- Page 1 Owner’s Manual for the turbochef high conveyor 2020 and 2620 ovens © 2008-2012 TurboChef Technologies, Inc.
- Page 3 For further information, call 800.90TURBO +1 214.379.6000...
- Page 4 The information contained in this manual is important for the proper installation, use, maintenance, and repair of this oven. Follow these procedures and instructions to help ensure satisfactory baking results and years of trouble-free service. Errors – descriptive, typographic, or pictorial – are subject to correction. Specifications are subject to change without notice.
-
Page 5: Table Of Contents
General Safety Information Reducing Fire Risk Preventing Oven Damage Grounding Instructions Power Cord Replacement Specifications and Installation HhC 2020 Dimensions HhC 2020 Electrical Specifications HhC 2620 Dimensions HhC 2620 Electrical Specifications Packaging Certifications Construction Installation Instructions Delivery and Initial Inspection... - Page 6 Oven Modes Config Mode Smart Card Screen (Loading a Menu) Accessing the Fault Count Screen Accessing the Setup Mode Setup Mode Changing the Display Temperature Changing the Belt Direction Edit Options Screen Changing the Speaker Volume Info Screen Updating the Firmware Troubleshooting Replaceable Parts North America Limited Warranty...
- Page 7 Important Safety Information – Please read first Improper installation, adjustment, alteration, service, or maintenance of this equipment can cause property damage, injury, or death. Thoroughly read the installation, operating, and maintenance instructions before installing or servicing this equipment. Strictly adhere to the following safety information to reduce the risk of: Damage to the oven Damage to property near the oven...
-
Page 8: Reducing Fire Risk
When servicing this appliance, do not tear insulation to get to components. Rather, find the edge of the insulation and remove the tape that holds it in place. Clean the oven daily. Clean the oven only with TurboChef Oven Cleaner. DO NOT clean with a water jet. ... -
Page 9: Hhc 2020 Dimensions
Max Input: 14.4 kW (330 mm) 4-wire supply 4.0” (102 mm) NEMA 15-50P plug (4-pin IEC60309 available by special order) figure 3: HhC 2020 Oven Dimensions - front (Single) 13.0” 50-amp max circuit breaker protection (330 mm) 60.1” (1527 mm) with extensions 5”... -
Page 10: Hhc 2620 Dimensions
SPeCIfICATION AND INSTALLATION HhC 2620 Dimensions exterior 17.0” (432 mm) 8.5” (216 mm) Height 13.0” (330 mm) 4.0” (102 mm) 4.0” (112 mm) --with legs 17.0” (432 mm) 24.0” (610 mm) 6.0” (152 mm) 41.7” (1059 mm) Width 48.3” (1227 mm) figure 6: HhC 2620 Oven Dimensions - Side Depth 41.7”... -
Page 11: Packaging
30” (762 mm) deep and capable of supporting local and/or national codes. It is the owner and/ 200 lb. (90.7 kg) for the HhC 2020 and 265 lb. or installer’s responsibility to comply with any (118 kg) for the HhC 2620. -
Page 12: Installation Near Open Heat Source
2” (51 mm) of clearance on each side. least 30” (762 mm) deep and capable of supporting 200 lb. (90.7 kg) for the HhC 2020 and 265 lb. (118 Ventilation requirements kg) for the HhC 2620 (weights are per oven). The... -
Page 13: Daily Cleaning Instructions
Daily Cleaning Instructions = Wash, rinse, sanitize. (Use only TurboChef- = Completely dry with clean towel. approved cleaner, part number 103180). WARNING: Always disconnect power before cleaning or servicing oven. WARNING: DO NOT attempt to clean the oven until it has cooled (screen reads “Oven Off”). -
Page 14: Weekly Cleaning Instructions
Weekly Cleaning Instructions = Wash, rinse, sanitize. (Use only = Completely dry with clean towel. TurboChef-approved cleaner, part number 103180). WARNING: Always disconnect power before cleaning or servicing oven. WARNING: DO NOT attempt to clean the oven until it has cooled (screen reads “Oven Off”). - Page 15 Step 3: Remove Inner Oven Step 4: Clean Oven Components Components Replace lters if damaged or torn.
- Page 16 CLeANING Step 5: Replace Oven Components Step 6: Verify Chain Tension See detail below. Acceptable - Chain (A) is tight and easily clears crumb tray holder (B) Call service to have link removed - Chain (A) is loose and risks contact with crumb tray holder (B) Step 7: Ready the Oven for Use Latch...
-
Page 17: Oven Controls
High h Conveyor by TurboChef BACK IDLE figure 12: Oven Controls Oven Controls Oven Controls Figure 12. Figure 19 1. Display 4. Back/Off Key The display shows current oven operation and/or Depending on the mode the oven is in, the back/ user programming information. -
Page 18: Cooking
STANDArD OVeN OPerATION PROFILE 1 PROFILE 3 PROFILE 1 PROFILE 1 PROFILE 3 TOP AIR 80 % OVEN OFF SOAKING COOLING DOWN BELT F 5:00 TIME LEFT = 5:00 475F OVEN TCC = 425F BELT R PROFILE 2 PROFILE 4 3:20 BTM AIR 100 % PROFILE 2... - Page 19 Mode 3: Warming Mode 6: Cooling Down Mode during which the oven warms to the preset Mode during which the burner assembly shuts off to cooking temperature defined by the cooking profile allow the oven to cool. that was selected. Happens When...
