- Page 1 WhatMiner Hydro Cooling Operation Guide V1.0 Shenzhen MicroBT Electronics Technology Co.,Ltd...
-
Page 2: Table Of Contents
content 1.Product Description ........................2 2.Product parameters and environmental parameters ..............3 3.Installation position and operation items ..................5 3.1 Installation location ........................ 5 3.2 Steps for putting the miner on the shelf: ................6 3.3 Attention: .......................... 8 4. Accessories Specifications ......................10 4.1 Accessories introduction ...................... -
Page 3: Product Description
1.Product Description Whatsminer Hydro Cooling series host model： M34S+,M33S,M33S+,M33S++, M53,M53S,M53S+,M53S++ This guide takes M33S++ as an example to introduce various operations in detail, and the operations of other models are similar The front panel... -
Page 4: Product Parameters And Environmental Parameters
The back panel ①Fixed hole ②Control board ③Network cable port ④Power interface ⑤Handle ⑥Water inlet (quick connector male head, with blue logo) ⑦baffle ⑧Water outlet (quick connector male head, with red logo) ⑨Transport Fixed button 2.Product parameters and environmental parameters Category Item Specifications... - Page 5 Liquid flow ≥10L/min Remarks: 10L/min corresponds to the temperature difference between inlet and outlet water close to 10℃@normal mode, 14℃@high performance mode Liquid pressure ≤300kpa Remarks: When the pressure is more than 300kpa, the hydro cooling plate will be deformed and cause the risk of coolant leakage.
-
Page 6: Installation Position And Operation Items
liquid medium. If the liquid medium uses antifreeze, the liquid temperature and flow parameters need to be calculated separately. Table 2 shows an example of 30% glycol antifreeze temperature and flow parameters. Example of temperature and flow parameters of 30% ethylene glycol antifreeze temperature Working temperature (inlet): 15℃~45℃... -
Page 7: Steps For Putting The Miner On The Shelf
water outtake water intake Back of the cabinet The hydro cooling mining rigs adopts a standard 2u structure design and is installed on a standard 19- inch hydro cooling cabinet. The front and back of the cabinet after the installation of the miner, respectively. 3.2 Steps for putting the miner on the shelf: （1）The first step is to slowly push the mining miner into the cabinet along the card slot. - Page 8 （2）The second step is to loosen the screws on the transportation fixing button on the rear panel of the miner, rotate the transportation fixing button and hook it with the cabinet hook, then tighten the screws, hook the water inlet side and then the water outlet side. The fixing example. Note: When the cabinet is transported with the miner, the miner must be hooked to the cabinet and tightened;...
-
Page 9: Attention
（5）The fifth step is to connect the network cable and power cable. The power cable adopts the original factory configuration power cable. An example of the connection of the network cable and power Steps for unloading: first shut down the miner, and then operate in reverse according to the put-on steps. - Page 10 Error demonstration (connector is not pushed in place)❌ Disconnection indication: Hold the movable ring in the middle of the quick connector (female head) and pull it back to disconnect. （3）Please press the connector shrapnel when unplugging the power cord;...
-
Page 11: Accessories Specifications
shrapnel （4）Before powering on the miner, confirm that the cooling system is circulating normally (the air in the pipeline has been emptied). （5）When all the miner of the same heat dissipation system are turned on at the same time, in order to avoid the overheating protection of the mining miner due to the out- of-control water temperature control of the heat dissipation system, it is recommended that the heat dissipation capacity of the heat dissipation system be fully turned on before all the miner are turned on (that is, the temperature control components of the... - Page 12 quick Interface size: M16X1.0 This connector is the connector screw thread; original water inlet （male Interface sealing interface of the miner head） method: sealing ring end face sealing; Color identification: blue; quick Interface size: M16X1.0 This connector is the connector screw thread;...
-
Page 13: Accessories Notes
power L=1000mm,Single head The socket interface of this cable with socket，4*2mm²; power cord is of the same specification as the power socket interface on the miner power L=1000mm,single head The plug of this power cord cable with plug，4*2mm²; matches the power interface (socket) of the miner 4.2 Accessories Notes Accessories... -
Page 14: Data Configuration（Configuration On The Web
6.Data Configuration（Configuration on the web page） 6.1 Query the dynamic IP address obtained by the miner Miner Data Configuration: Connect PC to the same network the miner is located, run WhatsMinerTools software on the PC, select the “IP Monitor” tab, set the room number, rack number and layer number of the rack where the mining miner is located, the location number of the layer, click "Start". - Page 15 Notes： （1）If all the lights on the panel of the control board are not lit after power-on, please check whether the power supply of the 220V power cable and the 16A power cable are reliable and the connection is correct. （2）If the indicator on the right side of the panel of the control board is on, but the network port is not lit, or the green light is not flashing, check whether the switch is normal, the whether network cable connection is reliable.
-
Page 16: Configuration Pool & Worker
6.2 Configuration Pool & Worker （1）After logging in, go to the Configuration - BTMiner Configuration page. （2）In the Configuration - BTMiner Configuration page, modify the mine pool address, mine worker name, and after modifying click “Save & Apply” in the lower right corner to save the modified configuration. -
Page 17: Modify The Ntp Synchronization Server Address (Optional)
In the System interface, click ”Reboot”. In the Restart interface, click "Perform reboot" to confirm the restart. 6.3 Modify the NTP Synchronization Server Address (optional) （1）After logging in, select System - System Configuration in the interface to enter the BTMiner configuration page. （2）In the BTMiner configuration interface, add or modify the NTP server address. -
Page 18: Configuration The Static Ip Address (Optional)
6.4 Configuration the Static IP Address (optional) （1）After logging in to the miner, in the miner interface, select: Configuration- >Interfaces to enter the network interface configuration interface. （3）In the "Configuration" interface, click "Edit". （4）In the interface modification page, select "Static address" for the protocol and click "Switch protocol". -
Page 19: Miner Operation Status Check
After saving the application, you need to re-use the newly set static IP address to log in to the mining miner (otherwise the page will display as loading until the loading fails). 7.Miner Operation Status Check After the mine is connected to the operation network, log in to the miner and check the running status of the miner. -
Page 20: Batch Configuration
8.Batch configuration You can use the WhatsMinerTool software to carry out batch data configuration, status check and firmware upgrade of the mining miner. For details, please refer to the "Whats Miner WhatsMinerTool Operation Guide". 9.Removal and installation 9.1 Control board removal （1）Power off the device first, then unscrew the two screws in the figure below, and pull the control board out.
