- Page 1 Use and Care Guide PALMETTO 7PCS DINING SET Product code: D71 M20309 UPC code: 471 333112 181 3 Vendor Item: SS-K-233NR/6 Date of purchase: _____/ _____/ _____...
-
Page 2: Table Of Contents
Thank you for your purchase Thank you for your purchase We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team. -
Page 3: Safety Information
Safety Information SET UP YOUR FURNITURE PROPERLY Ensure that all parts are assembled properly and fully tightened as per the instructions. When placing in the desired location, ensure that all legs are resting on the same surface. You may adjust the legs levelers as required to ensure that the item stands in a rigid position. -
Page 4: Care And Maintenance
Care and Maintenance Though its powder-coated finish is rust-resistant, steel is prone to rust over time with exposure to the elements. In case of rust or scratches, lightly sand the affected area and apply touch-up paint. To maintain the finish periodically apply wax with a soft cloth. Wash frames and cushions with a mild solution of soap and water;... -
Page 5: Assembly Instructions Package Content
Pre-Assembly Safety Information Do not completely tighten bolts and nuts until indicated in assembly step. Assembly Instructions Package Contents ITEM DESCRIPTION QUANTITY Chair Left Arm Chair Right Arm Chair Sling Seat And Back Chair Connection Bar Chair Rear Connection Bar... - Page 6 Assembly Instructions Attaching the chair connection bar to the chair arm Ka x 4 M6 Short Bolt Kd x 4 M6 Metal Washer Don’t tighten completely. Repeat procedure for the other side. Attaching the chair sling seat and back to the chair arm Kb x 4 M6 Long Bolt Kd x 4...
- Page 7 Assembly Instructions Attaching the rear connection bar to the chair arm Ka x 2 M6 Short Bolt Kd x 2 M6 Metal Washer Don’t tighten completely. Repeat procedure for the other side. Securely tighten all bolts Repeat procedure for the other three chairs. Package Contents ITEM DESCRIPTION QUANTITY...
- Page 8 Assembly Instructions Attaching the sling seat and back to the rocker arm Kb x 6 M6 Long Bolt Kd x 6 M6 Metal Washer Don’t tighten completely. Repeat procedure for the other arm. Securely tighten all bolts. Attaching the T-shaped bracket to the rocker sling seat and back Kc x 2 M8 Bolt Ke x 2...
- Page 9 Assembly Instructions Pushing the T-shaped bracket to the rocker base Repeat procedure for the other motion chair. Your chairs is now ready for use. Please refer to part numbers when reordering For questions or comments about product: 1- 800-457-4652 Call toll-free: between 9:00 am to 5:00 pm Eastern standard time Monday through Friday or contact us at www.numarkcustomerservice.com Made in / Hecho en CHINA...
- Page 10 Use and Care Guide PALMETTO 7PCS DINING SET Product code: D71 M20309 UPC code: 471 333112 181 3 Vendor Item: SS-K-233NT Date of purchase: _____/ _____/ _____...
- Page 11 Thank you for your purchase Thank you for your purchase We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team.
-
Page 12: Customer Service
Safety Information SET UP YOUR FURNITURE PROPERLY Ensure that all parts are assembled properly and fully tightened as per the instructions. When placing in the desired location, ensure that all legs are resting on the same surface. You may adjust the legs levelers as required to ensure that the item stands in a rigid position. - Page 13 Care and Maintenance Though its powder-coated finish is rust-resistant, steel is prone to rust over time with exposure to the elements. In case of rust or scratches, lightly sand the affected area and apply touch-up paint. To maintain the finish periodically apply wax with a soft cloth. Tabletop ceramic tiles must be stored during fall and winter months in a dry location where temperatures will not fall below 32°F (0°C).Always use an umbrella base to secure umbrella.Ensure the “o”...
- Page 14 Assembly Instructions Package Contents ITEM DESCRIPTION QUANTITY Table Rim (8 Bolts and 8 Metal Washers attached） Metal Leg (2 Bolts and 2 Metal Washers attached for each） Metal Center Ring Large Tile Small Tile...
- Page 15 Assembly Instructions Attaching the leg to the table rim Fa x 8 Bolt (Remove from the table rim) M6 Metal Washer x 8 (Remove from the table rim) Don’t tighten completely. Repeat procedure for the other side. Repeat procedure for the other leg. Attaching the metal center ring to the table rim...
- Page 16 Assembly Instructions Attaching the metal center ring to the table rim Fa x 4 Bolt (Remove from the leg) M6 Metal Washer x 4 (Remove from the leg) Don’t tighten completely. Repeat procedure for the other side. Putting tiles into the table rim...
- Page 17 Assembly Instructions Using tile bumper to adjust the tabletop level if needed Securely tighten all bolts in a digonal pattern. Your table is now ready for use. Please refer to part numbers when reordering For questions or comments about product: 1- 800-457-4652 Call toll-free: between 9:00 am to 5:00 pm Eastern standard time Monday through Friday...
