OPERATOR'S MANUAL
MODEL #BD201045
2300W PORTABLE INvERTER GENERATOR
or visit black-diamond.com
SAvE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do
so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
This product meets the requirements of the PGMA (Portable Generator Manufacturers' Association) standard ANSI/PGMA G300-2015 (Safety and Performance of
Portable Generators).
EN
REV 20221125
Mid-States Distributing, LLC., 2800 Meacham Blvd., Fort Worth, TX 76137 USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD201045 and is the answer not in the manual?

Questions and answers

Related Manuals for Black Diamond Equipment BD201045

Summary of Contents for Black Diamond Equipment BD201045

  • Page 1 OPERATOR’S MANUAL MODEL #BD201045 2300W PORTABLE INvERTER GENERATOR or visit black-diamond.com SAvE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do so could result in serious injury. This manual should remain with the product.
  • Page 2 CARBON MONOXIDE SAFETY: THE BIG PICTURE As the only safe way to use a portable generator, taking your generator outside is absolutely mandatory to keep your family safe from carbon monoxide. But there’s even more you can do. By educating yourself about all carbon monoxide risks, you’ll be better prepared to protect CARBON MONOXIDE K ILLS your family from this colorless, oderless threat.

  • Page 3: Table Of Contents

    TABLE Of CONTENTS Introduction Maintenance ....................Cleaning the Generator .......... Safety Definitions .......... Changing the Engine Oil .........

  • Page 4: Introduction

    (e.g., messages relating to property damage). model and serial numbers of your product. Transcribe the information found on your product’s dataplate label to the table below BLACK DIAMOND TECHNICAL SUPPORT TEAM 1-888-373-8272 MODEL NUMBER BD201045 SERIAL NUMBER DATE OF PURCHASE PURCHASE LOCATION...

  • Page 5: Important Safety Instructions

    IMPORTANT SAfETY INSTRUCTIONS WARNING DANGER   Cancer and Reproductive Harm – www.P65Warnings.ca.gov Generator produces powerful voltage. DO NOT touch bare wires or receptacles. DANGER  DO NOT use electrical cords that are worn, damaged or frayed. Generator exhaust contains carbon monoxide, a colorless, DO NOT operate generator in wet weather.
  • Page 6 IMPORTANT SAfETY INSTRUCTIONS WARNING CAUTION   Running engines produce heat. Severe burns can occur on Improper treatment or use of the generator can damage it, contact. Combustible material can catch fire on contact. shorten its life or void the warranty. DO NOT touch hot surfaces.

  • Page 7: Fuel Safety

    IMPORTANT SAfETY INSTRUCTIONS fuel Safety WARNING  DANGER When starting the generator:  Do not attempt to start a damaged generator. GASOLINE AND GASOLINE VAPORS ARE HIGHLY FLAMMABLE AND EXPLOSIVE. Always check that the gasoline cap, air filter, spark plug, fuel lines and exhaust system are properly in place.

  • Page 8: Safety And Dataplate Labels

    Artwork Notes Artwork Notes Revision Changes Revision Changes MODEL AC AMPS 15.4 BD201045 MODÈLE AMPÈRES C.A. 3mm corner radius; 2mm safe margin; to be printed 3mm corner radius; 2mm safe margin; to be printed 5019280 on white substrate. on white substrate.

  • Page 9: Safety Symbols

    IMPORTANT SAfETY INSTRUCTIONS Safety Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. SYMBOL MEANING Read Operator’s Manual. To reduce the risk of injury, user must read and understand operator’s manual before using this product.

  • Page 10: Operation Symbols

    IMPORTANT SAfETY INSTRUCTIONS Operation Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. SYMBOL MEANING Stop Gasoline Valve Off Choke 12V Direct Current...

  • Page 11: Quick Start Label Symbols

    IMPORTANT SAfETY INSTRUCTIONS Quick Start Label Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. Starting the Engine Stopping the Engine 1.

  • Page 12: Controls And Features

    CONTROLS AND fEATURES Read this operator’s manual before operating your generator. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Generator 1. Carrying Handle – Used to lift or carry the unit. 6.

  • Page 13: Control Panel

    CONTROLS AND fEATURES Control Panel 1. Circuit Breakers (Push Reset) – Protects the generator RECEPTACLES against electrical overloads. (2×) 120V AC, 20A (NEMA 5-20R) 2. Parallel Outlets – Used to parallel two inverters together for May be used to supply electrical power for increased power output.

  • Page 14: Fcc Statement

    CONTROLS AND fEATURES fCC Statement Parts Included 1. This device complies with Part 15 of the FCC Rules. Operation Accessories is subject to the following two conditions: Engine Oil ........13.5 fl.

  • Page 15: Assembly

    ASSEMBLY Your generator requires some assembly. This unit ships from our 1. Place the generator on a flat, level surface. factory without oil. It must be properly serviced with fuel and oil 2. Turn the oil access cover fastener to the unlock position and before operation.

  • Page 16: Add Fuel

    ASSEMBLY 1. Remove the gasoline cap. CAUTION  2. Slowly add gasoline to the tank. Tank is full when gasoline This engine is equipped with a low oil shut-off and will stop reaches red circle on screen. DO NOT OVERFILL. Gasoline can when the oil level in the crankcase falls below the threshold expand after filling.

