Specifications

CPU
Chipset
Memory
Expansion Slot
Onboard Graphics
Support 3rd Gen AMD Ryzen™ Desktop Processors and AMD
Ryzen™4000 G-Series Desktop Processors
∙ AMD B550 Chipset (B550M PRO)
∙ AMD A520 Chipset (A520M PRO)
∙ 2x DDR4 memory slots, support up to 64GB*
▪ Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/
3000/ 3066/ 3200 MHz by JEDEC
▪ Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200
/3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+
MHz by A-XMP OC MODE
▫ 1DPC 1R max speed 4600 MHz
▫ 1DPC 2R max speed 3866 MHz
∙ Dual channel memory architecture
∙ Supports non-ECC UDIMM memory
∙ Supports ECC UDIMM memory (non-ECC mode)
∙ Supports un-buffered memory
* Please refer www.msi.com for more information on compatible memory.
∙ 1x PCIe x16 slot (PCI_E2)
▪ B550M PRO supports PCIe 4.0/3.0*
▪ A520M PRO supports PCIe 3.0
∙ 2x PCIe 3.0 x1 slots
* The supported specification depends on installed processor.
∙ 1x VGA port, supports a maximum resolution of
2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz**
∙ 1x HDMI 2.1 port, supports a maximum resolution of
4096x2160@60Hz* **
/
∙ 1x DisplayPort 1.2 port, supports a maximum resolution of
4096x2160 @60Hz**
∙ Maximum shared memory of 2048 MB
* Graphics specifications may vary depending on the CPU installed.
** Available for the processor with integrated graphics.
Continued on next page
