Frigidaire FDB130RG Factory Parts Catalog

24" built-in dishwasher
Hide thumbs

Advertisement

Quick Links

P30L0080.eps P30C0159.eps P30B0041.eps P30U0024.eps P30M0030.eps P30F0022.eps
P30R0045.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FDB130RGB2 FDB130RGQ2 FDB130RGS2
Series
Built-in 24"
Color
black
Owner's Guide English 154648801
Owner's Guide Spanish 154648803
Owner's Guide French
154648802
Service Data Sheet
154441201
Energy Guide
154540001
Installation Instructions 154427301
Market
North America North America North America
Publication No.
5995503884
07/11/13
(EN/SERVICE/ECL)
821
Built-in 24"
Built-in 24"
bisque
white
154648801
154648801
154648803
154648803
154648802
154648802
154441201
154441201
154540001
154540001
154427301
154427301
24-INCH BUILT-IN
DISHWASHER
Model No.
FDB130RG
©
Copyright
All rights reserved.

Advertisement

loading

  Also See for Frigidaire FDB130RG

  Related Manuals for Frigidaire FDB130RG

  Summary of Contents for Frigidaire FDB130RG

  • Page 1 154648801 154648801 154648803 154648803 154648802 154648802 154648802 154441201 154441201 154441201 154540001 154540001 154540001 154427301 154427301 North America North America North America 24-INCH BUILT-IN DISHWASHER Model No. FDB130RG Publication No. 5995503884 07/11/13 (EN/SERVICE/ECL) © Copyright All rights reserved.
  • Page 2: Control Panel

    Publication No: 5995503884 FDB130RG CONTROL PANEL 11/07...
  • Page 3 154433001 154436201 154587201 154540001 # Functional Parts * Non-Illustrated Parts FDB130RG CONTROL PANEL A FDB130RG (FDB130RGB2) B FDB130RG (FDB130RGQ2) C FDB130RG (FDB130RGS2) DESCRIPTION A - - Panel, control, black, w/graphics - B - Panel, control, brown, w/graphics - - C...
