Introduction .......................................................2
Important Safety Information ....................3
Features ..............................................................5
Controls and Settings ....................................6
Frigidaire.com USA 1-800-374-4432
Dishwasher
use
&
Operating Instructions ..................................8
Care And Cleaning ........................................ 14
Troubleshooting ............................................. 16
Limited Warranty .......................................... 19
A23587501 (November 2022)
Frigidaire.ca Canada 1-800-265-8352
care
Advertisement
Related Manuals for Frigidaire FDPH4316AW
Summary of Contents for Frigidaire FDPH4316AW
-
Page 1: Table Of Contents
Dishwasher & care Introduction ............2 Operating Instructions ........8 Important Safety Information ....3 Care And Cleaning ........14 Features ..............5 Troubleshooting ..........16 Controls and Settings ........6 Limited Warranty .......... 19 A23587501 (November 2022) Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352... -
Page 2: Introduction
NOTE Very Important Information - Read Before Operating Your Dishwasher! Thank you for bringing Frigidaire into Normal Operating Sounds your home! We see your purchase as the beginning of a long relationship together. This dishwasher does not sound like most dishwashers - IT’S QUIETER. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION for recommendations, if not marked. Items that are not marked WARNING dishwasher safe may melt and create a potential fire hazard. When using your dishwasher, follow • Disconnect electrical power to basic precautions, including the dishwasher before servicing. following: •... - Page 4 IMPORTANT SAFETY INFORMATION Child Safety WARNING Destroy or recycle the carton, plastic bags, and any exterior wrapping material immediately after the dishwasher is To reduce the risk of fire, electrical unpacked. Children should never use shock or injury when using your these items to play.
-
Page 5: Features
Overfill Protector Silverware Basket Heating Element Lower Rack Middle Spray Arm Lower Spray Arm IMPORTANT Accessories are available for your appliance and may be purchased at Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in Canada) or from an authorized seller. -
Page 6: Controls And Settings
CONTROLS AND SETTINGS Option Selections NOTE Wash Cycle Selections: Cycle times are approximate and will Your dishwasher uses a DishSense vary with options selected. Hot water Technology to understand how much is necessary to activate dishwasher food is on the dishes and then adjusts detergent and melt fatty food soils. - Page 7 CONTROLS AND SETTINGS Select the Normal Wash cycle and The cycle time will be extended High Temp wash option along with a until the proper water temperature Rinse Aid agent for improved drying is reached. Washing action will performance. continue during the water heating delay.
-
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Operating Instructions The LEDs of selected cycle and options are illuminated, the status window Getting Started displays the remaining cycle time. The LED above START pad will blink to press Load Dishwasher (See Dish start. Preparation). To resume, press START pad and close 2. - Page 9 OPERATING INSTRUCTIONS Cycle and Option Chart Cycle and intended use Selectable Options Water per Cycle Duration* Temperature; Drying (approx.) (approx.) Heavy Wash Sanitize, 6 - 8.2 gal. 2.5 - 3.75 Max Dry, Heat Dry Hours 23 - 31 L. Recommended for pots, pans, casseroles and dinnerware having light to heavily soiled loads.
- Page 10 OPERATING INSTRUCTIONS 10 place settings standard loading pattern Some models have a fold-down cup shelf 12 place settings standard loading or a cup shelf/stemware holder. They can pattern be used to load two levels of cups, juice glasses, and other short items. Stagger Upper Rack items on upper level so that water can The upper rack can be used to wash a...
- Page 11 OPERATING INSTRUCTIONS Loading the Bottom Rack Loading the Silverware Basket Features and appearance of racks and CAUTION silverware basket may vary from your model. The lower rack is best for plates, saucers, Load sharp items (knives, skewers, etc.) bowls, and cookware. Large items should pointing down.
- Page 12 OPERATING INSTRUCTIONS Adding a Dish • Add detergent just before starting cycle. To add or remove items after wash cycle • Store detergent in a cool, dry starts: location. Moist or caked detergent • Unlatch door and wait a few seconds may not dissolve properly.
- Page 13 OPERATING INSTRUCTIONS Rinse Aid Water Pressure The hot water line to dishwasher must Rinse aid greatly improves drying, provide water pressure between 20 and reduces water spots, filming, and 120 psi. lubricates wash arm bearing for proper rotation. With it water “sheets” off dishes Low Water pressure may occur when rather than forming water droplets that laundry or showers are in operation.
-
Page 14: Care And Cleaning
3. Once empty, slide the glass trap back into the same location as when Cleaning the Interior removed, then push down to lock back into position. See image above. Use Frigidaire ReadyClean Dishwasher ® Cleaner Tablets (Item # 10FFPRDT01) to clean and freshen the interior of the dishwasher. - Page 15 CARE AND CLEANING Care of Drain Air Gap Winterizing If a drain air gap was installed for your A dishwasher left in an unheated place built-in dishwasher, check to make sure should be protected from freezing. Have it is clean so the dishwasher will drain a qualified person do the following: properly.
-
Page 16: Troubleshooting
TROUBLESHOOTING Before You Call • Cups with a concave bottom will collect water. Load them at the far Review this list before calling for service. left and right of the upper rack so It may save you both time and expense. they will be held in a tilted position. - Page 17 TROUBLESHOOTING Vapor at Vent Etching • Spilled rinse aid can cause foam and • Using too much detergent especially lead to overflowing. Wipe up any in soft or softened water causes spills with a damp cloth. damage that looks like a film but cannot be removed.
- Page 18 TROUBLESHOOTING Dishwasher Won’t Run Opening the door during cycle • Check to see if circuit breaker is • If the dishwasher door is opened while the unit is running, the START/ tripped or if a fuse is blown. CANCEL pad must be pressed and •...
-
Page 19: Limited Warranty
Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.265.8352 1-800-374-4432 Electrolux Canada Corp. Frigidaire 5855 Terry Fox Way 10200 David Taylor Drive Mississauga, Ontario, Canada Charlotte, NC 28262 L5V 3E4... - Page 20 Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your registration card for more information.) Frigidaire.com 1-800-374-4432 Frigidaire.ca 1-800-265-8352...
