9
INSTALLING THE LED LIGHT KIT
NOTE: Before starting installation, make sure power is turned off at the circuit breaker.
Step 1. While holding the LED light kit under the fan motor assembly, make the 2-pin wire
connections:
- Red to white
- Black to black
Step 2. Carefully push all wires back into the mounting plate. Installing the LED light kit to the
mounting plate with the screws provided. (Fig. 17)
CONNECTORS
MOUNTING
PLATE
LED LIGHT KIT
SCREWS
Fig 17
