VISTA-32FB
Designed to integrate seamlessly with CCTV, access
control and ADEMCO's full range of fire and burglary
components, the VISTA-32FB provides the ultimate
protection of life and property. The UL listed Commercial
Fire and Burglary Control Platform can control up to two
separate partitions independently, and supports up to 32
zones/points using hardwired, wireless and addressable
technologies. A diverse line of ADEMCO
initiating devices, notification circuits, digital dialers,
keypads, RF receivers and relays support this extremely
powerful control platform. Advanced technology, combined
with simple end-user operation, make the versatile
VISTA-32FB the smartest choice for the most
demanding applications.
FEATURES:
• Supports addressable
points using VistaKey (1 to 4 doors)
• Supports up to 16 doors of access control
using Vista Gateway Module (VGM)*
• Supports CCTV applications with the new
VistaView-100 CCTV Switcher Module
• Identifies the point or zone of a fire using the
new FSA-8/FSA-24 Fire System Annunciator
• Supports eight hardwired zones, 24
addressable points/zones, or 32 wireless
points/zones
• Can control two separate areas (partitions)
independently
• Stores up to 512 events and can
accommodate 75 user codes
• New E2 Software Simplifies Programing
• Easily programmed and maintained with newly
upgraded Compass Downloader Software
• Automatic smoke detector sensitivity
maintenance testing
• Commercial UL Wireless Fire and Burg
* Connects to Northern Computer's PassPoint
Access Control Systems. Maximum 32 doors.
Commercial
Fire/Burg/CCTV
and Access
Control
Platform
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADEMCO VISTA-32FB
Summary of Contents for ADEMCO VISTA-32FB
- Page 1 VISTA-32FB Designed to integrate seamlessly with CCTV, access control and ADEMCO’s full range of fire and burglary components, the VISTA-32FB provides the ultimate protection of life and property. The UL listed Commercial Fire and Burglary Control Platform can control up to two...
- Page 2 Supported by a diverse line of ADEMCO initiating devices, – Individually assignable to one or all eight partitions the VISTA-32FB is well suited for a variety of smaller to – Up to 16 two-wire smoke detectors each on zone one...
- Page 3 Applications Main Dialer: The VISTA-32FB control is well suited for a variety of • Line seize: Double Pole applications as an integrated fire and burglary control. A • Ringer equiv.: 0.7B diverse line of ADEMCO initiating devices supports this • Formats: ADEMCO Low Speed, ADEMCO 4+2 Express, extremely powerful control.
- Page 4 VISTA-32FB SPECIFICATIONS: Compatible Devices Passive Infrared Detectors: See ADEMCO Group control accessories • 998MX compatibility chart for complete list • 4275EX-SN • 4278EX-SN Auxiliary devices • QUEST2260SN • 4204 – Relay Module, four form C contacts V-Plex (addressable) Contacts: • 4204CF – Two supervised output circuits •...
- Page 5 • Quiescent current draw: 350mA Agency Listings – Individually assignable to one or all eight partitions the VISTA-32FB is well suited for a variety of smaller to • Backup battery: • Burglary – Up to 16 two-wire smoke detectors each on zone one medium sized applications as an integrated –...