-
Page 20: Editing A Cooking Profile
STANDArD OVeN OPerATION editing a Cooking Profile Changing a Cooking Profile Name 1. From the cooking screen (Figure 14), press To edit a cooking profile, the oven must be in the L1 to access the name change screen cooking mode and the full edit or flex option must (Figure 15). -
Page 21: Adjusting The Belt Speed
Adjusting the Belt Speed Adjusting the Top and Bottom Air The oven can accommodate either one or two con- 1. Press R1 (Figure 14, page 12) to access the veyor belts. The oven will automatically detect the top air controls, or R3 to access the bottom number of conveyor belts installed and display the air controls. -
Page 22: Oven Modes
OVeN MODeS Config Mode Accessing the fault Count Screen From the config mode (Figure 16), press R1 to The config mode (Figure 16) serves four main access the fault counts screen (Figure 20, page 15). purposes: The oven will display the number of faults that 1. -
Page 23: Changing The Display Temperature
Changing the Display Temperature FAULT COUNTS F1: 0 F6: 0 The oven can display the temperature in either F2: 0 F7: 0 F3: 0 F8: 0 Celsius or Fahrenheit units. To change the display F4: 0 F9: 0 F5: 0 F10: 0 temperature, press L1 in setup mode (Figure 21). -
Page 24: Info Screen
Please note that the oven will be inoperable until a successful update is performed. As such, TurboChef reinforces proper handling of smart cards to help prevent static damage, and recommends that each service technician keep a backup copy. -
Page 25: Troubleshooting
Troubleshooting The following is a list of fault codes and error messages, along with the possible problem(s) that the oven may experience. Please attempt the recommended action before calling Customer Support (800.90TURBO, +1 214.379.6000) or your Authorized Distributor. If any fault or error message occurs that is not listed below, contact Customer Support (800.90TURBO, +1 214.379.6000). - Page 26 TrOUBLeSHOOTING Issue Possible Cause(s) resolution F2: Low Temp - Oven power interrupted. - Verify wall circuit breaker is on. Reset breaker During Cook and then power oven back on. - Excessive load. - Reduce load. - Oven is not clean. - Clean the oven following the weekly cleaning instructions on pages 6-8.
-
Page 27: Replaceable Parts
Parts The following is a list of parts that may need replacing during the life of the oven. For more information, please contact TurboChef. (Within North America, call 800.90turbo. Outside North America, call +1 214.379.6000 or your authorized distributor.) -
Page 28: North America Limited Warranty
TurboChef ’s HhC 2020/HhC 2620 conveyor oven owner’s manual (as may be updated by TurboChef from time to time, the “Manual”), a copy of which is provided to you with the Equipment or otherwise will be furnished to you upon request, is excluded from this limited warranty. - Page 29 If the full invoiced amount for Equipment purchased has not been paid within forty-five (45) days from the invoice date, then TurboChef will have no obligation to honor this or any other warranty on the Equipment until payment is received in full, including any accrued interest or other charges, has been satisfied, at which time warranty coverage will be reinstated, but the Warranty Period will not be extended.
- Page 30 Any purported alteration, amendment or modification by a service agent or anyone else will not be enforceable against TurboChef. Waiver Waiver by TurboChef of any default will not be deemed a continuing waiver of such default or a waiver of any other default.
-
Page 31: International Limited Warranty
International Limited Warranty This Limited Warranty shall apply to the sales of all TurboChef HhC 2020 or HhC 2620 Conveyor ovens (the “Equipment”) manufactured by TurboChef Technologies, Inc. (“TurboChef ”), and sold to purchasers outside of the United States, Canada, and Puerto Rico by an Authorized Distributor of TurboChef International (the “Authorized Distributor”). - Page 32 TurboChef ’s option provided that: 1. You notify the Authorized Distributor from whom You purchased the Equipment and/or TurboChef as soon as reasonably possible after discovery of a defect and in accordance with the warranty claims procedure set out below;...
- Page 33 The claim must include the serial number of the Equipment and be received by TurboChef on or before the last day of the Warranty Period. Upon receipt of Your claim, TurboChef will promptly notify an Authorized Distributor or an authorized service agent to contact You, to verify Your claim and, if necessary, to arrange for an on-site repair visit during normal working hours.
- Page 34 Goods to this Limited Warranty is expressly excluded. This Limited Warranty may not be altered, amended or modified by the Authorized Distributor or its service agent, and no representation, alteration, amendment or modification by TurboChef shall be valid unless in a signed form from TurboChef.
- Page 36 For service or information: w i th in n ort h ame rica cal l Customer Support at 1-800-90turbo or outsi d e no rth amer ic a call +1 214-379-6000 or Your Authorized Distributor Global Operations Customer Support: 4240 International Pkwy, Suite 10 5 1 - 80 0- 90 tu rb o Carrollton, Texas 7 50 07 us a +1 214-379-6000...
