Installation manual Daikin room air conditioner Installation manual FTXTJ30A2V1BW English Daikin room air conditioner FTXTJ30A2V1BB... -
Page 2: Table Of Contents
▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). 11 Troubleshooting ▪ The full set of latest technical data is available on the Daikin 11.1 Solving problems based on error codes........11 Business Portal (authentication required). -
Page 3: About The Box
▪ the mounting plate attached to the back of the indoor unit, ▪ the spare SSID sticker located on the front grille. 1× 1× 1× 2× 2× 2× 1× 1× 2× 1× Installation manual Operation manual General safety precautions FTXTJ-A(W)(B) Installation manual Daikin room air conditioner 3P695637-3C – 2023.03... -
Page 4: About The Unit
▪ Wall insulation. When conditions in the wall exceed 30°C and a relative humidity of 80%, or when fresh air is inducted into the ▪ Daikin Industries Czech Republic s.r.o. declares that wall, then additional insulation is required (minimum 10 mm the radio equipment type inside of this unit is in thickness, polyethylene foam). -
Page 5: Mounting The Indoor Unit
4 After completing wiring, refrigerant piping and drain piping, do NOT forget to seal the gap with putty. 2 Insert a wall embedded pipe into the hole. 3 Insert a wall cover into the wall pipe. FTXTJ-A(W)(B) Installation manual Daikin room air conditioner 3P695637-3C – 2023.03... -
Page 6: To Remove The Pipe Port Cover
2 Gradually pour approximately 1 l of water in the drain pan, and check for water leaks. Right-side piping Right-bottom piping Right-back piping Remove the pipe port cover here for right side piping Remove the pipe port cover here for right-bottom piping Installation manual FTXTJ-A(W)(B) Daikin room air conditioner 3P695637-3C – 2023.03... -
Page 7: Piping Installation
Use an all-pole disconnection type breaker with at least Connecting the refrigerant piping 3 mm between the contact point gaps that provides full disconnection under overvoltage category III. DANGER: RISK OF BURNING/SCALDING FTXTJ-A(W)(B) Installation manual Daikin room air conditioner 3P695637-3C – 2023.03... -
Page 8: Specifications Of Standard Wiring Components
1 Set the indoor unit on the mounting plate hooks. Use the " " marks as a guide. Installation manual FTXTJ-A(W)(B) Daikin room air conditioner 3P695637-3C – 2023.03... -
Page 9: To Connect Optional Accessories (Wired User Interface, Central User Interface, Etc.)
To insulate the drain piping, refrigerant piping and interconnection cable 2 Pass the drain hose and refrigerant piping through the wall hole and seal the gap with a putty. FTXTJ-A(W)(B) Installation manual Daikin room air conditioner 3P695637-3C – 2023.03... -
Page 10: To Fix The Unit On The Mounting Plate
Prerequisite: Power supply MUST be in the specified range. commissioning instructions in this chapter, a general Prerequisite: Test run may be performed in cooling or heating commissioning checklist is also available on the Daikin mode. Business Portal (authentication required). Prerequisite: Test run should be performed in accordance with the... -
Page 11: Configuration
INFORMATION ▪ Indoor unit setting: brightness of the Daikin eye, open the front panel, wireless LAN connection, vertical See the service manual for: airflow function, indoor unit installation position, keep ▪... -
Page 12: Technical Data
▪ A subset of the latest technical data is available on the regional Light emitting diode (service Daikin website (publicly accessible). monitor green) ▪ The full set of latest technical data is available on the Daikin HIGH VOLTAGE High voltage Business Portal (authentication required). - Page 13 13 Technical data Symbol Meaning Terminal Terminal strip (block) Electronic expansion valve coil Y*R, Y*S Reversing solenoid valve coil Ferrite core ZF, Z*F Noise filter FTXTJ-A(W)(B) Installation manual Daikin room air conditioner 3P695637-3C – 2023.03...
