Larson Electronics GL-3 Series Instruction Manual

LED Search Light - 12-24V DC, 460,000 Candela - Permanent Mount -
Thank you for your purchase of a GL-2xxx or GL-3xxx series LED search light from Larson Electronics.
WARNING
Standard Warning (General)
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
•
RELEVANT LOCAL BUILDING CODES.
RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
•
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
• BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
• MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
• TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
SAFETY NOTICE
• If replacing LED module, the LED module
connector should be connected correctly
for positive and negative wires.
RED and BLUE: Positive (+)
BLACK and BROWN: Negative (-)
• FCC RULE Part. 15.21：Changes or
modifications not expressly approved by
the party responsible for compliance could
void the user's authority to operate the
equipment.
• This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
• This searchlight is a Radio Frequency (RF)
device which operates on Channel 433.92
MHz. It will send out RF energy when it is
in operation.
1. RF energy may affect some electronic
equipment.
2. Some electronic equipment on vehicles
or boats may be affected by RF energy.
Larson Electronics, LLC
White Housing
Instruction Manual
SAVE THESE INSTRUCTIONS
Phone: 877-348-9680
GL-2xxx and GL-3xxx Series LED Search Lights
IMPORTANT NOTICE
If searchlight DC power is disconnected (wires
disconnected from battery or power supply switched
off), after reconnecting to power, make sure to turn on
the searchlight using the wireless or wired remote, to
make a full 360° rotation, in order to reset the home
position memory.
Fax: (903) 498-3364 www.larsonelectronics.com
1 of 3
