect.

  • Page 201: Remote Control

    Scientific 30 Remote Control The SMO5000X provides a LAN port and a USB Device port which can be used for remote control in multiple ways. 30.1 Web Browser A built-in web server provides an approach to visit the oscilloscope by web browser.

  • Page 202: Other Connectivity

    Scientific Below is the instrument control interface: A. Display and control area of the instrument. The display in this area is a copy from the instrument display. Using the mouse to operate in the area is equivalent to directly operating the touch screen display of the instrument.

  • Page 203: Troubleshooting

    The commonly encountered failures and their solutions are listed below. When you encounter those problems, please solve them following the corresponding steps. If the problem remains still, please contact SCIENTIFIC as soon as possible. 1. The screen is still dark (no display) after power on: 1) Check whether the power is correctly connected.
  • Page 204 Scientific 2) Check whether it is a "false wave”: when the signal frequency is very large (more than half of the sample rate), it is easy to appear a "false wave". At this point, a small time base should be set to make the sample rate more than 2 times of the signal frequency.

  • Page 205: Service And Support

    Scientific 32 Service and Support No user serviceable parts are inside the instrument, should it become necessary to send back the instrument to factory for service, please observe the following procedure. 1. Before dispatching the instrument please write to us giving full details of the fault noticed, model number and serial number.

Table of Contents
