EEI – 3333 / 3334
STEP 3:
1: Insert Stretcher (4) into the upper hole on the bottom of Front Leg (3) and Seat Frame (2) as shown.
2: Insert 1 piece of Front Leg (3) into the upper hole on the bottom of Seat Frame (2) as shown.
Attach by 2 pieces of Bolt (B), 2 pieces of Spring Washer (D) and 2 pieces of Flat Washer (E) as shown.
3:
4: Repeat the same steps for Front Leg (3).
5: Do not fully tighten Bolt (B) for either leg.
Left (L)
B x 4 D x 4
STEP 4:
1: Attach 1 piece of CSK M4 (G) to the Stretcher (4) to Chair Back (1) and Front Leg (3).
2: Repeat steps to the other side of the Stretcher (4).
G x 4
Customer Service 908-368-1025︱www.modwayfurniture.com
DINING CHAIR
3
L F
4
L
3
R
Right (R)
B
B
E
D
E x 4
3
L
F
4
L
G
B
2
1
F
4
R
B
3
R
F
4
R
B
1
Hardware & Tool required
Hardware & Tool required
