- Page 1 BEOSOUND BOLLARD Installation Manual...
-
Page 2: Table Of Contents
Table of Contents • 1. Introduction • 2. Models & Specifications • 3. Items Included • 4. System Layout • 5. Installation Guidance • 6. Tap Settings • 7. 70V vs 8Ω Wiring Options • 8. 70V Wiring Setup • 9. -
Page 3: Introduction
1. INTRODUCTION Congratulations on selecting one of the finest outdoor speaker systems ever produced. The Bang & Olufsen | Origin Acoustics Bollard is a single unit that houses both a subwoofer and a mid/high frequency satellite in the same enclosure. The speaker is designed to allow the subwoofer section to be buried in the ground leaving only the pillar section exposed. -
Page 4: Models & Specifications
2. MODELS & SPECIFICATIONS The Beosound Bollard is available in: • Round (BOHBLR) or Square (BOHBLS) Sleeve • 360 or 180 Sound Dispersion ROUND SLEEVE (BOHBLR): Sleeve Color Sound Dispersion BOHBLR - Black360 Black BOHBLR - Black180 Black BOHBLR - Natural360... -
Page 5: Items Included
MODEL BOHBLR | BOHBLS Woofer 6 1/2” (165mm) Polypropylene Woofer Midrange 4 1/2” (115mm) Aluminum Tweeter 1” (25mm) PEI Frequency Response 48HZ - 20KHZ Power RMS Power Peak 100W Impedance 6 Ohm (Sub) / 4 Ohm (Sat) Transformer Taps 70V-50W/25W Mounting Depth 8 1/2”... -
Page 6: System Layout
4. SYSTEM LAYOUT Placement of the Beosound Bollard speakers throughout the home’s exterior will depend on a couple of factors. The first is how uniform of a sound field is required. The laws of physics dictate that the further the listener is from the sound source the lower the apparent sound pressure level or “volume.”... - Page 7 5A. OPTIONAL DRAIN PLUG The Bollard loudspeaker comes with a drain plug inserted at the bottom of its subwoofer enclosure. If there is water ingress for any unavoidable reason, removing the drain plug will allow for water to drain out. The drain plug is easily removable with a utility knife. Drain Plug DRAIN PLUG REMAINS IN THE SUB ENCLOSURE This option is recommended:...
- Page 8 DRAIN PLUG IS REMOVED This option is recommended: • In applications with dry soil where occasional water may accidently enter the enclosure. Use of gravel and sand will allow any water that gets into the sub enclosure to properly escape. e.g.
- Page 9 5C. BOLLARD INSTALLATION: LOCATION It is highly recommended that the Bollard speaker be installed at a location such that the water sprinkler nearby (if any) does not spray the water jet into or +/- 2 inches from vertical slots of the bollard shell. FOLLOW ILLUSTRATION BELOW: NOT OK NOT OK NO SPRAY ZONE...
-
Page 10: Tap Settings
6. TAP SETTINGS DSP2-200 100-1 SUB OUT SPEAKER BRIDGED IN(L) EQ PRESET BRIDGED AUTO ON OPTICAL OPTICAL +12V OFF NORMAL Each pair of wires connecting into the subwoofer and satellite portions of Bollard speaker UPDATE BRIDGED TRIGGER IN is labeled as SUB IN and SAT IN respectively. To change the power tap setting, use the tap switch under the cap on the subwoofer. -
Page 11: Wiring Setup
8. 70V WIRING SETUP • Use 1 separate wire run for: Subwoofer portions of Bollards • Use another separate wire run for: Satellite portions of Bollards The Beoamp 125.4 (BEO125 amplifier) from B&O | Origin Acoustics was specifically designed to drive the Beosound outdoor speaker systems. In 70V, is the recommended amp for Sub control and DSP for best performance. - Page 12 8B. 8 BOLLARDS - (25W) 70V WIRING WITH AMP Amp Output mode set to Hi-Z -70V [Bridge mode] • OUTPUT CH1/CH2 for Satallites Amp Output mode set to Hi-Z -70V [Bridge mode] • OUTPUT CH3/CH4 for Subwoofers • OUTPUT CH1/CH2 for Satallites Amp Output mode set to Hi-Z -70V [Bridge mode] •...
- Page 13 8C. 4 BOLLARDS - (50W) 70V WIRING WITH AMP Amp Output mode set to Hi-Z -70V [Bridge mode] Amp Output mode set to Hi-Z -70V [Bridge mode] • OUTPUT CH1/CH2 for Satallites • OUTPUT CH1/CH2 for Satallites • OUTPUT CH3/CH4 for Subwoofers •...
- Page 14 2 BOLLARDS 8Ω WIRING WITH AMP Amp Output mode set to Lo-Z [4~8 ohms] Amp Output mode set to Hi-Z -70V [Bridge mode] • OUTPUT CH1 & CH2 for Satallite • OUTPUT CH1/CH2 for Satallites • OUTPUT CH3 & CH4 for Subwoofer •...
-
Page 15: Painting
10. PAINTING The outer shell (pillar) of the Bollard outdoor speaker is anodized specifically for achieving maximum durability of the pillar color. If you wish to change the color of the Bollard shell by painting or other process, it may compromise the durability and finish of the product compared to the original manufacturing process and modify the specifications. - Page 16 Problem Possible Cause No Sound The volume may be turned down or muted. Check the volume settings on both the amplifier and the DVD player/television/computer/etc. No Sound Make sure the proper source is selected on the amplifier or receiver. No Sound Check the cord connecting the amplifier with the source.
-
Page 17: Technical Assistance
12. TECHNICAL ASSISTANCE If you have any questions or concerns about installing or using this product, you can reach us through one of the following methods: Phone: (844) 674-4461 Hours of operation: 8:00am - 5:00pm (Pacific Time), Mon - Fri Email: sales@originacoustics.com If you are having technical trouble, please include the model number and briefly explain what steps you took to resolve the problem in your email, or be prepared to answer these... -
Page 18: Warranty
13. LIMITED 5 YEAR WARRANTY Origin Acoustics warrants to the original retail purchaser only that this Origin Acoustics product will be free from defects in materials and workmanship, provided the speaker was purchased from an Origin Acoustics authorized dealer. If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. -
Page 19: Return Process
13B. NOT COVERED BY WARRANTY • Accidental damage • Damage caused by abuse or misuse • Damage caused by attempted repairs/modifications by anyone other than Origin Acoustics or an authorized dealer • Damage caused by improper installation • Normal wear, maintenance, and environmental issues •... - Page 20 NOTES...
- Page 21 www.originacoustics.com • 844-674-4461 • www.bang-olufsen.com Revision 07.13.2023 ©2023 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics. ©2023 Bang & Olufsen. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Bang & Olufsen.