  • Page 17: Grounding

    ASSEMBLY Grounding WARNING  Your generator must be properly connected to an appropriate Pouring gasoline too fast through the fuel screen may result ground to help prevent electric shock. in gasoline splashing over the generator and operator while filling. WARNING ...

  • Page 18: Operation

    OPERATION Generator Location WARNING  WARNING Do not expose to rain or use in damp locations.  Keep all objects a minimum of 5 feet (1.5m) away from the NEVER operate the generator inside any building, garage, generator at all times. Heat from the muffler surface and basement, crawlspace, shed, enclosure or compartment, exhaust gas stream can ignite combustible materials.
  • Page 19 OPERATION 4. Turn fuel selector dial to the full “CHOKE” position. NOTICE  For gasoline starting in standard ambient temperature >59°F (15°C): Keep fuel selector dial in “CHOKE” position for three pulls of the recoil cord. If generator does not start after three pulls, rotate the fuel selector dial to the “RUN”...

  • Page 20: Connecting Electrical Loads

    OPERATION Connecting Electrical Loads 3. Identify the highest starting wattage of all devices identified in step 1. Add this number to the number calculated in step 2. Let the engine stabilize and warm up for a few minutes after Starting wattage is the surge of power needed to start some starting.

  • Page 21: Eco (Economy) Mode

    For periods of high electrical load or momentary fluctuations, the Eco Mode should be off. The Black Diamond model BD201045 is parallel ready and can be operated in parallel with another Champion unit to increase the total available electrical power. A Champion parallel kit (optional 12v DC Regulated Automotive Style Outlet equipment) is required for parallel operation.

  • Page 22: Moving The Generator

    OPERATION Operation at High Altitude 4. Turn the fuel cap vent lever to the “OFF” position. The density of air at high altitudes is lower than at sea level. Engine power is reduced as the air mass and air-fuel ratio decrease.

  • Page 23: Maintenance

    MAINTENANCE Changing the Engine Oil Make certain that the generator is kept clean and stored properly. Only operate the unit on a flat, level surface in a clean, dry Change oil when the engine is warm. Refer to the oil specification operating environment.

  • Page 24: Cleaning And Adjusting The Spark Plug

    MAINTENANCE Cleaning and Adjusting the Spark Plug Cleaning the Air filter 1. Remove the spark plug access cover. 1. Remove the non-recoil side cover. 2. Locate the air filter plastic cover. Loosen the retaining screw and pull the cover off. 2.

  • Page 25: Cleaning The Spark Arrestor

    MAINTENANCE 6. Replace the spark arrestor if it is damaged. EVERY 50 HOURS OR ANNUALLY 7. Position the spark arrestor on the muffler and attach by — Clean air filter reversing the steps from above. — Change oil if operating under heavy load or in hot environments CAUTION ...

  • Page 26: Storage

    STORAGE Mid Term Storage (30 days – 1 year) WARNING  Ethanol blended gasoline in the tank has a maximum shelf life To avoid accidental or unintended ignition of your generator of up to 1 year with the addition of a properly formulated fuel during periods of storage, the following precautions should be stabilizer and stored in a cool, dry place.

  • Page 27: Long Term Storage (More Than 1 Year)

    STORAGE Long Term Storage (more than 1 year) Removing from Storage For storage over 1 year, the gasoline tank and carburetor must be NOTICE  completely drained of gasoline. If the generator has been improperly stored for a period 1. Be sure all appliances are disconnected from generator. longer than 30 days with ethanol blended gasoline in the 2.

  • Page 28: Specifications

    Generator Model ........BD201045 Use unleaded gasoline with a minimum octane rating of 87 and an ethanol content of 10% or less by volume. DO NOT USE E15 or Start Type .

  • Page 29: Troubleshooting

    TROUBLESHOOTING Problem Cause Solution No fuel. Add fuel. Faulty spark plug. Clean and adjust spark plug or replace. Fill crankcase to the proper level. Low oil level. Place generator on a flat, level surface. Engine will not start. Spark plug wire loose. Attach wire to spark plug.

  • Page 30: Warranty

    WARRANTY Other Exclusions CHAMPION POWER EQUIPMENT 3 YEAR LIMITED WARRANTY This warranty excludes: – Cosmetic defects such as paint, decals, etc. Warranty Qualifications – Wear items such as filter elements, o-rings, etc. To register your product for warranty please visit: –...
  • Page 31 CHAMPION POWER EQUIPMENT, INC. (CPE) AND THE UNITED STATES ENVIRONMENTAL PROTECTION AGENCY (U.S. EPA) EMISSION CONTROL SYSTEM WARRANTY Your Champion Power Equipment (CPE) engine complies with U.S. EPA emissions regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: The US EPA and CPE are pleased to explain the Federal Emission Control Systems Warranty on your 2022 small off-road engine (SORE) and engine powered equipment.
  • Page 32 EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System (ECS) Warranty Coverage. 1. APPLICABILITY: This warranty shall apply to 1997 and later model year small off-road engines (SORE). The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
  • Page 33 EMISSION-RELATED PARTS INCLUDE THE FOLLOWING: (using those portions of the list applicable to the engine) Systems covered by this Parts Description warranty Fuel Metering System Fuel regulator, Carburetor and internal parts Air Induction System Air cleaner, Intake manifold Ignition System Spark plug and parts, Magneto ignition system Exhaust System Exhaust manifold, catalytic converter...
